Page 61 of 288
58
*
[CF10200(ALL)01/96]
Interior Lights
%*
[CF10300(ALL)01/96]
Lighting Up the Interior and Instrument
Panel
*
[CF10400(ALL)01/96]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[CF10500(ALL)01/96]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[CF10600(ALL)01/96]
quarter page art:0030050-B
Dimmer control thumbwheel
[CF10700(ALL)01/96]
The dimmer control thumbwheel is located to
the left of the steering wheel on the instrument
panel.
[CF10800(ALL)01/96]
Dome Lamp
[CF10900(ALL)01/96]
The dome lamp illuminates whenever one of the
front doors is opened and turns off
automatically when the doors are closed. You
may turn the dome lamp on and off while the
doors are closed by using the ON/OFF switch
located on the interior/map lamp control panel.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 64 of 288
61
*
[CF15100(ALL)01/96]
Ignition
%*
[CF15200(ALL)01/96]
Understanding the Positions of the Ignition
[CF15300(ALL)01/96]
one third page art:0032054-A
Ignition lock cylinder
*
[CF15400(ALL)01/96]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[CF15500(ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
[CF15600(ALL)01/96]
To remove the key if you have a manual
transaxle, push the key in while turning it to the
LOCK position.
*
[CF15700(ALL)01/96]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[CF15800(ALL)01/96]
ACC (Accessory) allows some of your vehicle's
electrical accessories to operate while the engine
is not running.
*
[CF15900(ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 65 of 288
62
*
[CF16000(ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
%
*
[CF16010(ALL)02/96]
The Turn Signal Lever
*
[CF16020(ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF16030(ALL)02/96]
q
operate the headlamps and parking lamps
*
[CF16040(ALL)02/96]
q
operate the turn signals and cornering lamps
*
[CF16050(ALL)03/96]
q
turn the high beams on/off
*
[CF16060(ALL)03/96]
q
flash the lamps
*
[CF16070(ALL)02/96]
Headlamps and Parking Lamps
*
[CF16080(ALL)02/96]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[CF16100(ALL)01/96]
FIRST STOP Ð Turning the knob to the first
stop (g) will turn on the the license plate
lamps, parking lamps, side marker lamps, tail
lamps and instrument panel lamps.
[CF16200(ALL)03/96]
SECOND STOP Ð Turning the knob to the
second stop (B) will turn on the headlamps,
license plate lamps, parking lamps, side marker
lamps, tail lamps, and instrument panel lamps.
[CF16300(ALL)01/96]
quarter page art:0032032-A
Headlamp control
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 71 of 288
68
%*
[CF19100(ALL)01/96]
Windshield Wipers and Washer
*
[CF19200(ALL)01/96]
To operate the windshield wipers and washers,
make sure your ignition key is turned to the ON
position.
[CF19300(ALL)01/96]
The windshield wipers have two speeds. To
operate the wipers, pull down the lever on the
right side of your steering column. The first
position is LO (Low) and the second position is
HI (High). To turn the wipers off, return the
lever to the uppermost position.
[CF19400(ALL)01/96]
quarter page art:0032071-C
Windshield wiper control
[CF19500(ALL)01/96]
ONE-TOUCH WIPER CONTROL (If equipped)
Ð For one wiping cycle, push the lever away
from you and release it with the lever in the
OFF or interval position. The ignition switch
must be in the ON position for this operation.
[CF19600(ALL)01/96]
quarter page art:0032058-B
One touch wiper control
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 75 of 288
72
%*
[CF21300(ALL)03/96]
Speed Control (If equipped)
[CF21600(ALL)01/96]
half page art:0032031-C
Speed control switches on the steering wheel
%*
[CF21610(ALL)05/96]
To Turn Speed Control Off
[CF21612(ALL)05/96]
Press OFF, or
[CF21614(ALL)05/96]
Turn off the vehicle ignition.
*
[CF21616(ALL)05/96]
Once speed control is switched off, the
previously programmed set speed will be erased.
*
[CF21620(ALL)05/96]
To Turn Speed Control On
[CF21640(ALL)05/96]
Press ON
*
[CF21740(ALL)05/96]
To Set a Speed
[CF21760(ALL)05/96]
Press SET ACC. For speed control to operate,
the speed control must be ON and the vehicle
speed must be greater than 30 mph (48 km/h).
*
[CF21780(ALL)05/96]
If you drive up or down a steep hill, your
vehicle speed may vary slower or faster than the
set speed. This is normal.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 108 of 288
105
*
[SS11200(ALL)05/96]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, failure to do so may increase the
risk of personal injury in the event of a
collision.
*
[SS11250(ALL)05/96]
RWARNING
Do not place objects or mount equipment
on or near the air bag covers that may
come into contact with an inflating air
bag. Failure to follow these instructions
may increase the risk of personal injury in
the event of a collision.
*
[SS11300(ALL)05/96]
RWARNING
Do not attempt to service, repair, or
modify the air bag Supplemental Restraint
System or its fuses. See your Ford or
Lincoln-Mercury dealer.
*
[SS11350(ALL)05/96]
RWARNING
If you are close to an inflating air bag, it
could seriously injure you. Position your
seat such that it is as far back from the
steering wheel as possible but still allows
you to properly control the vehicle.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996
Page 129 of 288
126
*
[TO05500(ALL)01/96]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
*
[TO05600(ALL)01/96]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
%*
[TO05700(ALL)01/96]
Testing the Warning Lights
*
[TO05800(ALL)02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
%*
[TO06000(ALL)01/96]
Starting Your Engine
*
[TO06100(ALL)01/96]
To start your engine:
*
[TO06300(ALL)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO06320(ALL)01/96]
2. Keep your foot on the brake pedal and turn
the ignition key to the ON position.
*
[TO06330(ALL)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO06340(ALL)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO06400(ALL)05/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996
Page 136 of 288
133
Driving
%*
[GF00300(ALL)05/96]
Brakes
%*
[GF00400(ALL)01/96]
Applying the Brakes
[GF00500(ALL)04/96]
Your vehicle may have four-wheel power
anti-lock disc brakes which adjust automatically
through everyday use.
[GF00600(ALL)04/96]
Some models have power front disc brakes and
rear drum brakes which automatically adjust as
the brake pads and linings wear down.
*
[GF00700(ALL)01/96]
If your vehicle does not have anti-lock brakes,
apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[GF00800(ALL)01/96]
If your vehicle does not have anti-lock brakes,
extreme braking can make the wheels lock and
slide, causing you to lose control of the steering.
If the wheels lock, release the brake pedal and
repeat the ªsqueezeº technique.
*
[GF00900(ALL)01/96]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[GF00950(ALL)02/96]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
Page 138 of 288
135
engine and restart. If it remains illuminated, it
means the ABS is disabled and should be
serviced immediately to restore the benefits of
the anti-lock feature. Normal braking is not
affected unless the red BRAKE system warning
light is also illuminated.
[GF01500(ALL)04/96]
ABS has self-check capabilities. As described
above, the system turns on the ABS light each
time you start your engine. After the engine is
started and the ABS light turns off, the system
performs another test the first time the vehicle
reaches 4-9 mph (6-15 km/h). The system turns
on the ABS pump motor for approximately 1/2
second. At this time, a mechanical noise may be
heard. This is a normal part of the self-check
feature. If a malfunction is found during this
check the ABS light will come on.
[GF01510(ALL)12/96]
On vehicles equipped with an antilock braking
system (ABS), a noise from the hydraulic pump
motor and pulsation in the pedal may be
observed during ABS braking events. Pedal
pulsation coupled with noise while braking
under panic conditions or on loose gravel, wet
or snowy roads is normal and indicated proper
functioning of the vehicle's antilock brake
system. If the vehicle has continuous vibration or
shudder while braking, mainly in the steering
wheel, the vehicle most likely needs service.
[GF01600(ALL)03/96]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
equipped with the Anti-lock Brake System if
normal radio installation practices are rigidly
followed. However, if after installing mobile
radio transmitting equipment, the Anti-lock
Brake System light comes on at any time other
than immediately after turning the key to the
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
Page 140 of 288
137
*
[GF02200(ALL)01/96]
RWARNING
To prevent personal injury, do not release
the parking brake while outside the
vehicle.
*
[GF02300(ALL)01/96]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
*
[GF02400(ALL)01/96]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[GF02500(ALL)02/96]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
*
[GF02600(ALL)03/96]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
%
*
[GF02800(ALL)01/96]
Steering Your Vehicle
[GF02900(ALL)01/96]
Your vehicle is equipped with power steering.
Power steering uses energy from the engine to
help steer your vehicle.
%*
[GF03000(ALL)03/96]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
