TPMS training tools
The customer training tool, P/N 8C2Z-1A203-A, can be purchased from
any Ford dealer for training the system after maintenance has been
performed that requires system training. The tire pressure monitor
activation tool, P/N 204-363, is also available through the Rotunda
catalog. For either tool, follow the training instructions as outlined below.
TPMS sensor training procedure
Note:To reduce the chances of interference from another vehicle, TPMS
training should be performed at least three feet (one meter) away from
another Ford Motor Company vehicle undergoing the TPMS training
procedure at the same time.
Note:Do not wait more than two minutes between resetting each tire
sensor or the system will time-out and the entire procedure will have to
be repeated on all four wheels.
A double horn chirp indicates the need to repeat the procedure.
TPMS training procedure
Note:It is recommended that you read the entire procedure before
attempting.
Note:To enter the training mode, Steps 1–6 MUST be completed within
60 seconds.
1. Place the ignition in the off position and keep the key in the ignition.
2. Press and release the brake pedal.
3. Cycle the ignition from off to on three times ending in the on position
- DO NOT start the engine.
4. Press and hold the brake pedal for two seconds, then release.
5. Turn the ignition to off - DO NOT remove the key.
6. Cycle the ignition from off to on three times ending in on - DO NOT
start the engine.
If the training mode has been entered successfully, the horn will sound
once, the TPMS indicator will flash, and the information display will show
TRAIN LF TIRE.
If after repeated attempts to enter the training mode, the horn does not
sound, the TPMS indicator does not flash, and the information display
does not show TRAIN LF TIRE, seek service from your authorized
dealer.
