Brake (related)
pA
pEpA
Racing Brake Fluid Not all brake fluid is created equally. High
operating temperatures at the caliper transfers extreme heat through the piston
causing lesser quality brake fluid to boil. This in turn allows the fluid to become
compressed and reduces overall braking performance. The best way to
counter this from happening is to use a racing specification, mineral (never
synthetic) brake fluid and flush the system after each event for competition or
annually on performance street driven vehicles. Both AP550 and Wilwood 570
brake fluid is DOT approved with a dry boiling point of 550-570 degrees, low
viscosity minimizes aeration and permits easy bleeding.
Brake Fluid AP Competition (16.9oz. 500ml.) MC550
Brake Fluid Wilwood 570 (12oz. 355ml.) MC570
Brake Fluid Wilwood 570 (6 Pack) MC57-6
Brake Fluid Wilwood 570 (24 Case) MC57-C
pB
Cosworth & Scorpio Rotors For those fortunate few who own
Cosworth Sierras or have converted XR4's to Cosworth type front or rear brakes
and are in need of replacement rotors we have them. Scorpio front or rear rotors
in standard and cross drilled are also available. (see price list page 31)
Cosworth Front 283 x 24mm standard, X-drilled, grooved
Cosworth Rear 273 x 10mm standard, X-drilled, grooved
Scorpio Front 260 x 24mm standard or X-drilled
Scorpio Rear 253 x 10mm standard or X-drilled
Performance Brake Kits Engineered competition brake kits for the
ultimate in stopping power.
pC Front R/S Brake Kit (283 x 24mm)
BAT R/S "big brake" kit allows larger 11.25" (285mm) brake rotors to be fitted
with standard XR calipers. Increasing rotor "swept area" in this way will greatly
improve stopping power (leverage) and help to reduce high brake temperatures
that can cause premature brake fade and poor pedal feel.
Kit includes:
285 x 24mm vented (standard or cross-drilled) rotors, Mintex 1144 brake pad
set, caliper mounting brackets & hardware (fitment with most 15" wheels -
some require slight modification)
kit supplied with standard rotors
M418
kit supplied with cross drilled rotors M418A
pD Front Brake Kit (283 x 24mm) w/4 Piston Calipers
Combine the performance of the R/S large rotor kit with 4 piston calipers for the
ultimate in stopping power.
includes: 283 x 24mm vented rotors,
4-piston alloy Wilwood Superlite 2A calipers with pads. (fitment with most 15"
wheels -some require modification or spacers)
M416W
pD Front Brake Kit (300 x 32mm) w/4 Piston Calipers
For those who are looking for the ultimate brake performance. Quite simply the
largest and most competent competition type brake kit that can be fitted to the XR4.
includes: 300 x 32mm vented rotors with light alloy hats, 4-piston alloy Wilwood
Superlite IIA calipers, caliper mounting brackets & hardware
M417A
(this kit also available for Scorpio ! ) G417A
Rear Kit (XR4 w/16" wheels) 300 x 21mm (See Price List)
includes: 300 x 21mm vented rotors with light alloy hats, 4-piston alloy Wilwood
Superlite 2A calipers, caliper mounting brackets & hardware
pE Wheel Bearings Genuine European Ford wheel bearing kits are
complete with all required service parts to do a first class job. Each kit
include bearings, races, seals and hub nuts to service one wheel.
Front Wheel Bearing Kit (specify left or right) -XR4 M560F
Rear Wheel Bearing Kit (specify left or right) -XR4 M560R
Front Wheel Bearing Kit (specify left or right) -Scorpio G560F
Rear Wheel Bearing Kit (specify left or right) -Scorpio G560R
pB
pC
pD
1 0
Page 12 of 45
pA Constant Velocity Joints & Boots The Merkur XR4Ti and Scorpio
independent rear axle assemblys utilize half shafts that have inner and outer constant
velocity joints. Eventually these joints and protective boots will require service. We
have joints and boots available separately making it economical to replace just the
worn component without having to replace whole axle assembly. However, if more
than one C.V. per axle requires service, our complete axle assembly is the more cost
effictive way to go.
Note: right/left inboard and outboard C.V. joints and boots are
interchangeable- see price list for complete axle prices (handed left & right)
Constant Velocity Joint- XR4 & ScorpioM550B
C.V. Boot Kit-
XR4 & ScorpioM550BK
Complete Axle(specify left or right)-
XR4 & ScorpioM550L/R
pB
Rubber Drive Shaft Coupling The rubber "Drive Donut" or "Rotoflex
Coupling" on the XR4 and Scorpio drive shaft can be a real bugger. Many owners
have contacted us after being quoted up to 500.00 to totally replace the complete
drive shaft assembly by the local Ford L/M dealer, as they do NOT list the rubber
drive coupling as a separate service part. We import the proper replacement
drive coupling and make it available at considerable savings to you. If your car
exhibits a driveline shudder that increases with speed, (especially noticeable in
colder weather) we recommend taking a close look at the condition of the drive
coupling. Cracks in the rubber or missing pieces will require immediate replace-
ment, loosing one of these joints at speed will be very messy !
Note: BAT supplies
the standard equipment XR4i drive coupling by the original supplier to Ford. This
is not a lesser "fits all" component that just happens to be similar.
Rubber Drive Shaft Coupling- XR4 & ScorpioM17A
pC
Drive Shaft Center Support Bearing- Replacement driveshaft
center support bearing assemblys for XR4Ti and Scorpio.
Drive Shaft Center Support Bearing- XR4Ti M550SB
Drive Shaft Center Support Bearing- Scorpio G550SB
pD
Quaife Torque Biasing Differential Quaife torque biasing
differentials provide a constant and infinitely variable output to both rear
wheels. These unique differentials utilize a series of helical gears which
sense the amount of applied torque and adjust automatically for loss of
traction. The Quaife limited slip design is also free of high wear items
(clutches, ratchets and plates), making them stronger and more maintenance
free than other types of limited slip units. Anyone who has had the pleasure
of driving a vehicle equipped with a Quaife LSD will immediately comment on
its smooth seamless performance, very unlike clutch/plate type LSD's which
exhibit a notchy ratchet like take up through the drive line. The Quaife LSD
that we offer is originally designed as a replacement upgrade for the Sierra
Cosworth and are now supplied with output flanges tapped for either the large
108mm (Cosworth size) or smaller 100mm (XR4 size) C.V. joints.
Quaife Limited Slip DifferentialM710
pE
Clutch Kits We have a very good selection of clutch packages that include
clutch disk, pressure plate, throw out bearing, and clutch alignment tools. Buying one
of our engineered kits will guarantee best quality, performance, fitment (ease of
installation) and price. First option is a new (not rebuilt or re-lined) O.E. quality
replacement clutch kit by Sachs/Valeo. This clutch is best suited for standard or
slightly modified cars being used under normal driving conditions. If your requirements
are beyond the capabilities of the standard clutch we also have some heavy duty clutch
kit options. H.D. clutch kits include pressure plates that have increased clamping force
(from 30 to 50%) and clutch disks with high temperature friction materials applied.
Centerforce H.D. clutch kits have a unique centrifugal pressure plate design with
substantially more clamping force but requires very little pedal pressure over the stock
clutch.
Note: all kits are for standard transmission 1" 23 spline except where noted.
Sachs Clutch Kit XR - best quality O.E. clutchM519K
Sachs Clutch Kit Scorpio -
best quality O.E. clutchG519K
Sachs Clutch Kit XR w/ T5 Trans -
1 1/16" 10 spline for T-5 transM519T5
H.D. Centerforce Clutch Kit -
uprated disk & 30% p. plateM519C
H.D. Center Force II Clutch Kit -
uprated disk & 50% p. plateM519C2
Clutch Alignment Tool -
1" 23 spline for std. transmissionS11H
Clutch Cable- XR4Ti M562
Clutch Cable- Scorpio G562pD
Driveline
pA
pD pB
pC
1 1
Page 13 of 45
Bodywork
pL
pM
pNpE
pA pL
pC pD
pF
pBpG
pH
pI
pJ
pK
pA Front Fenders European Sierra fenders are a direct replacement for the
XR4Ti and are an attractive alternative considering the high price of the American
version. These fenders also include the holes required for side blinker mounting
(see below).
Note: specify left or right when ordering M806 L/R
pB
Inner Wheel Well Splash/Liners Replacements for the commonly
cracked, broken or missing inner fender splash on the XR4. Covers full inner
wheel house area as origional USA versions.
specify left or right M808L/R
pC
Door Skin - (specify left or right)M807 L/R
pD
Door Handle XR4 & Scorpio - (specify left or right)M362 L/R
pE
Door Sill (Rocker Panel) - (specify left or right)M803 L/R
pF
Rear Wheel Arch - (specify left or right)M804 L/R
pG
Battery TrayM817
pH
Rear PanelM815
pI
Cosworth Front Grille Nothing transforms the look of the XR4Ti quite like
adding a Cosworth grille. Designed with a center opening, the Cosworth grille
adds additional air flow to the radiator and A/C condenser for a cooler running
engine and better air conditioning performance. An intercooler could also be fitted
behind the grille opening as is done on the original Cosworth Sierra and R/S 500
models.
Note: Grilles are O.E. quality (injection moulded plastic) not shoddy fiberglass
replicas. Suppled (primed) un-painted- includes "Ford" emblem
M320
pJ
Grille Surround Gasket This gasket will almost always need to be
replaced when fitting a new grille.M320S
pK
European Side Blinker Lamp Kit Add an extra degree of safety when
signaling to turn. Side blinkers fit above European fenders without modification
and can also be fitted to standard Merkur XR4Ti fenders by drilling a mounting
hole. Kit includes (2) lamps, wiring and templates.M317
pL
Cosworth Hood Original equipment Ford Sierra Cosworth hoods are
designed to receive hood vents/louvers for additional under hood cooling. These
hoods look quite distinctive as the raised center section is lower and wider than
on the standard XR4 hood giving the car a more aggressive appearance.M813
pM
Cosworth Hood Vents Hood louvers/vents are both visually striking and
functional as they help to ventilate the engine compartment. These O.E. Ford vents
(pair) bolt into the Cosworth hood (above) or can be fitted to standard hoods by cutting
a hole and bonding them in place.
(see pg 11 for fiberglass versions)M814
pN
Cosworth Front Spoiler/Bumper We supply everything required to
install the stunningly attractive Cosworth Sierra front spoiler/bumper to your
XR4Ti. All components are original Ford including; bumper, bumper bar
brackets, lower side fender mounting panels, fog lamps, turn signal lamps, and
assorted hardware (clips & fasteners).
Note: bumpers are supplied in white-
can be painted to match other colors.
M353
(R/S 500 Version) M353RS
1 2
Page 14 of 45
pA Replica Cosworth Body Components
Fiberglass body panels are an alternative to the more expensive, and
becoming unavailable, factory Ford versions. We have searched far and wide
to import only the highest quality fiberglass replica bodywork. Even so,
fiberglass is more prone to incidental damage (cracking) than the more
flexible ABS plastic or urethane original Ford components. Also keep in mind
that fitting is totally DIY and most items will require paint prep work, fabricated
brackets and other hardware.
Important Note: We often hear horror stories
from customers who have ordered similar fiberglass items from European
mail-order suppliers only to receive broken or substandard components, and
now you own it! Worse yet, the shipping costs involved importing large, bulky,
items like these can far exceed the cost of the part, and what started out as
a bargain now has become a expensive learning experience. Our pricing on
all items, including sheet metal & body panels,
includes inbound freight from
Europe. Once here, some items that are too large for UPS (or other carriers)
will be shipped truck freight collect, we will also extend our 25% C.F. Motor
Freight discount.
Front Spoiler Bumper (R/S Cosworth type) M353F
Front Spoiler Bumper (R/S 500 Type) with lower "splitters*" M353FA
*lower chin spoiler moulded in on lower edge
Rear Bumper (R/S Cosworth type)
Rear Wing Airfoil (R/S Cosworth type)
see information belowM306F
Rear Wing Airfoil (R/S 500 type) M306FA
Lower Rear Wing (R/S 500 type) M306L
Cosworth Wheel Arches (4) & Side Skirts (2)
see information belowM302F
Cosworth Hood (complete with vent louvers)
Hood Vent Louvers (2)
fiberglass (functional)M814F
Hood Vent Louvers (2)
stick-on ABS plastic (non functional)M814FS
pB
Cosworth Sierra Arches & Skirt
Sadly the factory Ford wheel arches have recently become unavaiable. Some
side skirts still remain but for the most part the R/S arches and skirts have gone
the way of all the factory R/S 500 stuff "not availabe- not replaced". In place
of the origionals we can offer a reasonable cost & quality fiberglass alternative
wheel arch and side skirt kit. For anyone searching out new factory arches and
skirts we might still have a couple odd arches & skirts available (no full sets)
call for more information & pricing.
Cosworth Wheel Arches (4) & Side Skirts (2)-
fiberglassM302F
pC
Cosworth Rear Airfoil
One of the trademarks of the Cosworth Sierra is its large rear wing/airfoil.
Perhaps a bit gaudy for some tastes, none the less it does a great job at
keeping the rear end planted. At speeds over 100mph as much as 45 lbs. of
downforce is created for added high speed stability. Anyone interested in this
item had one of two choices. The factory Ford Cosworth rear wing/airfoil (still
available from Ford Europe) but at over $1800.00 who can afford it. Or the
usual aftermarket fiberglass versions, although much cheaper in cost the
quality suffers greatly. When we sampled most of these we were genuinely
concerned that some of the replica wings might come apart, or even fly off at
speed ! This dilemma prompted us to undertake manufacturing a super high
quality fiberglass replica that solves all the above problems. It is extremely
well built, can be securely attached to the car and is attractively priced.
Note:
rear wings are designed to fit smaller hatch 1985-87 cars- the mounting foot
will overhang on the hatch glass molding on later cars and will have to be trimmed.
Rear Wing Airfoil (R/S Cosworth type) M306F
see above section for larger RS500 version
pC
pB pA
Bodywork
(See Price List) (See Price List)
1 3
Page 15 of 45
Trim & Lighting
pA European Emblems & Badges Re-badge your XR4 with Ford ovals
and Sierra emblems or put the finishing touches on that Cosworth clone.
Genuine Ford European logos will distinguish your XR4 or Scorpio from the
rest. Location (on car) for emblems and sticker logos are listed below.
Emblems are chrome and black plastic with self stick backing. Stickers can be
applied to metal or glass surfaces.
Sierra (emblem)
rear hatch leftM321S
Sierra XR4i Red (sticker)
rear hatch leftM352R
Sierra XR4i Anthracite/Gray (sticker)
rear hatch leftM352A
Sierra R/S (emblem)
rear hatch leftM321RS
Cosworth (emblem)
rear hatch left under Sierra R/S emblemM321C
Sierra R/S Cosworth (sticker)
rear hatch leftM352C
R/S (emblem)
side fender XR & ScorpioM352RS
Ghia- crest (emblem)
side fender XR & ScoprioM352G
Oval "Ford" (emblem)
front grille center & rear hatch rightC321
"Ghia"- script (emblem) Scorpio rear hatchG352G
2.9i (emblem)
Scorpio rear hatchG352L
Scorpio (emblem)
Scorpio rear door sail panelG352S
pB
European Headlamps The standard US spec. XR4 & Scorpio
headlights were pretty poor when new, and get worse with age- especially when
the lenses turn cloudy. European headlamps will provide a significant increase
in light output and they look great too. These lamps utilize all glass lensing with
a halogen H-4 55/60 watt bulb for high/low main beam operation, and a halogen
H-3 55 watt bulb for the built-in driving lamp.
Note: Lamps are supplied in right hand
drive (English) specification which has a subtle different low beam flair pattern,
however, this is not very noticeable. If required left hand (German) type lenses are
available separately (see price list). We recommend installing the lamps first before
opting to swap out the lenses as most customers do not bother.
Sierra XR4 European Headlamp Kit* M318
*kit includes (2) lamps, rear bulk heads panels, bulbs & wiring instructions
Scorpio* European Headlamp Kit G318
*kit includes (2) lamps, left & right lamp lamps/indicators & front grille sections,
bulbs, and wiring instructions
Scorpio Fog Lamp (LH)- complete replacement assembly G349L
Scorpio Fog Lamp (RH)- complete replacement assembly G349R
pC
Head Lamp Bulbs Replacement and higher wattage bulbs for above
European headlamps and standard XR4 & Scorpio aerolamps. Headlamps- H4
bulbs are fit eurolamps (not stock headlamps), 9004 bulbs are for use with standard
XR4Ti & Scorpio aerolamps. Fog lamps- H3 bulbs are suitable for eurolamps and
Scorpio, 880 bulbs fit
only XR4Ti fogs. Krypton gas 9004 "Bright White" bulbs burn
brighter with more luminous output than standard halogen type bulbs.
"Blue Ion"
bulbs project a, low glare, blue tinted beam- definitely a different look !
H4 55/60 watt (for high/low main beam) Z H4 55/60
H4 55/100 watt (for high/low main beam) Z H4 55/100
H4 80/100 watt (for high/low main beam) Z H4 80/100
H3 55 watt (for fog & driving lamps) Z H3 55
H3 100 watt (for fog & driving lamps) Z H3 100
880 50 watt "Blue Ion" 50 watt (for XR4Ti fog lamps) Z 880/50B
880 50 watt "Amber" 50 watt (for XR4Ti fog lamps) Z 893/50G
9004 "Bright White" 45/65 watt (for high/low main beam) Z 9-45/65W
9004 55/100 watt (for high/low main beam) Z 9-55/100
9004 80/100 watt (for high/low main beam) Z 9-80/100
9004 "Blue Ion" 55/100 watt (for high/low main beam) Z 9-55/100B
Relay (Hella) 12 volt-
(2) required w/ 80/100 bulbsZ Relay12
pD
Rear Tail Lamp Seals & Lamp Sockets Puddles in the trunk or damp
carpeting might be due to leaking rear tail lamp seals. Non-functioning tail
lamps are usually due to corroded lamp sockets. We have new replacements
for both these USA Ford unavailable parts.
Left or Right Tail Lamp
Seal- XR4 M319S
Left or Right Tail Lamp
Socket- XR4 M319LS
H4 H3 9004 pC
pD
pA
(h XR) (Scorpio i)
pB
Scorpio fog lamps
1 4
Page 16 of 45
Wheels
pA
The XR4 is a unique application for road wheels. They are
designed for use with (hub-centric) wheels in a 35-40mm
offset- not the most common application here in the USA.
We import factory Ford European Ford "Rally Sport" brand
wheels, or proven aftermarket applications, that we know fit
the car properly.
pA
6-Spoke R/S Wheel Advanced styling with flat flush
spokes, silver color- clear coat finish for added protection,
locking center cap w/ R/S logo.
6-spoke R/S Wheel (
available sizes)
(15" x 7" , 16" x 7") $209.00 each
pB 5-spoke Cosworth Wheel
Original equipment on Cosworth Escort- optional on Mondeo in
Europe (similar to 1998 SVT wheel) silver color- clear coat finish
for added protection, center cap w/ Ford oval.
5-spoke Cosworth Wheel
(available sizes)
(15" x 6") $195.00 each
(16" x 6.5", 16" x 7") $209.00 each
pC 7-Spoke "Soft Effect" Wheel Flush spoke, silver color-
clear coat finish for added protection or optional chrome finish,
locking center cap w/ Ford oval.
7-spoke "Soft Effect" Wheel (silver)
available sizes
(15" x 6", 15" x 7", 17" x 7.5") $209.00 each
7-spoke "Soft Effect" Wheel (chrome) available sizes
(15" x 6", 15" x 7", 17" x 7.5") $309.00 each
pB
pC
pD
pE
pD
5-Spoke R/S Wheel Bright diamond cut silver face with
anthracite gray on sides of spokes, clear coat finish for added
protection, locking center cap w/ R/S logo.
5-spoke R/S Wheel
(available sizes)
(15" x 7", 16" x 7", 17" x 7.5") $209.00 each
pE 5-Spoke SVT Wheel These are original equipment 1999
SVT Contour (16" x 6.5" size) and 2001 Focus SVT (17x7") wheels.
5-spoke SVT Wheel (16" x 6.5") $135.00 each
5-spoke SVT Wheel (17" x 7.0") $135.00 each
pF 5-Spoke Motorsport Wheel Exclusive for Ford by
Compmotive. Five Spokes with Motorsport logo on one spoke,
carbon look center cap w/singel hex nut center.
5-spoke Motorsport Wheel (silver)
$249.00 each
available sizes (15" x 6" or 16" x 7") ET 35/38mm
pH Turbine Wheel Exclusive for Ford by Compmotive.
Flush face turbine style wheel.
Turbine Wheel (silver)
$249.00 each
available size (16" x 7") ET 38mm
pG 5-Spoke RE Wheel Exclusive for Ford by Compmotive.
"RE" Wheel (silver)
$189.00 each
available size (15" x 6") ET 35mm
pI 6-Spoke FLN Wheel Exclusive for Ford by Compmotive.
"FLN" Wheel (silver)
$189.00 each
available size (16" x 7") ET38mm
pG
pH
pI pF
1 5
Page 17 of 45
Wheels
4 Spoke "Turbo" Wheel
Stylish 4 spoke "Turbo" wheel available
in 16" diameter with either a 6" or 6.5"
width. Finish is bright silver. We highly
recommend these factory Ford wheels
for guaranteed quality fit and finish.
Center cap included.
4 Spoke "Turbo" Wheel
16 x 6" $195.00
16 x 6.5" $195.00
2 x 4 Spoke Wheel
Stylish 2 x 4 spoke wheel available
in 16 & 17" diameters from 6.5" to
7.5" widths. Finish is bright silver.
We highly recommend these factory
Ford wheels for guaranteed quality
fit and finish.
Center cap included.
2 x 4 Spoke Wheel
15 x 7" $209.00
16 x 6.5" $209.00
17 x 7.5" $209.00
TW "Thrust" Wheel
10 spoke "Thrust" light alloy
wheel with a locking center
cover. Available in charcoal
grey with polished silver lip in
15 x 7" size. A great looking
wheel at a budget price.
TW "Thrust" Wheel
15 x 7" $109.00
Wheels FYI
We offer only direct fit wheels for the Contour in the 4 x 108mm pattern and 35-40mm offset range. Most
are factory Ford or Ford Motorsport authorized wheels which guarantees quality fit and finish. BAT imports
these wheels directly from Europe and our prices include all inbound freight charges. Outbound freight
from our location to you by UPS ground will cost between 30.00 to 50.00 per set of 4 wheels- depending
on your location. Please note: We often hear horror stories from customers who have ordered wheels
from European mail-order suppliers only to receive damaged or substandard components, and now you
own it! Sending it back or trying to get the freight carrier to pay for the damage is next to impossible they
will just claim it was "improperly packed" or "it wasn't that way when it left here". Worse yet, the shipping
costs involved importing large, heavy, items like wheels can far exceed the cost of the part (expect 50.00
to 100.00 per wheel) What started out as a bargain now has become a expensive learning experience.
Avoid the hassles, let us supply your wheels to your door at a fair
price. When you do the math you will find we are saving you money.
ST200 Wheel
Stylish 14 spoke wheel available in 17" diameter with a 7" width. Factory
equipment on the Mondeo ST200. Finish is bright silver. We highly
recommend these factory Ford wheels for guaranteed quality fit and finish.
Center cap included. (wheel might requite a spacer for XR fitment)
ST200 Wheel 17 x 7" $209.00 each
1 6
Page 18 of 45
Accessories
pA Scorpio R/S Rear Wing This hot looking rear wing goes a long way
in transforming Scorpio's look. For installation R/S wings will require
painting to match your cars color, and some mounting holes from the
standard spoiler will need to be filled and spot painted. Also note that a rear
brake light will need to be located elsewhere in the rear window.G306
Scorpio R/S Side Skirts Matching Rally Sport rocker panel side skirt
set looks great with above rear wing or without. Other than just good
looks, side skirts help to keep the door sides and rockers cleaner and with
less stone chips. Easy to fit, paint and install.G302S
pB Scorpio Cowl Cover What is it, and why doesn't my car have one?
This is a commonly asked question regarding this item. Ford equipped
very few Scorpios bound for the US market with these European cowl
covers. This moulded plastic cover keeps dirt, debris and small animals
from winding up in the ventilation fan and associated duct work. Clean
out this area once and for all, then install a new cowl cover- your Scorpio
will thank you.G369C
pC Mini-Lite Wheels (15" x 7") for XR4 Cars of English heritage,
XR4's included, look great on classic Mini-Lite type wheels. These
wheels are both lightweight and attractive with a bright silver clear coat
finish. Specifications: 4 x 108mm pattern, 15" x 7" size, 38mm offset,
18lbs each, center caps included.M411M
pD Thrust Wheels (15" x 7") for XR4 We are often asked to supply
inexpensive road wheels, and here they are. The Thrust is a 10 spoke
light alloy wheel with locking center cover, available in either silver, or
charcoal w/silver lip. You will not find a better quality, proper wheel
fitment for the price. Specifications: 4 x 108mm pattern, 15" x 7" size,
35mm offset, 18lbs each, locking center covers included.M411T
pE Floor Mats Foul weather mats, commonly referred to as "ice cube
trays" or "waffle mats", are made of heavy duty rubber with small
compartments to catch melting ice, water, mud etc. from your shoes or
boots. These Euro. Ford mats are the best protection for your interior for the
winter months or when going afield. Can be placed over standard plush
mats or directly on carpeting. When dirty or filled with water- remove, drain,
hose off, and reinstall. Front mats will fit both XR4 and Scorpio, rear mats
are for XR4 only.
Front Mat set M1010 Rear Mat SetM1011
First Aid Kits We are often asked to supply the First Aid kits that Ford
equips new cars with in Europe. Includes more than just a selection of
"Band-Aids". Think of it as good insurance.M102
Fuse Box Covers A common breakage item on XR4's. We have new
European Ford replacements.M474
pF Sunroof Wind Deflector The buffeting effect, and wind noise, that
takes place with the sunroof open at speed can be eliminated with a
Sunroof Wind Deflector. Tinted smoke (grey) acrylic, fits both XR4 and
Scorpio- hardware included.M307
pG Side Window Wind Deflector for XR4 A similar product to the
Sunroof Deflector the Side Window Deflector keeps the wind noise levels
to a minimum while allowing maximum ventilation. Effective even in light
rain! Tinted smoke (grey) acrylic, easy installation- no holes to drill. For
XR4 only- sold in pairs.M340WD
pB
pD
pC
pA
pE
pG pF
1 7
Page 19 of 45
Accessories
pApA
Cosworth Sierra Steering Wheel This sporty 3 spoke design
leather wrapped steering wheel is standard factory issue on the Sierra
Cosworth and RS500 models. The smaller wheel diameter (13.9 inch) helps
make the steering ratio more effective and the fatter rim grip offers both comfort
and control. Wheel is available in black and included center horn button with
Ford logo and horn symbol.M322
pB Cosworth Sapphire Steering Wheel This 3 spoke leather wrapped
wheel from the Sierra Sapphire 4x4 steering wheel is a departure on the
original Coswoth version. It's wider center spokes are positioned lower for
comfortable hand position and a better view of the instrumentation. The smaller
wheel diameter (13.9 inch) helps make the steering ratio more effective and the
fatter rim grip offers both comfort and control. Wheel is available in black and
included center horn button with Ford logo and horn symbol.M322A
Standard Horn Button for the standard XR4 steering wheel we have the
European "Ford" oval logo horn button. Just the thing for finishing the interior
off while fitting Ford logos to the exterior.
Z61551
pC Contoured Dash Overlay just the ticket for covering up a cracked
vinyl dash pads which are so common on the XR4 & Scorpio. This moulded
plastic dash overlay is simple to install and covers up a world of sin, quickly
returning the interior to its original splendor.
note: supplied in black can be easily
painted to match interior color
(for XR4) M323
NEW (for Scorpio) G323
pD White Gauge Face Set Colored gauges are quite the rage. They add
a very unique look to the interior, and are easy to read in daylight or when
illuminated at night. We have a gauge face kit that will replace the standard
(black) speedo, tach/boost, fuel and water temp, gauges and indicator lamps
with a thick self adhesive mylar faces that are white in color. These gauge
faces are manufactured specially for BAT by a original equipment instrument
supplier to Ford, GM, Vauxhall so quality is outstanding. They illuminate from
the rear "back light", just as the standard gauges, and will not opaque with age
like typical cheap reproductions will. An added benefit of our gauge face kit
is the speedo is calibrated beyond 85mph all the way to 150mph. Updating
earlier cars with 85mph speedos is a snap.
(available spring 99) M341W
pE
170 mph Speedometer For the owners of land based cruise
missiles we offer the original equipment Sierra Cosworth speedometer
calibrated in mph (170 in white) and kmph (270 in yellow) with re-setable
trip-meter. A slight bit of tweaking is required to fit.
M341A
150 mph Speedometer Sierra XR4's and later Merkurs came with a more
realistic 150 mph speedometer which easily replaces the American (only
calibrated to 85 mph) version.M341
Dash Instrument Panel Bulb lamp with (white) socketM330L
Dash Warning Lamp Bulb lamp with (gray) socketM330WL
pF Torch Key & Battery complete Ford key blank and lamp/battery.
Torch key blanks and lamp batterys are also listed separately below.
C309KL
Torch Key Blank replacement key blank for XR4 (less lamp)Z61179
pG Lamp & Battery lamp and battery for XR4 & Scorpio keysC309KLB
pH Standard Keys as an extra key or an alternative to the more bulky torch
key, this European key blank has a molded plastic grip with wide ring slot with
Ford logo.
(for Scorpio) G309K (for XR4) C309K
Hatch Lock Assembly lock assem. w/housing & 2 keysM815L
Hatch Striker commonly required replacement itemM815S
Hatch Lock Retaining Clip commonly required replacement itemM815C
Complete Car Lock Set doors, hatch, ignition w/ 2 keysM309LS
pD
pE
BRAKE
pF
pHpG pC
pB
turbo
1 8
Page 20 of 45
pA Windshield Wiper Headlamp Switch Stalk We supply a new
Ford Europe replacement for this commonly required electrical item.
Note: please check associated fuses before ordering- this item is not
returnable.
Windshield Wiper Headlamp Switch/Stalk (XR4)M304
pB Turn Signal Flash/Hazard Switch Stalk We can supply a new
Ford Europe replacement for this commonly required electrical item.
Note: please check associated fuses before ordering- this item is not
returnable.
Turn Signal Flash/Hazard Switch Stalk (XR4)M305
pC Fuse Box Cover Missing, cracked, or not staying closed are all
reasons to replace the fuse box (lid) cover on the XR4. Getting water in
the fuse block can completely ruin a car or make for some very time
consuming and expensive electrical repairs. Don't delay fixing this
condition any longer, we have new Ford European replacements in stock.
Fuse Box CoverM474
pD Door Post Black-Out Trim (stick-on) Is it time to replace the
cracked or peeling door post black-out trim located between the door and
rear quarter window ? We have high quality reproductions of this
discontinued Ford item.
Left Side Door Post (black-out) Trim- 2 pieces M340TL
Right Side Door Post (black-out) Trim- 2 pieces M340TR
pE Pedal Pads The next time you give your cars interior a good detailing
don't forget the finishing touches. New pedal pads not only improve the
look of any interior, but are much safer too. Also it's not a bad idea to
replace pedal pads right before entering a car show or selling a vehicle
as smart buyers and judges will commonly check the pad wear as an
indicator of how (hard) the car is driven.
Accelerator Pedal Pad- XR4 & Scorpio M365A
Clutch Pedal Pad- XR4 & Scorpio M365C
Brake Pedal Pad (manual)- XR4 & Scorpio M365B
Brake Pedal Pad (auto)- XR4 & Scorpio M365BA
pF Rear Hatch Lift Struts Have you resorted to using a wooden
broomstick as a prop rod to hold up the rear hatch on your car ? If you
answered yes you are a definite candidate for new hatch lift struts. XR4's
and Scorpios have heavy rear lift gates (hatches) and when one or both lift
struts are worn forget about having the thing stay up, let alone raise up slowly
and unassisted as when they were new. BAT has new German manufac-
tured lift strut replacements guaranteed to keep things on the up and up.
Rear Hatch Lift Strut- XR4 (each) M308
Rear Hatch Lift Strut- Scorpio (each) G308
pG Rear View Mirror Has your rear view mirror fallen off more times
than you can count ? Don't mess around with nasty glues that only last
a week before redepositing the mirror back on the floor. BAT has the
correct Ford replacement day/night mirror with a (self stick peel-off)
adhesive backing that should keep it attached for another 10 years.
Rear View Day/Night Mirror- XR4 & ScorpioC339
Replacement "Stick-on Pad"
(for stock mirror)M339S
pA
pB
pC
pD
pG
pF
pE
Accessories
fuse box cover
1 9
