Instrumentation
15
%*
[IS05900(R)01/96]
Charging System Light
*
[IS06000(R)04/96]
This light indicates that your battery is not being charged and
that you need to have the electrical system checked.
[IS06100(R)01/96]
6 pica art:0021150-B
Charging system light symbol
*
[IS06200(R)03/96]
This light illuminates every time you turn the ignition to the
ON or START position (engine off). The light should go off
when the engine starts and the alternator begins to charge.
*
[IS06300(R)03/96]
If the light stays on or illuminates when the engine is running,
have the electrical system checked as soon as possible.
[IS06700(R)01/96]
Check Gage Light (If equipped)
[IS06800(R)04/96]
This light will come on when the key is in the ON position and
the:
[IS06900(R)01/96]
n
engine coolant temperature is high
[IS07000(R)01/96]
n
engine oil pressure is low
[IS07100(R)01/96]
n
fuel level is near empty
[IS07200(R)01/96]
This light serves as a notice that a system needs your attention
and to check the engine coolant temperature gauge, the engine
oil pressure gauge, and the fuel level gauge.
File:03unisr.ex
Update:Thu Mar 20 09:21:14 1997
Page 19 of 361
16
[IS07300(R)01/96]
Please seeEngine Coolant Temperature Gauge,Engine Oil Pressure
Gauge,orFuel Gaugein this chapter for more information.
[IS07400(R)01/96]
6 pica art:0021250-B
Check gage light
[IS07500(R)01/96]
Fuel Reset Light (If Equipped)
[IS07600(R)01/96]
Your vehicle may have a fuel reset light. The fuel reset light
will come on when you turn the ignition key to ON and the
fuel pump shut-off switch has been triggered. Refer toFuel
pump shut-off switchin the Index to find additional information.
[IS07700(R)01/96]
6 pica art:0021372-A
Fuel reset light
[IS07710(R)05/96]
Speed Control Light (If equipped)
[IS07720(R)05/96]
The SPEED CONT light will illuminate in the instrument cluster
when the speed control system is engaged. The light will turn
off when the brake pedal is pressed or if the speed control is
shut off.
[IS07730(R)05/96]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when speed
control is activated.
File:03unisr.ex
Update:Thu Mar 20 09:21:14 1997
Page 25 of 361
22
%*
[IS09600(R)05/96]
Fuel Gauge
*
[IS09700(R)01/96]
The fuel gauge displays approximately how much fuel is in the
fuel tank only when the ignition switch is ON.
*
[IS09850(R)01/96]
For a proper fuel gauge indication after adding fuel, the ignition
switch should be in the OFF position while the vehicle is being
refueled.
*
[IS09860(R)01/96]
The fuel gauge indicator may vary slightly when the vehicle is
in motion.
*
[IS09875(R)01/96]
With ignition switch OFF, the fuel gauge indicator may drift
from the ignition switch ON position.
[IS10200(R)01/96]
6 pica art:0020063-D
Fuel gauge Ð mechanical cluster
[IS10300(R)01/96]
6 pica art:0020752-E
Fuel gauge Ð mechanical cluster with tachometer
%*
[IS11100(R)03/96]
Engine Coolant Temperature Gauge
*
[IS11201(R)01/96]
This gauge tells you the temperature of the engine coolant, not
the coolant level. If the coolant is not at its proper level or
mixture, the gauge indicator will not be accurate.
File:03unisr.ex
Update:Thu Mar 20 09:21:14 1997
Page 26 of 361
Instrumentation
23
*
[IS11301(R)01/96]
The pointer moves from the C (cold) mark into the Normal
band as the engine coolant warms up. It is acceptable for the
pointer to fluctuate within the Normal band under normal
driving conditions. Under certain driving conditions, such as
heavy stop and go traffic or driving up hills in hot weather, the
pointer may move to the top of the Normal band.
*
[IS11401(R)04/96]
If, under any circumstances, the pointer moves above the
normal band, the engine is overheating and continued operation
may cause engine damage.
*
[IS11501(R)03/96]
If your engine overheats:
*
[IS11601(R)03/96]1.
Pull off the road as soon as it is safely possible.
*
[IS11701(R)03/96]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[IS11801(R)03/96]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
*
[IS11901(R)01/96]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine. Refer toEngine
coolantin the Index. If you do not follow these instructions,
you or others could be injured.
*
[IS12240(R)01/96]
If the coolant continues to overheat, have the coolant system
serviced as soon as possible.
[IS12300(R)01/96]
7-1/2 pica art:0020067-F
Engine coolant temperature gauge Ð mechanical cluster
File:03unisr.ex
Update:Thu Mar 20 09:21:14 1997
Page 27 of 361
24
[IS12325(R)01/96]
7-1/2 pica art:0021154-C
Engine coolant temperature gauge Ð mechanical cluster with tachometer
%*
[IS12601(R)03/96]
Speedometer
*
[IS12700(R)03/96]
The speedometer tells you how many miles (kilometers) per
hour your vehicle is moving.
*
[IS12753(R)03/96]
Some vehicles are equipped with a vehicle speed (mph/km/h)
limiting device that is contained within the Powertrain Control
Module (PCM). The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle speed limits may
vary based on engine displacement.)
*
[IS12756(R)03/96]
If you are experiencing an ªengine cut-outº condition at high
speeds, it may be the result of this limiting device. It is a
normal condition and can be avoided by reducing
vehicle/engine speed.
[IS12790(R)01/96]
10-1/2 pica
art:0020873-G
Speedometer
File:03unisr.ex
Update:Thu Mar 20 09:21:14 1997
Page 267 of 361
Maintenance and Care
267
*
[MC20325(R)05/96]
Recycled engine coolant
*
[MC20350(R)05/96]
Ford Motor Company recommends that Ford and
Lincoln-Mercury dealers use recycled engine coolant produced
by Ford-approved processes. Not all coolant recycling processes
produce coolant which meets Ford specification ESE-M97B44-A,
and use of such coolant may harm engine and cooling system
components.
*
[MC20375(R)05/96]
Always dispose of used automotive fluids in a responsible
manner. Follow your community's regulations and standards for
recycling and disposing of automotive fluids.
*
[MC20400(R)05/96]
Coolant refill capacity
*
[MC20425(R)05/96]
To find out how much fluid your vehicle's cooling system can
hold, refer to theCapacities and Specificationschapter.
*
[MC20450(R)05/96]
Have your dealer check the engine cooling system for leaks if
you have to add more than a quart (liter) of engine coolant per
month.
*
[MC20475(R)05/96]
Severe winter climate
*
[MC20490(R)05/96]
If you drive in extremely cold climates (less than-34ÊF [-36ÊC]),
it may be necessary to increase the coolant concentration above
50%. Refer to the chart on the coolant container to ensure the
coolant concentration in your vehicle is such that the coolant
will not freeze at the temperature level in which you drive
during winter months. Never increase the engine coolant
concentration above 60%. Leave a 50/50 mixture of engine
coolant and water in your vehicle year-round in non-extreme
climates.
%*
[MC20500(R)01/96]
Checking Hoses
*
[MC20600(R)01/96]
Inspect all engine and heater system hoses for deterioration,
leaks and loose clamps before adding or replacing engine
coolant. Make whatever repairs or replacements that are
necessary using Motorcraft parts or their equivalents.
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997
Page 268 of 361
268
%*
[MC22800(R)01/96]
Power Steering Fluid
*
[MC22810(R)01/96]
Check the level of the power steering fluid at least twice a
year (i.e., every Spring and Fall).
%*
[MC22900(R)01/96]
Checking and Adding Power Steering Fluid
*
[MC22910(R)04/96]1.
Start the engine and let it run until the power steering fluid
reaches normal operating temperature. The power steering
fluid will be at the right temperature when the engine
coolant temperature gauge in the instrument cluster is near
the center of the normal operating temperature range.
*
[MC22912(R)01/96]2.
While the engine idles, turn the steering wheel back and
forth several times. Make sure that the cap assembly is
installed at this time.
*
[MC22914(R)01/96]3.
Turn the engine off.
%*
[MC22916(R)01/96]4.
Check the fluid level on the dipstick (which is highlighted in
yellow in your vehicle). The fluid level should be between
the arrows in the FULL HOT range, which is marked on the
side of the dipstick, opposite the side marked FULL COLD.
Do not add fluid if the level is within the FULL HOT range.
[MC22918(R)01/96]
10-1/2 pica
art:0021195-A
Power steering dipstick
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997
Page 340 of 361
Index
343
A
Accessory position on the ignition............. 73
Additives, engine oil.................. 257
Air bag supplemental restraint system
and child safety seats................ 133
description...................122, 127
disposal...................... 131
driver air bag..................122, 127
indicator light..................... 12
operation...................... 127
passenger air bag.................. 127
proper seating................... 123
service and information labels............ 127
tone generator.................129, 131
wearing safety belts................. 123
Air cleaner filter
location...................... 253
specifications.................... 311
Alarm, activating remote personal............. 94
Ambulance packages................... 5
Antenna, radio (see Electronic sound system)...... 27,55
Antifreeze (see Engine coolant)............. 265
Anti-lock brake system (ABS)
description..................... 155
noise........................ 157
see also Brake.................... 155
warninig light..................... 10
Anti-theft system
arming the system................... 98
description...................... 98
disarming an untriggered system............ 99
disarming a triggered system.............. 99
triggering....................... 98
Appeals (see Dispute settlement board)......... 320
Assistance (see Customer assistance)........... 317
File:unixr.ex
Update:Thu Mar 20 09:01:44 1997
Page 344 of 361
347
Index
Climate control system.................. 64
Clock........................ 34,55
Clutch
fluid........................ 263
fluid reservoir.................261, 263
operation while driving............... 170
recommended shift speeds.............. 173
shifting the gears.................. 171
specifications.................... 313
Cold engine starting.................. 148
Combination lap and shoulder belts.........110, 112
Controls
mirrors........................ 86
power seat..................... 109
Convenience kit in cargo area.............. 229
Coolant (see Engine coolant)
checking and adding................ 265
preparing for storage................ 309
specifications.................... 313
temperature gauge.................. 22
warnings...................... 265
Cooling fan...................... 250
Crankcase emission filter................ 311
Customer Assistance Centre, Ford of Canada....... 324
D
Daytime running light system.............. 63
Defects, reporting................... 315
Defrost, windshield................. 67,70
Dipstick
automatic transmission fluid...........271, 273
engine oil..................... 258
power steering fluid................. 268
Disabled vehicle (see Towing).............. 242
File:unixr.ex
Update:Thu Mar 20 09:01:44 1997
Page 346 of 361
349
Index
Engine block heater.................. 150
Engine coolant
checking and adding................ 265
checking hoses................... 267
disposal..................250, 261, 273
preparing for storage................ 309
proper solution...............250, 261, 273
recovery reservoir.................. 253
specifications.................... 313
temperature gauge.................. 22
Engine coolant temperature gauge
description...................... 22
mechanical...................... 22
Engine coolant temperature guage:electronic........ 22
Engine fan...................... 250
Engine:idle speed control................ 149
Engine oil
changing oil and oil filter............258, 260
checking and adding................ 258
dipstick...................... 258
disposal..................250, 261, 273
engine oil pressure gauge............... 20
filter, specifications................. 311
specifications..................257, 313
synthetic oil.................... 257
ªbreak-inº oils.................... 5
viscosity...................... 257
Entry system
illuminated...................... 97
remote........................ 93
Exhaust fumes..................... 152
Extended Service Plan, Ford............... 4
File:unixr.ex
Update:Thu Mar 20 09:01:44 1997
