FORD FIVE HUNDRED 2005 D258 / 1.G Owners Manual

5
2
3
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
251

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the structure by the
trailing edge of the driver’s door or
the edge of the driver’s door.
Vehicle identification number (VIN)
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel. (Please note that
in the graphic XXXX is
representative of your vehicle
identification number.)
XXXXXXXXXXXXXXXXX
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
252

The Vehicle Identification Number (VIN) contains the following
information:
1. World manufacturer identifier
2. Brake type and Gross Vehicle
Weight Rating (GVWR)
3. Vehicle line, series, body type
4. Engine type
5. Check digit
6. Model year
7. Assembly plant
8. Production sequence number
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block and transaxle.
Transmission/Transaxle code designations
You can find a
transmission/transaxle code on the
Safety Compliance Certification
Label . The following table tells you
which transmission or transaxle
each code represents.
Code Description
A CVT (continuously variable transaxle)
B Six-speed automatic (Aisin F21)
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
253

GENUINE FORD ACCESSORIES FOR YOUR VEHICLE
A wide selection of Genuine Ford Accessories are available for your vehicle
through your local authorized Ford or Ford of Canada dealer. These quality
accessories have been specifically engineered to fulfill your automotive
needs; they are custom designed to complement the style and aerodynamic
appearance of your vehicle. In addition, each accessory is made from high
quality materials and meets or exceeds Ford’s rigorous engineering and
safety specifications. Ford Motor Company will repair or replace any
properly dealer-installed Genuine Ford Accessory found to be defective in
factory-supplied materials or workmanship during the warranty period, as
well as any component damaged by the defective accessory. The accessory
will be warranted for whichever provides you the greatest benefit:
•12 months or 12,000 miles (20,000 km) (whichever occurs first), or
•the remainder of your new vehicle limited warranty.
This means that Genuine Ford Accessories purchased along with your
new vehicle and installed by the dealer are covered for the full length of
your New Vehicle’s Limited Warranty — 3 years or 36,000 miles (60,000
km) (whichever occurs first). Contact your dealer for details and a copy
of the warranty.
Not all accessories are available for all models.
The following is a list of several Genuine Ford Accessory products for
your vehicle. Not all accessories are available for all models. For a
complete listing of the accessories that are available for your vehicle,
please contact your dealer or visit our online store at:
www.fordaccessoriesstore.com.
Exterior style
Bug shields
Front end covers
Side window air deflectors
Moonroof air deflectors
Splash guards
Wheels
Interior style
Electrochromic compass/temperature/Homelink options
Floor mats
Scuff plates
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Accessories
254

Lifestyle
Engine block heaters
Interior cargo organization and management
Smoker’s pack
Peace of mind
First aid kits
Full vehicle covers
Highway safety kits
Keyless entry keypads
Locking gas cap
Navigation systems
Remote start
Vehicle security systems
Wheel locks
For maximum vehicle performance, keep the following information in
mind when adding accessories or equipment to your vehicle:
•When adding accessories, equipment, passengers and luggage to your
vehicle, do not exceed the total weight capacity of the vehicle or of
the front or rear axle (GVWR or GAWR as indicated on the Safety
Compliance Certification label). Consult your dealer for specific weight
information.
•
The Federal Communications Commission (FCC) and Canadian Radio
Telecommunications Commission (CRTC) regulate the use of mobile
communications systems — such as two-way radios, telephones and
theft alarms - that are equipped with radio transmitters. Any such
equipment installed in your vehicle should comply with FCC or CRTC
regulations and should be installed only by a qualified service technician.
•Mobile communications systems may harm the operation of your vehicle,
particularly if they are not properly designed for automotive use.
•To avoid interference with other vehicle functions, such as anti-lock
braking systems, amateur radio users who install radios and antennas
onto their vehicle should not locate the Amateur Radio Antennas in
the area of the driver’s side hood.
•Electrical or electronic accessories or components that are added to
the vehicle by the dealer or the owner may adversely affect battery
performance and durability.
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Accessories
255

A
Accessory delay ..........................48
Air cleaner filter .......................245
Air conditioning ....................27, 29
Airbag supplemental restraint
system ........................109, 116, 119
and child safety seats ............111
description ..............109, 116, 119
disposal ....................................122
driver airbag ............111, 117, 120
indicator light .................116, 121
operation .................111, 117, 120
passenger airbag .....111, 117, 120
side airbag ...............................116
All Wheel Drive (AWD),
driving off road .........................178
Antifreeze
(see Engine coolant) ................225
Anti-lock brake system
(see Brakes) ..............................169
Anti-theft system ........................86
arming the system ....................86
disarming a triggered system ..87
Audio system (see Radio) ...17, 20
Automatic transaxle
fluid, adding ....................242–243
fluid, checking ................242–243
fluid, refill capacities ..............246
fluid, specification ..................250
Automatic transmission
driving an automatic
overdrive .........................174–175
Axle
lubricant specifications ..........248
B
Battery .......................................223acid, treating emergencies .....223
jumping a disabled battery ....194
maintenance-free ....................223
replacement, specifications ...245
servicing ..................................223
BeltMinder .................................103
Brakes ........................................169
anti-lock ...................................169
anti-lock brake system (ABS)
warning light ...........................169
fluid, checking and adding ....242
fluid, refill capacities ..............246
fluid, specifications .........248, 250
lubricant specifications ..248, 250
parking ....................................170
shift interlock ..........................172
Bulbs ............................................37
C
Capacities for refilling fluids ....246
Cargo net .....................................71
Cassette tape player ...................17
Cell phone use ............................70
Changing a tire .........................138
Child safety restraints ..............123
child safety belts ....................123
Child safety seats ......................125
attaching with tether straps ..129
in front seat ............................127
in rear seat ..............................127
Cleaning your vehicle
engine compartment ..............211
instrument panel ....................213
interior .....................................213
interior trim ............................213
plastic parts ............................212
washing ....................................210
waxing .....................................210
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Index
256

wheels ......................................211
wiper blades ............................212
Climate control (see Air
conditioning or Heating) ......27, 29
Clock ............................................45
Clock adjust
6-CD in dash .............................21
Compass, electronic
set zone adjustment .................61
Console ........................................70
overhead ....................................45
Controls
power seat .................................90
steering column ........................53
Coolant
checking and adding ..............225
refill capacities ................230, 246
specifications ..................248, 250
Cruise control
(see Speed control) ....................50
Cupholder(s) ...............................94
Customer Assistance ................185
Ford accessories for your
vehicle .....................................214
Ford Extended Service
Plan ..........................................207
Getting assistance outside the
U.S. and Canada .....................208
Getting roadside assistance ...185
Getting the service you
need .........................................201
Ordering additional owner’s
literature .................................208
The Dispute Settlement
Board .......................................203
Utilizing the
Mediation/Arbitration
Program ...................................206D
Daytime running lamps
(see Lamps) ................................34
Dipstick
automatic transmission
fluid ..................................242–243
engine oil .................................219
Doors
lubricant specifications ..........248
Driving under special
conditions ..........................179, 182
sand .........................................181
snow and ice ...........................183
through water .................181, 184
E
Electronic message center .........59
Emergencies, roadside
jump-starting ..........................194
Emission control system ..........239
Engine ........................................250
cleaning ...................................211
coolant .....................................225
idle speed control ...................223
lubrication
specifications ..................248, 250
refill capacities ........................246
service points ..........................218
starting after a collision .........186
Engine block heater .................168
Engine oil ..................................219
change oil soon warning,
message center .......................219
checking and adding ..............219
dipstick ....................................219
filter, specifications ........222, 245
recommendations ...................222
refill capacities ........................246
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Index
257

specifications ..................248, 250
Exhaust fumes ..........................168
F
Fluid capacities .........................246
Foglamps .....................................34
Four-Wheel Drive vehicles
driving off road .......................178
Fuel ............................................231
calculating fuel
economy ............................60, 236
cap ...........................................233
capacity ...................................246
choosing the right fuel ...........234
comparisons with EPA fuel
economy estimates .................239
detergent in fuel .....................235
filling your vehicle with
fuel ...........................231, 233, 236
filter, specifications ........235, 245
fuel pump shut-off switch .....186
improving fuel economy ........236
octane rating ...................234, 250
quality ......................................235
running out of fuel .................235
safety information relating to
automotive fuels .....................231
Fuel pump shut-off switch .......186
Fuses ..........................................187
G
Garage Door Opener
(see Homelink wireless control
system) ........................................55
Gas cap (see Fuel cap) ............233
Gas mileage
(see Fuel economy) .................236
Gauges .........................................14H
Hazard flashers .........................186
Head restraints .....................88, 93
Headlamps ...................................33
aiming ..................................35–36
autolamp system .......................33
bulb specifications ....................38
daytime running lights .............34
flash to pass ..............................35
high beam .................................35
replacing bulbs ...................38–39
turning on and off ....................33
Heating
heating and air conditioning
system ...........................25, 27, 29
Homelink wireless control
system ..........................................55
Hood ..........................................217
I
Ignition ...............................165, 250
Infant seats
(see Safety seats) .....................125
Inspection/maintenance (I/M)
testing ........................................241
Instrument panel ........................45
cleaning ...................................213
cluster ........................................10
lighting up panel and
interior .......................................35
J
Jack ............................................138
positioning ...............................138
storage .....................................138
Jump-starting your vehicle ......194
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Index
258

K
Keyless entry system .................80
autolock .....................................82
Keys
positions of the ignition .........165
L
Lamps
autolamp system .......................33
bulb replacement
specifications chart ..................38
daytime running light ...............34
fog lamps ...................................34
headlamps .....................33, 38–39
headlamps, flash to pass ..........35
instrument panel, dimming .....35
interior lamps ...........................37
replacing bulbs ...................37–42
Lane change indicator
(see Turn signal) ........................37
Lights, warning and indicator ....10
anti-lock brakes (ABS) ..........169
Load limits .................................155
Locks
autolock .....................................82
childproof ..................................73
doors ..........................................72
Lubricant specifications ...248, 250
Lug nuts ....................................145
Lumbar support, seats ...............89
M
Message center ...........................59
english/metric button ...............63
system check button ................64
warning messages .....................64
Mirrors ...................................45, 49automatic dimming rearview
mirror ........................................49
fold away ...................................49
side view mirrors (power) .......49
Moon roof ....................................54
Motorcraft parts ................235, 245
O
Octane rating ............................234
Oil (see Engine oil) ..................219
P
Parking brake ............................170
Parts (see Motorcraft parts) ....245
Passenger Occupant
Classification Sensor ...................96
Power adjustable foot pedals .....50
Power distribution box
(see Fuses) ...............................190
Power door locks ........................72
Power mirrors .............................49
Power point .................................46
Power steering ..........................172
fluid, checking and adding ....241
fluid, refill capacity ................246
fluid, specifications .........248, 250
Power Windows ...........................46
R
Radio ......................................17, 20
Relays ........................................187
Remote entry system .................75
illuminated entry ................79–80
opening the trunk .....................76
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Index
259

Reverse sensing system ...........176
Roadside assistance ..................185
S
Safety Belt Maintenance ..........108
Safety belts (see Safety
restraints) ......................95, 98–102
Safety Canopy ...........................119
Safety defects, reporting ..........209
Safety restraints ............95, 98–102
belt minder .............................103
extension assembly ................108
for adults ...........................99–101
for children .....................122–123
Occupant Classification
Sensor ........................................96
safety belt maintenance .........108
warning light and
chime ...............................102–103
Safety seats for children ..........125
Safety Compliance
Certification Label ....................252
Seat belts
(see Safety restraints) ...............95
Seats ............................................88
child safety seats ....................125
front seats .....................88, 90, 92
heated ........................................29
memory seat .......................76, 92
Servicing your vehicle ..............216
Setting the clock
AM/FM/In-dash 6 CD ................21
Spare tire (see Changing
the Tire) ............................139, 141
Spark plugs,
specifications .....................245, 250Specification chart,
lubricants ...........................248, 250
Speed control ..............................50
Starting your vehicle .......165–166,
168
jump starting ..........................194
Steering wheel
controls ......................................53
tilting .........................................44
T
Tilt steering wheel ......................44
Tires ...........................133–134, 138
alignment ................................152
care ..........................................151
changing ..................138–139, 141
checking the pressure ............136
inspecting and inflating .........135
label .........................................150
replacing ..................................138
rotating ....................................153
safety practices .......................152
sidewall information ...............145
snow tires and chains ............154
spare tire .................................139
terminology .............................134
tire grades ...............................134
treadwear ........................133, 151
Towing .......................................161
recreational towing .................164
trailer towing ..........................161
wrecker ....................................199
Traction control ........................171
Transaxle
fluid, refill capacities ..............246
lubricant specifications ..........250
Transmission .............................172
brake-shift interlock (BSI) ....172
2005 Five Hundred(500)
Owners Guide (post-2002-fmt)
USA(fus)
Index
260
