REMOTE ENTRY SYSTEM FEATURES*
Press
once to unlock the driver door. Press again within three seconds to
unlock all of the doors and tailgate*.
Press
once to lock all the doors and the tailgate*. Press again within three
seconds to confirm that you closed and locked all of the doors and tailgate*.
Press
to activate the panic alarm. Press again or switch the ignition on to
deactivate the panic alarm.
Car finder: Press
twice within three seconds. The horn sounds and the
direction indicators flash. We recommend that you use this method to locate
your vehicle, rather than using the panic alarm.
REMOTE TAILGATE RELEASE*
With the tailgate unlocked, you can open the power tailgate by using the
remote transmitter. Press
twice within three seconds.
POWER RUNNING BOARDS*
The running boards automatically extend down and out when you open the
door. This can help you enter and exit your vehicle. When you close the doors,
the running boards return to the stowed position after a two-second delay. To
operate the Power Deploy feature manually, use the information display.
Set the running boards in the deployed position (OUT) to access the roof.
The running boards return to the stowed position and enter automatic mode
when the vehicle speed exceeds 5 mph (8 km/h). TAILGATE STEP*
Use the step to make entering the truck bed easier. This feature includes a
step-up into the box and a handle. These items store inside the tailgate.
To Use
1.
Lower the tailgate.
2. Push the button in the center of the tailgate moulding. The step pops
out slightly.
3. Pull the step out fully and lower it to the lowest position.
4. Pull the yellow handle stop toward you and out of the tailgate.
5. Rotate the handle up from a horizontal position to a vertical one until
you hear a sound, indicating that the handle locked into place.
To Close
1. Store the telescoping handle first. Press button 1 to lower the
telescoping handle.
2. Push button 2 to unlock the handle. Rotate the handle down to a horizontal
position, and then slide it back into the tailgate.
3. Raise the step up and then push it into the tailgate fully to secure.
BOX SIDE STEP*
Use the step for easier access to the trunk bed.
To Use
Push down on the release lever with your foot.
The step automatically extends from the
stowed position.
Push the step under the truck with your foot until it fully latches. Do not push
on the release lever while attempting to stow the step. CARGO AND TRAILER HOOKUP LAMPS*
The cargo lamps are positioned in the central high mounted stop lamp and
to either side of the cargo box. The trailer hookup lamp is positioned on the
tailgate next to the handle. Use the control in the box or on the instrument
panel to switch the lights on and off.
Note: The box lights turn off automatically after 10 minutes, fading
gradually to off.
BOXLINK™ CLEATS*
These cleats attach to the inner box walls to help you to tie down cargo. Lock
the cleats to prevent removal and unlock them for removal.
You can take the cleats out to attach accessories, upfitter package items and
more. See your Owner's Manual for complete details.
Function
You can enable and disable the power running board feature in the
information display. See the Information Display section in your
Owner's Manual for details.
Note: Do not use any part of the power running boards to lift your vehicle
when jacking. Always use proper jacking points. See your Owner’s Manual
for details.
*if equipped
