spare wheel FORD TAURUS 1996 Owners Manual

222
*
[RE04450(ALL)03/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
%
*
[RE04500(ALL)03/95]
Changing a Tire
*
[RE04600(ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
[RE04610(ALL)01/95]
NOTE: Tire sealants that are injected through
the valve stem are not to be used to
service punctured tires because they
can produce wheel rust and tire
imbalance.
%*
[RE04700(ALL)03/95]
The Temporary Spare Tire
*
[RE04800(ALL)03/95]
You may have a high pressure temporary spare
tire. This spare tire is smaller than a regular tire
and is designed for emergency use only. Use it
only when you get a flat tire and replace it as
soon as you can. This spare tire is marked with
the words ªTEMPORARY USE ONLYº so that
you can easily identify it.
*
[RE04900(ALL)01/93]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
File:12fcret.ex
Update:Mon Jan 22 16:01:15 1996
ProCarManuals.com

223
*
[RE05000(ALL)01/95]
When you drive with the temporary spare tire,
DO NOT:
*
[RE05100(ALL)01/95]
q
exceed 50 mph (80 km/h) under any
circumstances.
*
[RE05200(ALL)01/95]
q
load your vehicle so that it is heavier than
the maximum vehicle load rating listed on
the tire decal.
*
[RE05300(ALL)01/95]
q
tow a trailer.
*
[RE05400(ALL)01/95]
q
use tire chains on this tire.
*
[RE05500(ALL)01/95]
q
try to repair the temporary spare tire or
remove it from its wheel.
*
[RE05600(ALL)01/95]
q
use the wheel for any other type of vehicle.
*
[RE05700(ALL)01/95]
q
drive through an automatic car wash with
this tire. Because the temporary spare tire is
smaller than a conventional tire, it reduces
the ground clearance. Your vehicle may get
caught in the rails and it could be damaged.
% [RE05800(ALL)11/94]
The Conventional Spare Tire (If equipped)
*
[RE05900(ALL)01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
%*
[RE06000(ALL)03/95]
Spare Tire Location
[RE06100(ALL)04/95]
In a sedan, the spare tire is stored in the trunk
under the floor carpet.
File:12fcret.ex
Update:Mon Jan 22 16:01:15 1996
ProCarManuals.com

225 [RE06300(ALL)11/94]
In the wagon, the temporary spare tire is stored
in the left side rear trim panel.
[RE06400(ALL)02/95]
one third page art:0000392-B
The temporary spare tire in the wagon
[RE06700(ALL)11/94]
To remove the cover for the temporary spare
tire in the wagon:
[RE06800(ALL)04/95]
1. Twist the three fasteners 90 degrees into a
vertical position.
[RE06900(ALL)02/95]
2. Lift the the cover to disengage the three
retainers.
[RE07000(ALL)05/94]
3. Pull the front of the cover out slightly and
remove the cover by sliding it toward the
front of the vehicle.
*
[RE07100(ALL)01/89]
4. Lift out the spare tire, jack, and lug wrench.
%*
[RE07400(ALL)03/95]
Preparing to Change the Tire
*
[RE07500(ALL)05/94]
You should only raise your vehicle with a jack
properly placed at the front or rear jacking
points.
*
[RE07600(ALL)03/95]
1. Make sure that your vehicle will not move
or roll. Put the gearshift in P (Park). Set the
parking brake and block the wheel that is
diagonally opposite the tire that you are
changing.
File:12fcret.ex
Update:Mon Jan 22 16:01:15 1996
ProCarManuals.com

226 [RE07700(ALL)07/95]When one of the front wheels is off the ground,
the transaxle alone will not prevent the vehicle
from moving or slipping off the jack, even if the
vehicle is in P (Park). To prevent the vehicle
from moving when you change a tire, block (in
both directions) the wheel that is diagonally
opposite to the tire being changed.
*
[RE08400(ALL)09/95]
RWARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
*
[RE08800(ALL)03/95]
2. Get out the spare tire and jack.
*
[RE08850(ALL)05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
% [RE08900(ALL)02/93]
3. Remove wheel covers or aluminum wheel
ornaments with the tapered end of a wheel
nut wrench. Insert the handle of the wrench
between the wheel and ornament and twist
it against the inner wheel cover flange.
*
[RE09200(ALL)09/95]
4. Loosen each wheel lug nut one-half turn
counterclockwise, but do not remove them
until the tire is raised off the ground. You
should pull up on the handle rather than
push to develop maximum force to loosen
wheel lug nuts. SeeAnti-Theft Wheel Lug
Nutslater in this chapter for information on
removing anti-theft lug nuts.
File:12fcret.ex
Update:Mon Jan 22 16:01:15 1996
ProCarManuals.com

228
*
[RE12002(ALL)08/95]
Your vehicle has metric (12 mm) wheel studs
and lug nuts. During wheel removal and
replacement, make certain that you use the same
lug nuts to reinstall the wheel or replace them
with nuts of the same metric size and threading.
*
[RE12005(ALL)08/95]
RWARNING
Installation of an English thread nut on a
metric stud (or vice-versa) will not
properly secure the wheel to the hub.
Damaged studs may result in wheel
separation and possible injury.
*
[RE12100(ALL)01/95]
3. Replace the flat tire with the spare tire,
making sure that the air valve stem is facing
outward.
*
[RE12200(ALL)03/95]
4. Reinstall the lug nuts, tightening until the
wheel is snug against the hub. The beveled
edges on the lug nuts face inward. Do not
fully tighten the lug nuts until you lower the
vehicle. If you do, you could force the
vehicle off the jack.
*
[RE12300(ALL)01/95]
5. Lower the vehicle by turning the jack handle
counterclockwise.
*
[RE12400(ALL)01/95]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration. As soon as possible, have your
dealer or a qualified service technician check
the lug nuts for proper torque specifications.
File:12fcret.ex
Update:Mon Jan 22 16:01:15 1996
ProCarManuals.com

232 %
*
[RE14100(ALL)03/95]
Anti-Theft Wheel Lug Nuts (If equipped)
[RE14200(ALL)03/95]
If your vehicle has this feature, one of the lug
nuts on each wheel lock must be removed and
replaced with a special key. The key and
registration card are attached to the lug wrench
and stored with the spare tire. If you lose the
key, send the registration card to the
manufacturer (not to the dealer) to get a
replacement key.
*
[RE14250(ALL)03/95]
NOTE: If entire lug wrench/lug nut key
assembly is lost, see your nearest Ford
or Lincoln-Mercury dealer who has
access to a master set of keys.
[RE14275(ALL)11/94]
DO NOT USE THE KEY WITH AN IMPACT
WRENCH.
[RE14300(ALL)04/95]
quarter page art:0010357-B
The anti-theft lug nut and key
[RE14350( T)02/95]
one third page art:0000398-A
The anti-theft lug nut and key (SHO only)
File:12fcret.ex
Update:Mon Jan 22 16:01:15 1996
ProCarManuals.com

295
*
[SV28950(ALL)05/95]
q
Put the chains on the front tires tightly with
the ends held down securely. Retighten the
chains after driving 1/2 mile (1 km). Follow
the chain manufacturer's instructions.
*
[SV28975(ALL)05/95]
q
Do not drive faster than 30 mph (50 km/h)
or the chain manufacturer's recommended
speed limit, whichever is lower. Avoid
bumps, holes and sharp turns. If you can
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[SV29025(ALL)11/94]
q
Tire chains may affect vehicle handling. Drive
carefully and avoid hard braking.
*
[SV29050(ALL)11/94]
q
Do not use chains on temporary spare tires.
They may damage the vehicle and the tire.
*
[SV29150(ALL)05/94]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%*
[SV29160(ALL)04/95]
Cleaning the Wheels
*
[SV29170(ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[SV29180(ALL)09/95]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

Index 375
Steering, power............. 201
Steering wheel
horn................. 119
locking................ 59
speed controls............ 120
tilting................ 119
Storage compartments
cargo area.............. 160
cargo net.............. 161
center console............ 156
locking storage............ 161
Storing your vehicle........... 331
Sunroof (moon roof)........... 144
Sun visor................ 154
Supplemental air bag readiness light.... 77
Supplemental Restraint System (SRS).... 23
T
Tachometer................ 84
Tail lamps, cleaning........... 108
Temperature control (see Climate control) . . 93
Tether anchor installation
(see Child restraints).......... 43
Tilt steering wheel........... 119
Tires.................. 288
changing............... 222
checking the pressure......... 288
cleaning............... 295
inspection and maintenance...... 288
replacing............... 291
rotating............... 290
snow tires and chains......... 294
spare tire.............. 222
storing your vehicle.......... 333
tire grades.............. 292
treadwear.............. 293
wear bands............. 291
Towing a trailer (see Trailer towing) . . . 211
