Engine coolant temperature
Illuminates briefly when the
ignition key is turned to On (light
from optional cluster shown).
Illuminates when the engine
coolant temperature is high. Stop
the engine and check the engine
coolant temperature level as soon
as possible. Refer toChecking
and adding engine coolantand
What you should know about
fail-safe coolingin the
Maintenance and caresection.
Oil pressure
Illuminates briefly when the
ignition key is turned to On (light
from base cluster shown).
Illuminates when the oil pressure
is low. Stop the engine and check
the engine oil level as soon as
possible. Refer toChecking and
adding engine oilin the
Maintenance and caresection.
Door ajar
Illuminates when the ignition
switch is in the ON or START
position and any door is open.
Charging system
Briefly illuminates when the
ignition is turned on and the
engine is off. The light also
illuminates when the battery is not
charging properly, requiring
electrical system service.
DOOR
AJAR
f12_oil_pressure
com_door-ajar.02
com_charging_system.01
com_brake_system.01
Instrumentation
9

Voltage gauge
If the pointer moves and stays
outside of the normal range, it
indicates that the battery is not
being charged. Have the vehicle's
electrical system checked by your
dealer as soon as possible.
Engine oil pressure gauge
This shows the engine oil pressure
in the system. Sufficient pressure
exists as long as the needle
remains in the normal range. If the
gauge indicates constantly low
pressure at normal engine speed,
refer toChecking and adding
engine oilin theMaintenance
and carechapter. If the gauge
indicates a low pressure and the
engine oil level is correct, switch
off the engine immediately and
have your vehicle checked at your
dealer.
Odometer
Registers the total kilometers
(mileage) of the vehicle.
818818
LHLH
MPH
50
4080
120
140
18 0
4060100
20 km/h
0010
000005
MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
0
00
00
00
00
05
5
f12_oil_pressure
f12_odometer f12_trip_odometer
Instrumentation
16

Position Amps Description
9 - Not used
10 - Not used
11 30 Wiper system
12 5 On-board diagnostic (OBD II) data link
connector
13 15 Brake ON/OFF switch, rear anti-lock brake
module and brake pressure switch
14 15 Interior lamps and accessory delay relay
15 5 GEM module/CTM module
16 20 High beam headlamps
17 - Not used
18 5 Instrument illumination
19 10 Air bag diagnostic monitor, instrument cluster
20 5 GEM module/CTM module and powertrain
control module (PCM)
21 15 Starter relay
22 10 Air bag diagnostic monitor and passenger air
bag deactivate switch
23 10 4WD clutch relay, electronic flasher, 4WD/2WD
vacuum solenoids and trailer tow battery charge
relay
24 10 I/P blower relay
25 5 4WABS module and relay
26 10 Right low beam headlamp and DRL module
27 5 Foglamp relay
28 10 Left low beam headlamp
29 5 Autolamp, instrument cluster, transmission
control indicator lamp and switch
30 30 Ignition coils and PCM relay
31 - Not used
Roadside emergencies
138

Do not park, idle, or drive
your vehicle in dry grass
or other dry ground cover. The
emission system heats up the
engine compartment and exhaust
system, which can start a fire.
If you smell exhaust fumes
inside your vehicle, have
your dealer inspect your vehicle
immediately. Do not drive if you
smell exhaust fumes.
On vehicles without
original equipment floor
covering or insulation, do not let
passengers ride in your truck in
a manner that allows contact
between skin and the metal floor.
If you notice one or more of the
following, the emissions system
may not be working properly. Have
your vehicle serviced as soon as
possible.
²Fluid leaks
²The
orCHECK
ENGINElights
illuminate in the instrument
cluster and remain lit
²Strange odors
²Engine runs more than five
seconds after shut-off or engine
misfires, surges, stalls or
backfires
²Loss of oil pressure.
f12_important_emissions_info
