Tire rotation pattern
*
[SV26900(ALL)10/89]
After each rotation, adjust individual tire pressure as specified
on the Safety Compliance Certification Label. Tighten wheel lug
nuts to the required torque specification and retighten again
after 500 miles (800 km).
*
[SV27000(ALL)08/95]
If your vehicle has aluminum wheels, you may demount the full
size, non-temporary spare tire (if so equipped) and remount on
an aluminum wheel to rotate the spare tire into your vehicle's
rotation pattern. Rebalance the wheel.
