Fuel Tank
Capacity/Fuel Info
Fuel tank capacity varies on your Fusion,
depending on your drive type: 16.5 gallons
(62.5 liters) for front-wheel drive models
and 17.5 gallons (66.2 liters) for all-wheel
drive models. Use only UNLEADED
gasoline with an 87 octane rating. Do not
use ethanol (E85), diesel, fuel-methanol,
leaded fuel or any other fuel because
it could damage or impair the emission
control system.
Fuel-efficient
Automatic Transmission
*
Your vehicle has been designed to improve
fuel economy by reducing fuel usage
while coasting or decelerating. This may
be perceived as a light to medium braking
sensation when removing your foot from
the accelerator pedal.
Easy Fuel® System
With this system, open the fuel door, insert
the nozzle and begin fueling. It is self-
sealing and therefore protected against
dust, dirt, water, snow and ice. Wait 10
seconds from the time the refueling nozzle
is shut-off until you remove the nozzle from
the vehicle to allow residual fuel in the
nozzle to drain into the tank.
NOTE When using a portable fuel
container, use the removable fuel funnel,
located behind the left rear seat, under
the carpet. To access, fold the seatback
down and pull back the piece of carpet.
Slowly insert the fuel funnel and pour the
fuel into the funnel. When done, clean the
funnel or properly dispose of it. Do not use
aftermarket funnels as they will not work
with the Easy Fuel system and may cause
damage. Refer to the Refueling section
in the Fuel and Refueling chapter of your
Owner's Manual for additional information.
ESSENTIAL INFORMATION
13*if equipped
Electric Parking Brake
This feature replaces the conventional
handbrake. The operating switch is located
on the center console, to the left of the
gearshift lever. To apply the electric parking
brake, pull the switch up. The brake system
warning lamp will light to confirm that the
electric parking brake has been applied.
You can release the electric parking brake
manually by switching the ignition on,
pressing the brake pedal and then pressing
the electric parking brake switch. Refer to
the Brakes chapter of your Owner's Manual
for more details.
Towing Your Fusion
Towing your vehicle behind an RV or any
other vehicle may be limited. Refer to
Towing the Vehicle on Four Wheels in the
Towing chapter of your Owner’s Manual.
Roadside Assistance
Your new Ford vehicle comes with the
assurance and support of 24-hour
emergency roadside assistance.
To receive roadside assistance in the
United States, call 1-800-241-3673.
In Canada, call 1 -800-665-2006.
BLIS® (Blind Spot
Information System)
with Cross Traffic Alert
*
BLIS uses radar sensors to help you
determine if a vehicle may be in your blind
spot zone. Cross traffic alert will alert you
if a car is coming toward you when you
are backing out of a parking space. BLIS

and cross traffic alert will display a yellow
indicator light in your exterior mirrors and
cross traffic alert will also sound tones
and display messages to warn you which
direction vehicles are approaching. Refer
to the Driving Aids chapter in your Owner’s
Manual for more information.
Tire Pressure
Monitoring System
Your vehicle displays a low tire pressure
warning light in your instrument
cluster when one or more of your tires are
significantly under-inflated. If this happens,
stop and check your tires as soon as
possible, then inflate them to the proper
pressure. Refer to the Inflating Your Tires
section in the Wheels and Tires chapter of
your Owner’s Manual for more information.
