warning light FORD RANGER 1998 2.G Owners Manual

Fuel reset (if equipped)
Illuminates when the ignition key is
turned to the ON position and the
fuel pump shut-off switch has been
triggered. For more information,
refer toFuel pump shut-off switch
in theRoadside emergencieschapter.
Air bag readiness
Momentarily illuminates when the
ignition is turned ON. If the light
fails to illuminate, continues to flash
or remains on, have the system
serviced immediately.
Safety belt
Momentarily illuminates when the
ignition is turned to the ON position
to remind you to fasten your safety
belts. For more information, refer to
theSeating and safety restraints
chapter.
Brake system warning
Momentarily illuminates when the
ignition is turned to the ON position
and the engine is off. Also
illuminates when the parking brake
is engaged. Illumination after
releasing the parking brake indicates low brake fluid level.
Anti-lock brake system (ABS)
Momentarily illuminates when the
ignition is turned to the ON position
and the engine is off. If the light
remains on, continues to flash or
fails to illuminate, have the system
serviced immediately.
FUEL
RESET
!
BRAKE
ABS
Instrumentation
8

Adjusting the rear center facing jump seat lap belt (if equipped)
The lap belts for rear center facing jump seat occupants have automatic
retractors for the belt tongue and a fixed position buckle.
To fasten the belt, pull the belt all
the way across your hips and insert
the tongue into the buckle on your
rear door until you hear a snap and
feel it latch. Make sure the buckle is
securely fastened by pulling on the tongue.
²Position the belt so that it fits snugly and as low as possible around
the hips.
²If you need to lengthen the belt, unfasten it and repeat the procedure
above.
To unfasten the belt, push in the release button prior to opening the rear
door.
Safety belt extension assembly
If the safety belt assembly is too short, even when fully extended, 20 cm
(8 inches) can be added to the safety belt assembly by adding a safety
belt extension assembly (part number 611C22). Safety belt extension
assemblies can be obtained from your dealer at no cost.
Use only extensions manufactured by the same supplier as the safety
belt. Manufacturer identification is located at the end of the webbing on
the label. Also, use the safety belt extension only if the safety belt is too
short for you when fully extended. Do not use extensions to change the
fit of the shoulder belt across the torso.
Safety belt warning light and indicator chime
The seat belt warning light illuminates in the instrument cluster and a
chime sounds to remind the occupants to fasten their safety belts.
Seating and safety restraints
45

Conditions of operation
If... Then...
The driver's safety belt is not
buckled before the ignition switch
is turned to the ON position...The safety belt warning light
illuminates for one to two minutes
and the warning chime sounds for
four to eight seconds.
The driver's safety belt is buckled
while the indicator light is
illuminated and the warning chime
is sounding...The safety belt warning light and
warning chime turn off.
The driver's safety belt is buckled
before the ignition switch is turned
to the ON position...The safety belt warning light and
indicator chime remain off.
Safety belt maintenance
Check the safety belt systems periodically to make sure they work
properly and are not damaged. Check the safety belts to make sure there
are no nicks, wears or cuts. All safety belt assemblies, including
retractors, buckles, front seat belt buckle assemblies (slide bar)
(if equipped), shoulder belt height adjusters (if equipped), child safety
seat tether bracket assemblies (if equipped), and attaching hardware,
should be inspected after a collision. Ford recommends that all safety
belt assemblies used in vehicles involved in a collision be replaced.
However, if the collision was minor and a qualified technician finds that
the belts do not show damage and continue to operate properly, they do
not need to be replaced. Safety belt assemblies not in use during a
collision should also be inspected and replaced if either damage or
improper operation is noted.
Failure to replace the safety belt assembly under the above
conditions could result in severe personal injuries in the event of
a collision.
Refer toCleaning and maintaining the safety beltsin the
Maintenance and caresection.
Seating and safety restraints
46

The SRS consists of:
²driver and passenger air bag modules
(which include the inflators and air bags)
²one or more impact and safing sensors, passenger air bag deactivation
switch and diagnostic monitor (RCM)
²a readiness light and tone
²and the electrical wiring which connects the components.
The RCM (restraints control module) monitors its own internal circuits
and the supplemental air bag electrical system warning (including the
passenger air bag deactivation switch, the impact sensors, the system
wiring, the air bag system readiness light, the air bag back up power and
the air bag ignitors).
Determining if the system is operational
The SRS uses readiness lights in the instrument cluster and the
passenger air bag deactivate switch or a tone to indicate the condition of
the system. Refer to theAir bag readinesssection in the
Instrumentationchapter orPassenger air bag deactivate switch
section in this chapter. Routine maintenance of the air bag is not
required.
A difficulty with the system is indicated by one or more of the following:
²The readiness lights will either
flash or stay lit.
²The readiness lights will not
illuminate immediately after
ignition is turned on.
²A series of five beeps will be heard. The tone pattern will repeat
periodically until the problem and light are repaired.
If any of these things happen, even intermittently, have the SRS serviced
at your dealership or by a qualified technician immediately. Unless
serviced, the system may not function properly in the event of a
collision.
Disposal of air bags and air bag equipped vehicles
For disposal of air bags or air bag equipped vehicles, see your local
dealership or qualified technician. Air bags MUST BE disposed of by
qualified personnel.
Seating and safety restraints
50

ABS warning lamp
The
ABSwarning lamp in the instrument cluster illuminates for about
five seconds when starting the vehicle. If an ABS fault is detected, the
light will remain on and your vehicle should be serviced as soon as
possible.
Normal braking is still effective
unless the BRAKE warning lamp is
also illuminated.
Using ABS
²In an emergency or when maximum efficiency from the ABS is
required, apply continuous full force on the brake. The ABS will be
activated immediately, thus allowing you to retain full steering control
of your vehicle and, providing there is sufficient space, will enable you
to avoid obstacles and bring the vehicle to a controlled stop.
²We recommend that you familiarize yourself with this braking
technique. However, avoid taking any unnecessary risks.
Parking brake
Apply the parking brake whenever
the vehicle is parked. To set the
parking brake, press the parking
brake pedal down until the pedal
stops.
The BRAKE warning lamp in the
instrument cluster illuminates and
remains illuminated (when the
ignition is turned ON) until the
parking brake is released.
!
BRAKE
!
BRAKE
Driving
66

EMISSION CONTROL SYSTEM
Your vehicle is equipped with various emission control components and a
catalytic converter which will enable your vehicle to comply with
applicable exhaust emission standards. To make sure that the catalytic
converter and other emission control components continue to work
properly:
²Use only unleaded fuel.
²Avoid running out of fuel.
²Do not turn off the ignition while your vehicle is moving, especially at
high speeds.
²Have the services listed in your ªService Guideº performed according
to the specified schedule.
The Scheduled Maintenance Services listed in the ªService Guideº are
required because they are considered essential to the life and
performance of your vehicle and to its emissions system.
If other than Ford, Motorcraft or Ford authorized parts are used for
maintenance replacements or for service of components affecting
emission control such non-Ford parts should be equivalent to genuine
Ford Motor Company parts in performance and durability.
Do not park, idle, or drive your vehicle in dry grass or other dry
ground cover. The emission system heats up the engine
compartment and exhaust system, which can start a fire.
Watch for fluid leaks, strange odors, smoke, loss of oil pressure, the
charging system warning light, the ªCheck Engineº light or the
temperature warning light. These events could indicate that the emission
control system is not working properly.
If you smell exhaust fumes of any kind inside your vehicle, have
the dealer inspect and fix your vehicle immediately. Do not drive
if you smell exhaust fumes. These fumes are harmful and could kill
you.
Maintenance and care
138

Do not make any unauthorized changes to your vehicle or engine. By
law, vehicle owners and anyone who manufactures, repairs, services,
sells, leases, trades vehicles, or supervises a fleet of vehicles are not
permitted to intentionally remove an emission control device or prevent
it from working. Information about your vehicle's emission system is on
the Vehicle Emission Control Information Decal located on or near the
engine. This decal identifies engine displacement and gives some tune up
specifications.
Please consult your ªWarranty Guideº for complete emission warranty
information.
Readiness for inspection/maintenance (I/M) testing
In some localities, it may be a legal requirement to pass an I/M test of
the on-board diagnostic (OBD-II) system. If your ªcheck engine/service
engine soonº light is on, reference the applicable light description in the
Warning Lights and Chimessection of your owners guide. Your vehicle
may not pass the I/M test with the ªcheck engine/service engine soonº
light on.
If the vehicle's powertrain system or its battery has just been serviced,
the OBD-II system is reset to a ªnot ready for I/M testº condition. To
ready the OBD-II system for I/M testing, a minimum of 30 minutes of city
and highway driving is necessary as described below:
²First, at least 10 minutes of driving on an expressway or highway.
²Next, at least 20 minutes driving in stop and go, city type traffic with
at least four idle periods.
Allow the vehicle to sit for at least eight hours without starting the
engine. Then, start the engine and complete the above driving cycle. The
engine must warm up to its normal operating temperature. Once started,
do not turn off the engine until the above driving cycle is complete.
EXTERIOR BULBS
Replacing exterior bulbs
Check the operation of the following lamps frequently:
²headlamps
²foglamps
²high-mount brakelamp
²brakelamps
Maintenance and care
139

Aiming headlamps ....................142
Air bag supplemental restraint
system ..........................................47
and child safety seats ..............48
description ................................47
disposal ......................................50
indicator light ...........................50
passenger air bag ...........48,51,52
Air conditioning
manual heating and air
conditioning system .......19,20,21
Ambulance packages ....................3
Anti-lock brake system (ABS)
description ................................66
Anti-theft system ........................35
Battery .......................................128
voltage gauge ............................15
Brake fluid
checking and adding ..............118
Brakes ..........................................64
anti-lock ................................64,65
anti-lock brake system (ABS)
warning light .............................66
fluid, checking and adding ....118
Brake-shift interlock ...................67
Break-in period .............................2
Bulbs, replacing ........................139
headlamps ...............................140
specifications ..........................141
Changing a tire .........................101
Child safety seats ........................54
Chime
headlamps on ............................11
Cleaning your vehicle ...............142
engine compartment ..............143
fabric ........................................146
instrument panel ....................146
plastic parts ............................145
safety belts ..............................146
tail lamps .................................145
washing ....................................142
waxing .....................................143wheels ......................................143
windows ..................................146
Clutch
fluid ..........................................119
Controls ..................................23,31
Driving under special
conditions ....................................77
high water .................................78
slippery roads ......................78,79
Emission control system ..........138
Engine ........................................151
service points ............112,113,114
Engine block heater ...................62
Engine coolant
checking and adding ..............121
disposal ....................................122
refill capacities ........................123
Engine oil ...........................115,117
changing oil and oil filter .......118
checking and adding .......115,117
Exhaust fumes ............................63
Foglamps .....................................16
Four-Wheel Drive vehicles .........74
control trac ..........................22,75
indicator light ...........................75
Fuel
calculating fuel economy .......137
improving fuel economy ..........92
octane rating ...........................136
quality ......................................136
running out of fuel .................137
safety information relating
to automotive fuels ................135
Fuel gauge ...................................12
Fuel pump shut-off switch .........93
Fuse panels
instrument panel ......................95
power distribution box .............98
Fuses .......................................94,95
Gauges, Mechanical
engine coolant temperature
gauge .........................................13
Index
156

Hazard flashers ...........................93
Headlamps ...................................16
daytime running lights .............16
flashing ......................................17
high beam .................................16
Heating ........................................17
High beams
indicator light .............................9
Hood ..........................................111
Instrument panel
lighting up panel and interior .17
Jump-starting your vehicle .....106,
107
attaching cables ......................107
disconnecting cables ..............108
Keys
key in ignition chime ...............11
Lamps
interior lamps .........................141
Lights, warning and indicator
air bag ..........................................8
anti-lock brakes (ABS) ..............8
anti-theft .....................................9
brake ............................................8
charging system ..........................9
check engine ............................6,7
cruise indicator .........................10
door ajar ....................................10
fuel reset .....................................8
overdrive off ................................9
safety belt ...................................8
turn signal indicator ...................9
Load limits
trailer towing ............................81
Lubricant specifications ...........150
Manual transmission
driving .............................72,73,74
Mirrors
cleaning ...................................146
side view mirrors (power) .......31
Motorcraft parts ........................147
Odometer .....................................14Off road driving, 4-wheel drive .77
Overdrive .....................................28
Panic alarm feature, remote
entry system ................................33
Parking brake ..............................66
Power door locks ........................31
Power steering
fluid, checking and adding ....123
Radio ............................................24
Recreational towing, all wheels
on the ground .............................89
Refill capacities for fluids ........148
Relays ..........................................94
Remote entry system .................32
illuminated entry ......................34
locking/unlocking doors ...........32
replacement/additional
transmitters ...............................34
replacing the batteries .............33
Reporting safety defects ..........155
Safety restraints
extension assembly ..................45
lap and shoulder belts ...40,41,42
maintenance ..............................46
proper use .................................39
warning light and chime .........11,
45,46
Safety seats for children
attaching with tether straps ....57
tether anchorage hardware .....58
Seats ............................................37
adjusting the seat, manual .......37
jump seats ............................38,39
lumbar support .........................38
rear seat access ........................38
Servicing your vehicle ..............110
precautions when servicing ...110
Snowplowing .................................2
Special notice
diesel-powered vehicles .............3
utility-type vehicles ....................2
Speed control ..............................24
Index
157
