The cooling system on the XR4Ti is fairly unique. If there is
another car with more individual hoses in the cooling system,
we have yet to see it. Compound this with the changes
throughout the model run and it gets even more complex. We
have a good inventory of the hoses and other cooling related
components that fit 1985-87 XR4Ti and some (where similar
or noted) for 88-1989 cars.
pA
Hose- heater valve to pipe (leads to oil cooler) M421HC
pB
Hose- heater valve to heater coreM421H

(note: pB interchanges with pJ)
pC Hose- heater valve to pipe along valve cover (upper)
at rear
(note: pC interchanges with pF )M421HB
pD
Heater Valve- heater control valve XR & Scorpio M421V
pE
Hose- water pipe (lower) to oil coolerM421HE
pF
Hose- oil cooler to water pipe (from heat valve)M421HB

(note: pF interchanges with pC )
pG Hose- oil cooler to intake manifoldM421HD
pH
Oil Cooler- replacement water to oil heat exchangerAWC1
pI Hose- pipe along valve cover (lower) @ front to water
pump. This one is a common problem.M421HA
pJ
Hose- pipe along valve cover (upper) @ front to thermostat
housing (heater supply). Don't hit the road without an extra one
of these!
(note: pJ interchanges with pB )M421H
pK
Water Pump- quality replacement pump L6A
pK1
Thermostat Housing- H.D. cast Iron version L2F
pL
Hose- radiator (lower) 1985-88 (MT & AT)M421BH
pL
Hose- radiator (lower) 1989 (auto & manual)M421BH9
pM
Hose- radiator (upper) 1985-88 (MT & AT)M421TH
pM
Hose- radiator (upper) 1989 (MT & AT) M421TH9
pS
pK1
Cooling System (XR)
pW
Plumbing Schematic
1985-88 XR4Ti w/5 speed
pTpR
pN Hose- expansion tank (top fitting) to valve cover pipe
(note: shape of hose not accurate in drawing)M421TT
pO
Expansion Tank- Thread-on cap (similar to Scorpio) Ford
tanks, some with, or without, the fluid level sensor port. Tank
caps, fluid level sensors, and sensor mounting parts are also
available. (see price list for complete listing)
Tank 1985-88 M421E Tank 1989 w/o sensor M421E9
pP
Hose- expansion tank (lower fitting) to radiator drain line
M421TL
pQ
Hose- expansion tank (middle fitting) to radiator (upper)
M421TM
pR
Radiator- O.E. type replacement radiators for 1985-89 manual
or 1985-88 auto transmission XR4Ti's.
(1985-88 manual) M421R (1985-88 auto) M421RA
(1989 manual) M421R9 (1989 auto) M421R9A
Mount/Bushing- @ radiator top mounting locationM421RM
pS
Electric Fan- An altermative to the sometimes troublesome
dual cooling fans on the XR4Ti, this highly efficent (1100 cfm) 16"
electric "puller" fan does the work of both. Wire directly or use our
(optional) adjustable 165-215 degree thermostat/relay pack.
(16" puller fan) A16F-PL (thermo/relay) AFTR1
pT
Blower Motor & Fan A/C & Heater -for heater and A/C,
check fuse & relay first before ordering. M470A
pU
Heater Core- New O.E. Ford heater cores. M471
pV
Turbo Water Hose -high temperature CPE silicone hose for
turbo (water) inlet/outlet pipes. (1 foot makes 3 hoses)
M421WT
pW
Hose- Lower drain pipe @ radiator lower M421HF
