wheel FORD RANGER 1996 2.G Owners Manual

4
%*
[IN04000(ALL)01/95]
Buying a Ford Extended Service Plan
*
[IN04100(ALL)01/94]
If you bought your vehicle in the U.S., you can buy a Ford
Extended Service Plan for your vehicle. This optional contract
provides service protection for a longer period of time than the
basic warranty that comes with your vehicle.
*
[IN04200(ALL)01/95]
You do not have to buy this option when you buy your vehicle.
However, your option to purchase the Ford Extended Service
Plan runs out after 18 months or 18,000 miles. See your dealer
for more details about the Ford Extended Service Plan.
*
[IN04250(ALL)01/95]
If you purchased a Canadian vehicle and did not take
advantage of the Ford Extended Service Plan at the time of
purchase, you may still be eligible. See your dealer for the
details.
%*
[IN04650(ALL)06/92]
Special Notice
%*
[IN04750(R )11/89]
NOTICE TO OWNERS OF FOUR-WHEEL
DRIVE VEHICLES
%*
[IN04800(R )11/89]
As with other vehicles of this type, failure to operate this
vehicle correctly may result in loss of control or an accident. Be
sure to read theAdditional Special Driving Instructions for
Four-Wheel Drive Vehicle Operators, in this book and the special
supplement included with four-wheel drive vehicles entitled
4-Wheeling with Ford.
File:02uninr.ex
Update:Wed May 1 13:42:39 1996

Introductory Information
5
%*
[IN06000(ALL)01/95]
Breaking Your Vehicle In
*
[IN06100(ALL)03/95]
Your new vehicle goes through an adjustment or break-in
period during the first 1,000 miles (1,600 km) that you drive it.
During the break-in period, you need to pay careful attention to
how you drive your vehicle.
%*
[IN06300(ALL)01/95]
n
Avoid sudden stops.Because your vehicle has new brake
linings, you should take these steps:
*
[IN06400(ALL)01/95]
Ð Watch traffic carefully so that you can anticipate when to
stop.
*
[IN06500(ALL)01/95]
Ð Begin braking well in advance.
*
[IN06600(ALL)01/95]
Ð Apply the brakes gradually.
*
[IN06700(ALL)01/95]
The break-in period for new brake linings lasts for 100 miles
(160 km) of city driving or 1,000 miles (1,600 km) of
highway driving.
*
[IN06750(ALL)12/93]
n
Wheel lug nuts must be retightened to proper torque
specifications at 500 miles/800 km of new vehicle operation.
Proper torque specifications are provided in this guide. Also
retighten to proper torque specification at 500 miles/800 km
after any wheel change or any other time the wheel lug nuts
have been loosened.
%*
[IN06800(ALL)01/95]
n
Use only the type of engine oil that Ford recommends.See
Engine oil recommendationsin the Index. Do not use special
ªbreak-inº oils.
*
[IN07000(ALL)03/95]
Some vehicles are equipped with a Powertrain Control Module
that limits engine speeds with a cut-out mode to promote
durability.
File:02uninr.ex
Update:Wed May 1 13:42:39 1996

Safety Restraints
31
[SR12900(ALL)06/95]
The driver air bag is in the center of the steering wheel. The
right front passenger seat air bag (if equipped) is in the upper
right hand section of the instrument panel ledge above the
glove compartment.
*
[SR13010(ALL)07/95]
If a collision occurs, the sensors sense the severity of the impact
and activate the air bags if necessary. The air bag system is
designed to deploy in frontal and front-angled collisions more
severe than hitting a parked vehicle (of similar size and weight)
head-on at about 28 mph (45 km/h). Because the system senses
the crash severity rather than vehicle speed, some frontal
collisions at speeds above 28 mph (45 km/h) will not inflate the
air bag.
*
[SR13020(ALL)07/95]
When the sensors activate the system, the air bags inflate
rapidly, filling with non-toxic nitrogen gas in a fraction of a
second. Immediately after inflation, the air bags deflate by
releasing the nitrogen gas through vent holes. The whole
process takes place in a matter of seconds.
*
[SR13030(ALL)07/95]
RWARNING
Air bag system components get hot after inflation. Do
not touch them after inflation.
%*
[SR13050(ALL)05/95]
The air bag system uses a readiness light on the instrument
cluster and a tone to indicate the condition of the system. When
you turn the ignition key to the ON position, this light will
illuminate for approximately six (6) seconds and then turn off.
This indicates that the system is operating normally. NOTE:
Maintenance of the air bag system is not required.
File:03unsrr.ex
Update:Wed May 1 13:43:56 1996

41
Starting Your Ranger
*
[ST01700(ALL)03/95]
Ignition
%*
[ST01800(ALL)01/95]
Understanding the Positions of the Ignition
[ST02000(ALL)04/94]
7-1/2 pica art:0021143-A
The positions of the key in the ignition lock cylinder.
%*
[ST02201(ALL)07/95]
ACCESSORY allows some of your vehicle's electrical accessories
such as the radio and the windshield wipers to operate while
the engine is not running.
*
[ST02301(ALL)01/95]
In order to turn the key from the ON or OFF position to the
ACCESSORY position, you must push the key release button if
your vehicle's manual transmission gearshift is mounted on the
floor.
*
[ST02401(ALL)08/95]
LOCK locks the steering wheel and gearshift lever.
*
[ST02501(ALL)10/95]
RWARNING
LOCK does not lock the gearshift on console or
floor-mounted manual transaxle gearshifts. If the parking
brake is not set and the gearshift is moved out of gear,
your vehicle may move unexpectedly and injure someone.
[ST02600(R )06/95]
A neutral tow feature is available on your vehicle. See your
dealer for more information.
File:04unstr.ex
Update:Wed May 1 13:44:22 1996

42
*
[ST02601(R )05/95]
RWARNING
Do not leave the vehicle unattended with the transfer
case in the N (Neutral) position. Always set the parking
brake fully and turn off the ignition when leaving the
vehicle.
*
[ST02651(ALL)01/95]
LOCK is the only position that allows you to remove the key.
The LOCK feature helps to protect your vehicle from theft.
*
[ST02701(ALL)05/95]
If your key is stuck in the LOCK position and will not turn,
move your steering wheel left or right until the key turns freely.
*
[ST02801(ALL)03/95]
OFF allows you to shut off the engine and all accessories
without locking the steering wheel or the automatic
transmission gearshift lever.
*
[ST02901(ALL)05/95]
ON allows you to test your vehicle's warning lights (except the
brake system warning light) to make sure they work before you
start the engine. The key returns to the ON position once the
engine is started and remains in this position while the engine
runs.
*
[ST02951(ALL)03/95]
START cranks the engine. Release the key once the engine starts
so that you do not damage the starter. The key should return to
ON when you release it. The START position also allows you to
test the brake warning light.
%*
[ST03025(ALL)08/95]
Ignition Key Buzzer or Chime
*
[ST03050(ALL)08/95]
The buzzer or chime will sound if you open the driver's door
while the key is in the ignition. Never leave your vehicle
unattended with the key in the ignition.
File:04unstr.ex
Update:Wed May 1 13:44:22 1996

Starting Your Ranger
45
*
[ST05400(ALL)01/95]
Before you start your vehicle, do the following:
*
[ST05500(ALL)08/95]1.
Make sure all occupants in the vehicle buckle their safety
belts. SeeSafety Restraintsin the Index for more details.
*
[ST05600(ALL)03/95]2.
Make sure the headlamps and other accessories are turned
off when starting.
*
[ST05700(ALL)10/94]3.
If you have an automatic transmission,make sure that the
gearshift lever is in P (Park) and the parking brake is set
before you turn the key.
*
[ST05800(ALL)03/91]4.
If you have a manual transmission,make sure that the
parking brake is fully set, push the clutch pedal to the floor,
and put the gearshift into Neutral before you turn the key.
(Remember, the starter will operate only if the clutch pedal
is pushed in all the way).
*
[ST06000(ALL)03/95]
Before you start your vehicle, you should test the warning lights
on the instrument panel to make sure that they work. Refer to
theWarning Lights and Gaugeschapter.
%*
[ST06200(ALL)02/95]
Starting Your Engine
*
[ST06300(ALL)06/95]
To start your engine:
*
[ST06400(ALL)05/95]1.
Follow the steps underPreparing to Start Your Vehicleat the
beginning of this section.
*
[ST06425(ALL)03/95]2.
Turn the ignition key to the ON position.
*
[ST06451(ALL)06/95]3.
DO NOT depress the accelerator pedal when starting your
engine. DO NOT use the accelerator while the vehicle is
parked.
*
[ST06475(ALL)02/95]4.
Turn the key to the START position (cranking) until the
engine starts. Allow the key to return to the ON position
after the engine has started.
*
[ST06501(ALL)02/95]
If you have difficulty in turning the key, rotate the steering
wheel slightly because it may be binding.
File:04unstr.ex
Update:Wed May 1 13:44:22 1996

Instrument Panel Controls
81
[IP17250(ALL)09/95]3.
Rotate the thumb wheel when the headlamp control knob is
in an ªONº position to brighten or dim the instrument panel
lamps. Rotate fully upward to operate courtesy and cargo
lamps.
[IP17260(ALL)09/95]
17-1/2 pica
art:0090190-A
Headlamp control knob
%*
[IP17715(ALL)04/95]
Fog Lamps (If equipped)
[IP17725(ALL)03/95]
The fog lamps switch is located on the instrument panel to the
right of the radio and climate control.
[IP17730(ALL)05/95]
n
To turn the fog lamps on, turn on the low-beam headlamps,
then push the fog lamp switch. An indicator light will glow
when the lamps are on.
*
[IP17735(ALL)10/94]
n
To turn off, push the switch again.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

Instrument Panel Controls
83
*
[IP17890(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system will not
illuminate the tail lamps and parking lamps. Turn on
your headlamps at dusk. Failure to do so may result in a
collision.
%*
[IP17900(ALL)03/95]
Lighting Up the Instrument Panel and the Interior of
Your Vehicle
[IP18000(ALL)10/94]
The instrument panel lights can be turned on by turning the
headlamp knob toward either the first or second position. You
can brighten or dim the instrument panel lights by rotating the
thumb wheel.
[IP18200(ALL)03/95]
The interior lights will shut off after 25 seconds with all the
doors closed, or immediately when the ignition switch is turned
to the ON position, or if the vehicle speed is above five MPH
(8 km/h). The interior lights will turn off after 40 minutes if
any of the doors are left open. Refer toBattery Saverin the
Featuressection for more details.
[IP18500(R )11/89]
Courtesy and Dome Lamps
[IP19175(R )04/94]
The interior/courtesy lamp is automatically turned on when the
driver or passenger door is opened. Turning the thumb wheel
fully counterclockwise will operate the interior lamp when the
doors are closed.
[IP19185(R )08/94]
7-1/2 pica art:0021156-B
Interior/Courtesy lamp
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

84
%*
[IP19187(ALL)04/95]
Cleaning the Interior Lamps
*
[IP19188(ALL)04/95]
Your interior dome lamps and map lamps are plastic and
should be cleaned with a mild detergent diluted in water. Rinse
them with clear water.
%*
[IP19190(R )08/94]
Combination Cargo and High-Mount Brakelamp
[IP19200(R )08/94]
The combination cargo/high-mount brakelamp is located outside
the vehicle, directly over the rear window. Use the thumb wheel
to turn on the cargo lamp and interior courtesy lights.
[IP19350(R )08/94]
7-1/2 pica art:0021157-B
Cargo/High-mount brakelamp
*
[IP19400(R )05/91]
RWARNING
Do not drive your vehicle with the cargo/courtesy light
on. Showing a white light to the rear while driving on
public roads is illegal in some places.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

87
Steering Column Controls
*
[SC00400(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
%*
[SC00500(ALL)01/95]
The Turn Signal Lever
*
[SC00600(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC00700(ALL)03/95]
n
operate the turn signals and cornering lamps
*
[SC00800(ALL)01/95]
n
turn the high beams on/off
*
[SC00900(ALL)05/95]
n
flash the lamps
*
[SC01000(ALL)01/95]
n
turn the windshield wipers and washer on/off
%*
[SC01100(ALL)01/95]
Turn Signals
[SC01600(ALL)07/95]
7-1/2 pica art:0090131-B
Turn signal lever and functions
*
[SC01800(ALL)11/89]
If the turn indicator light in the instrument panel does not
illuminate or remains on (doesn't flash) when you signal a turn,
the turn signaling system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that you use the
accepted hand signals in the meantime.
File:07unscr.ex
Update:Wed May 1 13:46:58 1996
