Page 17 of 288
13
*
[IS02700(ALL)03/96]
This light will also illuminate if the parking
brake does not release fully. If it does stay on
afterthe parking brake is fully released, it
means there may be a brake problem. Pull off
the road and stop carefully. You may notice that
the pedal is harder to push, the pedal may go
closer to the floor, or it may take longer to stop
the vehicle. Try the brakes again after you have
stopped.
*
[IS02800(ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
%*
[IS02900(ALL)03/96]
Anti-Lock Brake System Warning Light
[IS03000(ALL)03/96]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light will illuminate. When the engine is started,
the anti-lock brake system control unit will
determine if all components of the system are
operating correctly. The warning light could
remain on for two to four seconds.
[IS03100(ALL)01/96]
one inch art:0032359-C
The anti-lock brake system warning light
*
[IS03200(ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 19 of 288
15 %
*
[IS03800(ALL)05/96]
High Beam Light
*
[IS03900(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
*
[IS04000(ALL)01/96]
one inch art:0030174-A
High beam light
%*
[IS04100(ALL)03/96]
Check Engine Warning Light
*
[IS04200(ALL)03/96]
This light illuminates when the electronic engine
control system is not working properly. This is
the computer that controls the operating
conditions of the engine.
*
[IS04300(ALL)01/96]
one inch art:0030175-B
Check engine warning light
[IS04400(ALL)03/96]
This light illuminates briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 21 of 288
17
*
[IS05400(ALL)01/96]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. You can get a more
accurate reading with the vehicle on smooth,
level ground.
[IS05500(ALL)01/96]
Charging System Gauge
[IS05600(ALL)01/96]
This gauge tells you your battery's voltage when
you turn your ignition key to ON. When you
start your engine, the pointer should move to
the NORMAL range if you are not operating
any electrical accessories. (If electrical accessories
are operating and the engine is not running, the
pointer may move into the red area).
[IS05700(ALL)01/96]
If the pointer moves into the red area when no
electrical accessories are operating, have the
vehicle's electrical system checked.
%*
[IS05800(ALL)04/96]
Engine Oil Pressure Gauge
[IS05900(ALL)01/96]
The gauge needle should stay in the NORMAL
range (indicating normal engine oil pressure). If
the needle drops below the NORMAL range into
the low range, there is a loss of oil pressure.
[IS06000(ALL)01/96]
If this happens:
*
[IS06100(ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS06200(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
[IS06300(ALL)01/96]
3. Check the oil level when the vehicle is on
level ground.
[IS06400(ALL)01/96]
4. Add only as much oil as the engine needs
before you drive the vehicle again. Do not
overfill the oil reservoir. For more
information, seeAdding engine oilin the
Index.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 22 of 288
18 %
*
[IS06500(ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS06600(ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS06650(ALL)04/96]
The pointer usually moves from C (cold) into
the NORMAL band as your vehicle warms up.
Under most driving conditions, the pointer
should stay in the NORMAL band. If you are
driving in heavy traffic or on an extended grade
in hot weather, the pointer may reach to the top
of the NORMAL band.
*
[IS06700(ALL)04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
*
[IS06800(ALL)03/96]
If your engine overheats:
*
[IS06900(ALL)03/96]
1. Pull off the road as soon as it is safely
possible.
*
[IS07000(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
*
[IS07100(ALL)01/96]
3. Let the engine cool.
*
[IS07200(ALL)01/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. (SeeEngine coolantin the
Index.) If you do not follow these
instructions, you or others could be injured.
*
[IS07250(ALL)01/96]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 131 of 288
128 %
*
[TO06510(ALL)01/96]
If the engine does not start after two attempts:
*
[TO06520(ALL)01/96]
1. Turn the ignition key to the OFF position.
*
[TO06530(ALL)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO06540(ALL)01/96]
3. Turn the ignition key to the START position.
*
[TO06550(ALL)01/96]
4. Release the ignition key when the engine
starts.
*
[TO06560(ALL)03/96]
5. Release the accelerator gradually as the
engine speeds up.
*
[TO06570(ALL)05/96]
If the engine still does not start, the fuel pump
shut-off switch may have been activated. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the index.
%*
[TO06580(ALL)01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs high. These faster
engine speeds will make your vehicle coast
slightly faster than its normal idle speed. It
should, however, slow down after a short time.
If it does not, have the idle speed checked.
*
[TO06585(ALL)01/96]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[TO06590(ALL)01/96]
RWARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996
Page 134 of 288
131
*
[TO12100(ALL)01/96]
Have the exhaust and body ventilation systems
checked whenever:
*
[TO12200(ALL)01/96]
q
your vehicle is raised for service
*
[TO12300(ALL)01/96]
q
the sound of the exhaust system changes
*
[TO12400(ALL)01/96]
q
your vehicle has been damaged in a collision
*
[TO12500(ALL)01/96]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
*
[TO12600(ALL)01/96]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, adjust
the heating or air conditioning system to bring
in outside air.
[TO12800(ALL)01/96]
q
If you are using the heater, set the fan speed
on MEDIUM or HIGH with the function
selector control on VENT.
[TO13000(ALL)01/96]
q
If you want to use the air conditioner, set the
function selector control in the NORM A/C
position which brings in fresh air.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996
Page 138 of 288
135
engine and restart. If it remains illuminated, it
means the ABS is disabled and should be
serviced immediately to restore the benefits of
the anti-lock feature. Normal braking is not
affected unless the red BRAKE system warning
light is also illuminated.
[GF01500(ALL)04/96]
ABS has self-check capabilities. As described
above, the system turns on the ABS light each
time you start your engine. After the engine is
started and the ABS light turns off, the system
performs another test the first time the vehicle
reaches 4-9 mph (6-15 km/h). The system turns
on the ABS pump motor for approximately 1/2
second. At this time, a mechanical noise may be
heard. This is a normal part of the self-check
feature. If a malfunction is found during this
check the ABS light will come on.
[GF01510(ALL)12/96]
On vehicles equipped with an antilock braking
system (ABS), a noise from the hydraulic pump
motor and pulsation in the pedal may be
observed during ABS braking events. Pedal
pulsation coupled with noise while braking
under panic conditions or on loose gravel, wet
or snowy roads is normal and indicated proper
functioning of the vehicle's antilock brake
system. If the vehicle has continuous vibration or
shudder while braking, mainly in the steering
wheel, the vehicle most likely needs service.
[GF01600(ALL)03/96]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
equipped with the Anti-lock Brake System if
normal radio installation practices are rigidly
followed. However, if after installing mobile
radio transmitting equipment, the Anti-lock
Brake System light comes on at any time other
than immediately after turning the key to the
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
Page 140 of 288
137
*
[GF02200(ALL)01/96]
RWARNING
To prevent personal injury, do not release
the parking brake while outside the
vehicle.
*
[GF02300(ALL)01/96]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
*
[GF02400(ALL)01/96]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[GF02500(ALL)02/96]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
*
[GF02600(ALL)03/96]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
%
*
[GF02800(ALL)01/96]
Steering Your Vehicle
[GF02900(ALL)01/96]
Your vehicle is equipped with power steering.
Power steering uses energy from the engine to
help steer your vehicle.
%*
[GF03000(ALL)03/96]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
Page 161 of 288
158
*
[ER00940(ALL)03/96]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ER00950(ALL)03/96]
1. Turn the key in the ignition to the LOCK
position.
*
[ER00960(ALL)03/96]
2. Check under the vehicle for leaking fuel.
*
[ER00970(ALL)03/96]
3. If you do not see or smell fuel, push the red
reset button on the fuel pump shut-off
switch down.
[ER00980(ALL)03/96]
The reset switch on your vehicle is located on
the left side of the luggage compartment
under the carpet. The red reset button is
under the raised area of the rubber cover.
*
[ER00990(ALL)03/96]
4. Attempt to start your vehicle. If the vehicle
starts, let it run a few seconds, then turn the
key to the LOCK position.
*
[ER00995(ALL)03/96]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
*
[ER02000(ALL)05/96]
Fuses
[ER02100(ALL)04/96]
If electrical parts in your vehicle are not
working, the system may have been overloaded
and blown a fuse. If a fuse blows, all the parts
of your vehicle that use the fuse will not work.
[ER02200(ALL)04/96]
Your vehicle has two fuse panels. The interior
fuse panel is below the instrument panel in front
of the driver's door. The main panel is under
the hood behind the battery.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
Page 179 of 288
176 %
*
[ER11800(ALL)02/96]
Preparing Your Vehicle
*
[ER11900(ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[ER12000(ALL)02/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[ER12100(ALL)02/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER12200(ALL)02/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
%*
[ER12400(ALL)02/96]
Connecting the jumper cables
*
[ER12500(ALL)02/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER12600(ALL)02/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[ER12700(ALL)02/96]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
