seat adjustment FORD F250 1996 Owners Manual

118
*
[FV24101(BEF )01/95]
Seats
*
[FV24801(BEF )05/90]
Adjusting the Front Seat Manually
*
[FV24901(BEF )08/94]
To move the front seat forward or rearward:
*
[FV25001(BEF )08/94]
1. Find the adjustment lever at the lower left
corner of the front seat.
*
[FV25101(BEF )10/89]
2. Push the lever to the left to unlatch the seat.
*
[FV25201(BEF )04/95]
3. Move the seat to the desired position.
*
[FV25301(BEF )04/89]
4. Release the lever to latch the seat in its new
position. Make sure the seat locks securely in
place.
*
[FV25600(B F )03/91]
one third page art:0020218-B
Adjusting bucket seat
*
[FV25700(B F )05/95]
one third page art:0020220-E
Adjusting the bench seat
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996
ProCarManuals.com

120
*
[FV26400(BEF )10/89]
Reclining Bucket Seats
*
[FV27301(BEF )02/92]
You can tilt the seat back of your bucket seats
backward.
*
[FV27401(B F )03/93]
1. On the outboard side of the seat, lift the
recliner handle up and hold it in place.
*
[FV27501(BEF )10/89]
2. Lean against the back of the seat and adjust
it to the position you want.
*
[FV27601(BEF )10/89]
3. Release the handle to lock the seat back in
place.
*
[FV27701(BEF )10/89]
4. To return the seat back upright, lift the
handle and lean forward.
*
[FV27800(B F )02/92]
one third page art:0020222-B
Reclining bucket seat
*
[FV28001(B F )10/90]
Lifting the seat-back adjustment lever of an
unoccupied seat will allow the seat back to fold
forward for access to the rear. Pushing the seat
back backward with the handle released returns
the seat upright.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996
ProCarManuals.com

204
*
[DR23250( ALL)11/89]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
*
[DR23300( ALL)02/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes annoyingly loud or increases
significantly in frequency of occurrence, return
the vehicle to your dealer for inspection.
*
[DR23400(BEF )11/89]
RWARNING
Modifications to the suspension spring
rates and/or vehicle ride height may
adversely affect vehicle stopping ability.
*
[DR23500(BEF )07/92]
If Brakes Pull
*
[DR23600(BEF )07/92]
q
Check tire pressure
*
[DR23700(BEF )07/92]
q
Perform the self-adjustment procedure
described underIf Brakes Do Not Grip Well or
Pedal is ªLow.º
*
[DR23800(BEF )05/95]
If pull occurs during the first 500 miles
(800 km), make 10 moderately fast stops from
40 mph (65 km/h) and then perform the
self-adjustment procedure above. It may be
necessary to repeat this operation to properly
seat new brake linings and pads.
*
[DR24000( ALL)01/93]
Stopping Distances
*
[DR24100( ALL)11/89]
Stopping distances vary with different loads and
driving conditions. Use caution when
encountering new conditions and acquaint
yourself with vehicle performance. Take full
advantage of engine braking power when
slowing down.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com
