FORD F150 1996 10.G Owner's Guide

28
*
[SR12820(BEF )03/95]
4. After inflation, the gas empties through holes
in the air bag. The air bag deflates at once.
*
[SR12840(BEF )03/95]
The surface of the air bags and the vehicle
interior may be dusted with a powdery residue.
The powder is cornstarch or talcum powder,
which is used to lubricate the air bag as it
inflates, and sodium compounds such as sodium
carbonates (e.g., baking soda), and possibly a
very small amount of sodium hydroxide that
may be irritating to the skin and eyes, but is not
toxic.
*
[SR12860(BEF )03/95]
Right after air bag inflation, you may notice
smoke (from the powder and dust) and smell
the burnt propellant. This is normal.
*
[SR12880(BEF )05/95]
RWARNING
Air bag system components get hot after
inflation. Do not touch them after
inflation.
*
[SR12901(BEF )05/95]
Air bags may not inflate in certain frontal
collisions, even though the vehicle may be badly
damaged. The fact that your air bag did not
inflate in such a collision does not mean that
something is wrong with the air bag system.
Rather, it means the crash forces were not severe
enough to need an air bag to prevent serious
injury.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

29
*
[SR13000(BEF )03/93]
half page art:0011063-A
Inflated driver side air bag
*
[SR13500(BEF )05/95]
RWARNING
If the air bag is inflated, THE AIR BAG
WILL NOT FUNCTION AGAIN AND
MUST BE REPLACED IMMEDIATELY. If
the air bag is not replaced, the unrepaired
area will increase the risk of injury in a
collision.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

30
*
[SR13600(BEF )03/95]
Disposal of supplemental air bag equipped
vehicles
*
[SR13700(BEF )03/95]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer, or refer to the procedures in the 1995
Ford Service Manual. Information on how to
order a service manual is available at an
authorized Ford or Lincoln-Mercury dealer. You
can also order a service manual using the order
form in theAccessorieschapter of your Owner
Guide.
%*
[SR13800(BEF )05/95]
Service and information labels
*
[SR13900(BEF )05/95]
Service and information labels are attached to
the sun visors, the headliner above the sun
visors (Canadian vehicles), and the radiator
support in the engine compartment.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

31
*
[SR14000(BEF )04/95]
full page art:0020847-D
The label located on the back of the driver's sun visor
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

32
*
[SR14200(BEF )02/94]
one third page art:0010605-D
Label on radiator support in the engine compartment
%*
[SR14300(BEF )05/95]
Safety Restraints for Children
*
[SR14400(BEF )02/95]
In the U.S. and Canada, you are required by law
to use safety restraints for children. If small
children ride in your vehicle Ð this generally
includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or
less Ð you must put them in safety seats that
are made specially for children. Safety belts
alone do not provide maximum protection for
these children. Check your local and state laws
for specific requirements.
*
[SR14500(BEF )05/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

33
*
[SR14600(BEF )05/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[SR14700(BEF )05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SR14800(BEF )05/95]
When possible, put children in the rear seat of
your vehicle. Accident statistics suggest that
children are safer when properly restrained in
the rear seating positions than in the front
seating positions.
*
[SR14900( F )05/95]
RWARNING
Do not install a child seat in a center
facing jump seat.
*
[SR15000(BEF )05/95]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

34
*
[SR15025(BEF )05/95]
RWARNING
Never leave a child unattended in your
vehicle.
%*
[SR15250(BEF )05/95]
Safety Belts for Children
*
[SR15300(BEF )05/95]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SR15400(BEF )05/95]
RWARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SR15500(BEF )05/95]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
*
[SR15600(BEF )01/95]
RWARNING
If the shoulder belt cannot be properly
positioned, move the child to one of the
seats with a lap belt only (preferably in a
rear seat) and use the lap belt.
*
[SR15700(BEF )05/95]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

35
*
[SR15800(BEF )05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR15900(BEF )01/95]
Safety Seats for Children
*
[SR16000(BEF )05/95]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SR16015(BEF )02/95]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
[SR16025(BEF )05/95]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position making sure the tongue is securely
fastened in the buckle and for a shoulder/lap
belt combination with a sliding tongue make
sure the retractor is in the ªautomatic locking
mode.º
*
[SR16095(BEF )05/95]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
*
[SR16100(BEF )05/95]
RWARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

36
*
[SR16200(BEF )05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SR16250(BEF )10/94]
RWARNING
Seatbacks should be upright for use with
child safety seats.
*
[SR16275(BEF )05/95]
RWARNING
Always keep the buckle release button
pointing upward and away from the child
seat, with the tongue between the child
seat and the release button as shown in
the following illustration.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

37 [SR16280(BEF )05/95]
half page art:0021377-B
[SR16300(BEF )04/95]
Installing Child Safety Seats
[SR16305( F )04/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for the
front seat passenger and a dual-locking mode
retractor for rear outboard passengers.
[SR16320( EF )04/95]
If you choose to install a forward-facing child
safety seat or infant carrier in the front seating
positions, move vehicle seat as far back as
possible.
[SR16325( EF )04/95]
For seating positions equipped with a
dual-locking mode retractor, use the following
procedure:
*
[SR16345(BEF )04/95]
1. Position the child seat in the center of the
passenger seat.
*
[SR16350(BEF )04/95]
2. Pull down on shoulder belt, then grasp
shoulder belt and lap belt together. Figure 1.
