FORD TAURUS 1997 Owner's Guide

CHILDPROOF DOOR LOCKS
When these locks are set, the rear doors cannot be
opened from the inside. The rear doors can be
opened from the outside when the doors are
unlocked.
Move lock control up
to engage the lock.
Move control down to
disengage childproof
locks.
CONSOLE
If your vehicle is
equipped with a floor
mounted gearshift, it
will have a full console
with the following
features:
²cup holders (push to
open)
Controls and features
32
ProCarManuals.com

²coin holder and
utility bin
²cassette/CD storage
²cellular phone (if
equipped)
²ashtray (push to
open)
The release for the utility compartment is on the
front of the console, just below the armrest. Press
and release at the ridges to open.
Controls and features
33
ProCarManuals.com

If your vehicle is
equipped with a
cellular phone, press
the latch release
located on the driver's
side edge of the
console lid to access
the phone.
If your vehicle is
equipped with the
column shift, it has a
center console in the
center front seating
position.
The center console has the same features as the full
console. To open the storage compartment, raise the
armrest and pull the strap on the seat up and
toward the front of the vehicle. The cupholders in
the center console can be removed for cleaning.
Cellular phone
Refer to the cellular phone user's manual for
instruction on operation.
Controls and features
34
ProCarManuals.com

CONSOLE
If your vehicle is
equipped with a floor
mounted gearshift, it
will have a full console
with the following
features:
²cup holders (push to
open)
²coin holder and
utility bin
²cassette/CD storage
Seating and safety restraints
35
ProCarManuals.com

²ashtray (push to
open)
The release for the utility compartment is on the
front of the console, just below the armrest. Press
and release at the ridges to open.
If your vehicle is
equipped with the
column shift, it has a
center console in the
center front seating
position.
The center console has the same features as the full
console. To open the storage compartment, raise the
armrest and pull the strap on the seat up and
toward the front of the vehicle. The cupholders in
the center console can be removed for cleaning.
POSITIVE RETENTION FLOOR MAT
(IF EQUIPPED)
Position the floor mat so that the eyelet is over the
pointed end of the retention post and rotate forward
to lock in. Make sure the mat does not interfere with
the operation of the accelerator and brake pedal. To
remove the floor mat, reverse the installation
procedure.
Seating and safety restraints
36
ProCarManuals.com

OPENING THE TRUNK WITH REMOTE
CONTROL (IF EQUIPPED)
Press the remote
release control on the
instrument panel to the
left of the steering
wheel.
LIFTGATE (WAGON ONLY)
You can open the
entire liftgate or just
the liftgate window. To
open the entire liftgate,
press the release
button hidden under
the exterior trim panel
just above the license
plate.
You must lock the liftgate with the key or power
lock control; it does not lock automatically.
The window locks when the liftgate is locked. To
open the window, make sure the liftgate and window
are unlocked, then press the outside lock cylinder.
The window can only be opened from the outside.
To prevent any damage to the liftgate and window,
close them completely before driving.
Seating and safety restraints
37
ProCarManuals.com

STORAGE COMPARTMENT (WAGON ONLY)
Your vehicle comes
equipped with a
storage compartment
in the floor of the
cargo area. An
additional
compartment is in the
rear trim panel on the
right. Always put the
load you are carrying as far forward as possible.
CARGO NET (IF EQUIPPED)
The cargo net secures
lightweight objects in
the cargo area. Attach
the net to the anchors
provided. Do not put
more than 22 kg (50
lbs.) in the net. This
net is not designed to
restrain objects during
a collision.
CARGO COVER (WAGON - IF EQUIPPED)
You can cover the rear
compartment by
fastening the cover
into the pockets in the
trim panel (make sure
the cover is right side
up so it unrolls from
the top), then pulling
and hooking the cover
into the pockets into the trim panel.
REWINDING THE SLIDING SHADE
If the shade is damaged or loses its spring tension
from excessive use, manual rewinding of the shade
may be necessary. The following procedure is a
two-person operation:
Seating and safety restraints
38
ProCarManuals.com

1. Remove the shade from the mounting brackets by
detaching the safety clip and pressure fit plastic
knobs from either side of the shade.
2.Wrap the vinyl around the tube twice by twisting
the tube away from you. Tuck the edged of the vinyl
end cap with each wrap.
3. Fold the vinyl toward the center, making sure the
edges clear the end cap slots. Use tape or a rubber
band to hold the vinyl on the left side of the tube..
4. Push in the right end cap (marked R) about 6 mm
(1/4 inch) to disengage the clutch and hold in while
turning the tube toward you fourteen times.
5. Let go of the right end cap and unfold the vinyl.
Place the vinyl into the end cap slots.
6. Place the shade back into the vehicle.
The cover may cause injury in a sudden stop
or accident if it is not securely installed.
LUGGAGE RACK (WAGON ONLY)
The rear crossbar can be adjusted to fit the item
being carried. The front crossbar does not move. No
more than 44 kg (100 lbs.) can be loaded on the
luggage rack.
To adjust the luggage
rack, loosen the
adjusting levers by
pushing them toward
the front of the
vehicle, then slide the
crossbar forward and
lock the adjusting
levers by pulling them
toward the back of the vehicle.
Seating and safety restraints
39
ProCarManuals.com

KEYLESS ENTRY SYSTEM (IF EQUIPPED)
You can lock or unlock
the vehicle doors
without using a key.
See alsoRemote entry system (if equipped)in this
chapter.
The computer code that operates the keyless system
is located on your owner's wallet card found in the
glove compartment.
Illuminated entry system:
²turns on the interior lights for approximately 25
seconds and
²lights up the keypad controls for five seconds.
Do not push the control keypad with any hard object
that could damage the controls.
Programming your own entry code
This code does not replace the permanent code from
the dealership.
To program your own code:
1. Select five digits for your personal code.
2. Enter the permanent code that the dealership
gave you.
3. Within five seconds,
press 1/2.
4. Within five seconds of pressing 1/2, enter your
personal code, pressing each digit within five
seconds of the previous digit.
You can now use either code. The system
remembers only one personal code at a time.
To erase your personal code:
1. Enter the original permanent code.
1
23
45678
90
1
23
45678
90
Seating and safety restraints
40
ProCarManuals.com

2. Press 1/2 within five
seconds of step one.
3. Wait six seconds.
For maximum security, do not set a code that
presents the numbers in sequential order or uses the
same button five times.
Unlocking the doors with the keyless entry
system
The driver's door must be unlocked before any
other. If more than five seconds pass between
pressing numbers, enter the code again. The system
has shut down if the keypad light is out. If the
keyless entry system does not work, use the key or
remote entry transmitter(s).
1. To unlock the driver's door, enter one of the two
codes. After pressing the fifth number, the driver's
door unlocks.
2. To unlock the
passenger's door(s) and
liftgate (wagon), press
the 3/4 button within
five seconds of unlocking the driver's door.
3. To unlock the trunk
or liftgate (wagon),
enter the five-digit
factory code, then
press the 5/6 button within five seconds.
Locking the doors with the keyless entry
system
To lock all the doors,
press 7/8 and 9/0 at the
same time. It is not
necessary to first enter
the keypad code.
1
23
45678
90
1
23
45678
90
1
23
45678
90
1
23
45678
90
Seating and safety restraints
41
