spark plugs replace FORD RANGER 1999 2.G Owners Manual

MOTORCRAFT PART NUMBERS
Component 2.5L I4
engine3.0L V6
engine4.0L V6
engine3.0L V6 FFV
engine
Air filter FA-1658 FA-1658 FA-1658 FA-1658
Fuel filter FG-986B FG-986B FG-986B FG-991
Battery BXT-59 BXT-59 BXT-59 BXT-59
Oil filter FL-400S FL-400S FL-1A FL-400S
PCV valve EV-227 EV-130 EV-225 EV-130
Spark plugs* AWSF-
32F**AWSF-
32PP***AGSF-
22PP***AGSF-
12PP***
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
** Two spark plugs per cylinder required (eight total).
*** If any spark plug needs to be removed for inspection, it must be
re-installed in the same cylinder. Cylinders No.1, 2 and 3 have a ªPGº
suffix. Cylinders No. 4, 5 and 6 have a ªPº suffix. If any spark plug needs
to be replaced, use only spark plugs with the service part number suffix
letters ªPPº as shown on the engine decal.
REFILL CAPACITIES
Fluid Ford Part
NameApplication
Capacity
Engine oil
(includes filter
change)Motorcraft 5W30
Super Premium
Motor Oil2.5L I4 and 3.0L
V6 engine4.3L
(4.5 quarts)
4.0L V6 engine 4.7L
(5.0 quarts)
Brake fluid High
Performance
DOT 3 Motor
Vehicle Brake
FluidAll
Fill to line on
reservoir
Power steering
fluidMotorcraft
MERCONtAT FAll Fill to range on
dipstick
Capacities and specifications
200

locking/unlocking doors ...........65
replacement/additional
transmitters ...............................67
replacing the batteries .............66
Safety belts (see Safety
restraints) ....................................11
Safety restraints
cleaning the safety belts ...81,199
extension assembly ..................80
for children ..........................90,91
lap belt .................................78,79
warning light and chime .....11,80
Seat belts (see Safety
restraints) ................73,74,75,76,77
Seats ............................................71
child safety seats ......................92
Servicing your vehicle .......152,153
Snowplowing .................................3
Spark plugs, specifications .......200
Special notice ................................3
ambulance conversions ..............3
utility-type vehicles ....................3
Specification chart, lubricants .202
Speed control ..............................56
Speedometer ...............................14
Starting your vehicle ......97,98,100
jump starting ............146,147,149
Steering wheel
tilting .........................................61
Tachometer .................................13
Tires .............................173,174,175
changing .............141,142,143,144
checking the pressure ............175replacing ..................................176
rotating ....................................175
snow tires and chains ............177
tire grades ...............................174
treadwear ................................174
Towing
recreational towing ..........130,131
wrecker ....................................151
Traction-lok rear axle ...............120
Transfer case
fluid checking .........................169
Transmission ......................107,166
fluid, checking and adding
(automatic) ......................166,167
fluid, checking and adding
(manual) .................................168
manual operation ....................112
Trip odometer .............................14
Vehicle dimensions ...................205
Vehicle Identification Number
(VIN) ..........................................208
Vehicle loading ..........................121
camper bodies ........................132
Ventilating your vehicle ...........102
Warning chimes .............................6
Washer fluid ..............................162
Water, Driving through .............121
Windows .................................62,63
Windshield washer fluid and
wipers
checking and cleaning ............172
operation ...................................62
replacing wiper blades ...........173
Index
212
