FORD F150 1996 10.G Owners Manual

249
*
[DR41274( F )02/94]
Ford recommends the following vehicle
specifications for low speed, personal use snow
removal:
[DR41276( F )05/95]
ten pica chart:0021090-B*
[DR41300( F )01/93]
Snowplowing and the Heavy Duty Front
Suspension Package
*
[DR41400( F )03/94]
If you plan to use your vehicle for plowing
snow, it should be equipped with the Heavy
Duty Front Suspension option. After adding the
snowplowing equipment, check the front-end
alignment and if necessary reset to prevent
uneven tire wear. If the snowplowing equipment
is later removed, check the front-end alignment
again.
*
[DR41500( F )01/93]
If you add equipment to your vehicle, which
will not ordinarily be removed when not in use,
such as heavy-duty winches, snowplow
components, brush guards, etc, then the
following index cannot be exceeded.
*
[DR41550( EF )03/94]
NOTE: Diesel equipped vehicles not
recommended for snow plowing.
*
[DR41600( F )01/93]
q
Front axle curb weight must not exceed 63%
of the total vehicle curb weight.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

250
*
[DR41700( F )01/93]
q
If necessary, add weight to the rear of the
vehicle or bed to obtain the above and to
comply with U.S. Federal Hydraulic Brake
Requirements, when aftermarket equipment is
added.
*
[DR41801( F )01/93]
q
The Front Axle Accessory Reserve Capacity
and the Total Accessory Reserve Capacity
listed on the Safety Compliance Certification
Label will help you to determine if the
addition of a snowplow will overload the
vehicle. The total of the weights of all
aftermarket accessories added to your vehicle,
plus the weight of the snowplow, must not
exceed the Total Accessory Reserve Capacity.
Additionally, the portion of these weights
distributed to the front axles must not exceed
the Front Axle Accessory Reserve Capacity.
*
[DR41900( F )01/93]
q
The weight of the snowplow and related
equipment should be properly matched to the
load capacity of your vehicle. The weight of
the installed equipment must not load the
vehicle beyond the GAWR and GVWR listed
on the Safety Compliance Certification Label.
*
[DR41950( F )01/93]
q
Permanently attached plow equipment should
not exceed 270 lbs. (122 kg). The weight of all
installed aftermarket equipment should not
exceed 680 lbs. (308 kg).
*
[DR42000( F )01/93]
Equip your vehicle with lights that conform to
Federal and local regulations for snowplowing.
See your dealer for the correct type of wiring.
*
[DR42100( F )01/93]
Do not plow snow until your vehicle has been
driven 500 miles (800 km). Maintain the vehicle
and snowplow equipment in accordance with
their respective manufacturer's recommendations.
Refer to the notes under Scheduled Maintenance
Services when plowing snow for extended
periods.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

251
*
[DR42200( F )02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
*
[DR42300( F )01/93]
Vehicle Operation On the Road
*
[DR42400( F )01/93]
When operating on the road, your engine may
run at a temperature higher than normal because
the attached snowplow blade will restrict airflow
to the radiator. So if you are driving more than
15 continuous miles (24 km), at temperatures
above freezing, angle the plow blade either full
left or full right to provide maximum airflow to
the radiator. Shorter trips of 15 miles (24 km) in
cold weather may be made at speeds up to
40 mph (64 km/h) without paying special
attention to plow blade position.
*
[DR42500( F )01/93]
Vehicle Operation While Plowing
*
[DR42600( F )01/93]
Guard against transmission and drivetrain
damage. When plowing small areas or heavy
snow, operate with the transfer case in 4L and a
vehicle speed of 0-5 mph (8 km/h). When
plowing larger areas or light snow, at higher
speeds, operate with the transfer case in 4H and
do not exceed 15 mph (24 km/h).
*
[DR42700( F )01/93]
Do not shift the transmission from forward to
reverse until the engine is at idle and the wheels
are stopped.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

253
Roadside Emergencies
%*
[RE00400( ALL)03/95]
Jump-Starting Your Vehicle
*
[RE00450( EF )04/94]
NOTE: Read the7.3L Diesel Engine Owner's
Guide Supplementfor information on
jump-starting your diesel-powered light
truck.
*
[RE00500( ALL)01/95]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start from a booster battery
to start your vehicle.
*
[RE00600( ALL)02/95]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[RE00700( ALL)02/95]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[RE00800( ALL)05/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

254 %
*
[RE00900( ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[RE00925( ALL)05/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE00950( ALL)12/89]
RWARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[RE01000( ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01100( ALL)03/95]
Preparing Your Vehicle
*
[RE01200( ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300( ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

255
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
%*
[RE01700( ALL)05/95]
Connecting the jumper cables
*
[RE01800( ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[RE01900( ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02000( ALL)05/95]
3. Connect one end of the second cable to the
negative (-) terminal of the booster battery
Ð NOT to the discharged battery.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

256
*
[RE02100( ALL)04/95]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
*
[RE02200( ALL)05/95]
RWARNING
Do not connect the end of the second
cable to the negative (-) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
*
[RE02300( ALL)06/93]
one third page art:0020262-C
Attaching jumper cables
*
[RE02500( ALL)03/95]
Jump-Starting
*
[RE02600( ALL)03/95]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[RE02700( ALL)03/95]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[RE02800( ALL)03/95]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

257 %
*
[RE02900( ALL)03/95]
Removing jumper cables
*
[RE03000( ALL)03/95]
1.Always remove the jumper cables in the
reverse order.Remove the negative (s) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[RE03100( ALL)05/95]
2. Remove the negative (s) cable from the
booster battery.
*
[RE03200( ALL)03/95]
3. Remove the positive (+) cable from the
booster battery.
*
[RE03400( ALL)05/95]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[RE03500( ALL)04/95]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
You may need to use a battery charger to fully
recharge the battery.
*
[RE03550( ALL)03/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

258
%*
[RE03600( ALL)03/95]
Changing a Tire
*
[RE03700( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
*
[RE03800( ALL)03/95]
The Conventional Spare Tire
*
[RE03900(BEF )01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
*
[RE04275(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE04280(BEF )10/94]
Extended use of other than matching size spare
tires on a Traction-Lok axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

259
*
[RE05100(BEF )03/95]
Spare Tire Location
*
[RE11700( F )05/90]
The spare tire for your truck is stowed at the
rear under the frame unless you have the
optional in-box spare tire mounting.
*
[RE11750( F )05/90]
one third page art:0020281-A
Spare tire stowage
*
[RE11800( F )03/91]
To remove the spare tire:
*
[RE11900( F )05/90]
1. With the tapered end of the lug nut wrench
through the eyebolt eye, loosen the bolt until
the bracket is loose from the upper support.
Be careful you do not loosen too much and
cause the spare to fall.
*
[RE12000( F )03/90]
2. Line up the eyebolt eye with the channel
slot, the eye toward the tire.
*
[RE12100( F )04/89]
3. Hold the socket end of the wrench parallel
to the ground. Put the tapered end into the
channel assembly tube and lift up on the
wrench. At the same time pull the eyebolt
toward the tube and push on the wrench to
pass the eyebolt through the channel
keyhole.
File:ltref.ex
Update:Thu May 9 15:24:41 1996
