remote control FORD EXPEDITION 2014 3.G Quick Reference Guide

CONVENIENCE
mYkeY®
MyKey allows you to program certain
driving restrictions in order to promote
good driving habits. You can program
things such as speed restrictions and
limited volume levels. For complete
information, refer to the MyKey chapter
in your Owner’s Manual.
inTegraTed keYhead TranSmiTTer
Press once to lock all doors. Press
again to confirm all doors are closed.
• Press
once to unlock the driver’s
door. Press again within three
seconds to unlock all doors.
• Press
to activate the panic alarm.
Press again or turn the ignition on
to deactivate.
• Press
twice within three seconds
to unlatch the liftgate window. With a
power liftgate*, however, this button
will open or close the power liftgate
or reverse its movement instead of
the liftgate window.
• Car finder: Press
twice within three
seconds to locate your vehicle. The
horn will chirp and the turn lamps
will flash.
SecUricode™ keYLeSS
enTr Y keYP ad
Lock or unlock the doors, or release the
liftgate glass without using a key. The
keypad can be operated with the factory-
set, 5-digit entry code; this code is located
on the owner’s wallet card in the glove
box. You can also create up to five of your
own 5-digit personal entry codes.
To lock all of the doors and liftgate
Press and hold 7•8 and 9•0 at the same
time. For complete information, refer to
the SecuriCode Keyless Entry Keypad in
the Locks chapter of your Owner’s Manual.
rain-SenSing wiPerS*
If activated, your wipers will automatically
turn on when moisture is present on
the windshield. The wiper speed will
vary based on the amount of moisture
detected and the sensitivity setting. To
deactivate, turn your wiper controls off.
Note: Make sure that this feature is turned
off before entering a car wash.
memor Y feaTUre*
The memory function will save and recall
the positions of the driver seat, power
mirrors and adjustable pedals. Use the
memory controls located on the left side
of the driver’s seat
to program
and then recall memory positions.
To program
1. Switch the ignition on.
2. Move the memory features to your
desired position.
3. Press and hold the 1 button
until
you hear a tone.
Use this same procedure to set the
second position using the 2 button
.
You can now use these controls to recall
the set memory positions.
SoS PoST -craSh aLerT SYSTem™
The SOS Post-Crash Alert System
provides audible and visual alarms in
the event of a crash. The turn signals
will flash and the horn will sound. To
deactivate the system, press the hazard
flasher control, or you can press
on
your remote transmitter.
COMFORT
Sea Ting-To-cargo VerSa TiLiTY
Note: Before folding the second- or third-row
seats, make sure that the head restraints are
fully flipped down by pulling on the strap, and
that all items have been removed from the floor
and seats.
To foLd The fLa T-foLding Third-row
Sea TS To The Load fLoor
Pull up on the handle located behind the
seatback while pushing the seatback forward
and down into the seat cushion.
Note: A moderate force may be required to
move the seat forward and down.
To return the seats to an upright
seating position
Lift and pull the seat rearward until the latch
is fully engaged.
Pull Strap
handle
e-Z enTr Y inTo The
Third-row Sea TS
The E-Z entry seat allows for easier
entry and exit to and from the
third-row seat.
To enter the third-row seating area
1. Fold the head restraint forward.
2. Pull up on Lever 1.
3. Fold down the second-row seat
and release the handle.
4. Pull the handle up again until the
seat releases from the floor.
5. Push the seat upward and fold it
away from the third row.
To return the seat to an upright
seating position
1. Push the seat down and latch it
to the floor.
2. Bring the seatback to an upright
position. It should lock into position.
3. Lift up on the head restraint until it
locks into its original position.

Lever 1
Position 2
Position 3
page 11 page 10*if equipped

COMFORT (continued)
Pull Strap
Position 2
Position 3
instrument Panel
Liftgate
Rear Quarter Panel
The sliding shade can be manually opened
or closed when the moonroof is closed. Pull
the shade toward the front of the vehicle to
close it.
Power LifTgaTe oPeraTion*
You can open your power liftgate three
different ways:
• Push the button on the instrument panel
•
Press the
button on your remote entry
transmitter twice within three seconds
•
Press the liftgate control button located
on the inside of the liftgate handle.
To close with the rear cargo area button,
press and release the control located on the
left, rear quarter panel.
Obstacle detection
If the power liftgate is closing, the system
is designed to reverse to fully open when it
encounters a solid obstacle. A three-second
tone also sounds when the system detects
an obstacle. Once the obstacle is removed,
the liftgate can be closed under power.
If the power liftgate is opening, the system is
designed to stop when it encounters a solid
obstacle. A tone will sound for three seconds
while the obstacle is present.
ESSENTIAL INFORMATION
eaSY fUeL® SYSTem
Your vehicle’s fuel system allows you to
open the fuel filler door, insert the nozzle
and start fueling. Wait 10 seconds from the
time the refueling nozzle is shut off until you
remove the nozzle from the vehicle to allow
residual fuel in the nozzle to drain into
the tank.
The Easy Fuel system is self-sealing and
therefore protected against dust, dirt,
water, snow and ice. If you need to fill your
fuel tank with a portable fuel container,
use the fuel funnel which is attached to
the underside of the spare tire cover or
is included with the tire changing tools.
Slowly insert the funnel into the Easy Fuel
system and fill the tank with fuel from the
container. When done, clean the funnel or
properly dispose of it. Extra funnels can be
purchased from your authorized dealer.
Note: Do not use aftermarket funnels as they
will not work with the Easy Fuel system and
may cause damage.
fUeL TYPe and fUeL Tank caP aciTY
Depending on your vehicle, your fuel tank
has a capacity of either 28 gallons (106L)
or 33.5 gallons (126.8L). Flex Fuel vehicles
have a yellow ring around the top of the fuel
filler inlet (tube) and can use either Regular
unleaded fuel, E85 Ethanol fuel or any
mixture of the two. It is best not to alternate repeatedly
between gasoline and E85.
If you do switch
fuels, it is recommended that you add
as much fuel as possible—at least half
a tank. Do not add less than five gallons
(18.9L) when refueling. You should drive
the vehicle immediately after refueling
for at least 5 miles (8 km) to allow the
vehicle to adapt to the change in ethanol
concentration. If you exclusively use E85
fuel, it is recommended to fill the fuel tank
with regular unleaded gasoline at each
scheduled oil change.
fUeL-efficienT TranSmiSSion
Your vehicle has been designed to improve
fuel economy by reducing fuel usage
while coasting or decelerating. This may
be perceived as a light to medium braking
sensation when removing your foot from
the accelerator pedal.
rear window BUffeTing
You may hear a pulsing noise when one or
both of the rear windows are open. Lower a
front window slightly to reduce this noise.
Tire PreSSUre moniToring SYSTem
Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that illuminates
a low tire pressure warning light when one
or more of your tires are significantly under- inflated.
If this happens, stop and check your
tires as soon as possible. Inflate them to the
proper pressure. Refer to the Inflating Your
Tires section in the Wheels and Tires chapter
of your Owner’s Manual for more information.
Loca Tion of SP are Tire and TooLS
Your vehicle is equipped with a temporary
spare tire located under the vehicle, just
forward of the rear bumper. The temporary
spare is designed for emergency use only
and should be replaced as soon as possible.
The jack and tools are located in the access
panel on the floor behind the third-row seat.
Make sure that you turn off the deployable
running boards (if equipped) as well as the
air suspension system (if equipped) prior to
jacking, hoisting or towing your vehicle. For
complete details on how to change your tire,
refer to the Roadside Emergencies chapter in
your Owner’s Manual.
page 13 page 12
To exit the third-row seating area
1. Pull the strap located at the bottom
outboard of the seatback to release it
from the floor. Rotate it up toward the
front seat.
2. Continue pulling up on the pull strap
and the seat will flip forward.
3. To return the seat to the upright
position, push the seat down until
it is latched.
4. Then, lift the seatback and the head
restraint to the upright position.
moonroof*
The moonroof control is located on the
overhead console. It has a one-touch
open and close feature. To stop its motion
during the one-touch operation, press the
control a second time.
To open, press and release the SLiDE
control. It will stop short of the fully
opened position to help reduce wind
noise. Press the SLiDE control again to
fully open the moonroof. To close, pull
and release the SLiDE control.
To vent, press and release the TiLT
control. Pull and hold the TiLT control to
close the moonroof.
*if equipped
roadSide aSSiST ance
Your new Ford Expedition comes with
the assurance and support of 24-hour
emergency roadside assistance.
To receive roadside assistance in the
United States, call 1-800-241-3673.
in Canada, call 1-800-665-2006.
