High Beam Light
*
[LG07300( ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
[LG07400( ALL)05/92]
one inch art:0010125-A% [LG08300( BC )07/93]
Check Gauges Warning Light (if equipped)
[LG08310( BC )03/93]
one inch art:0010128-D*
[LG08400( BC )06/94]
This light will come on when the key is in the
ON position and the:
[LG08500( BC )04/89]
q
engine coolant temperature gauge is high, or
[LG08600( BC )04/89]
q
engine oil pressure gauge is low, or
[LG08700( BC )05/95]
q
when the fuel tank has reached empty
reserve.
[LG08825( BC )03/90]
This light serves as a reminder for you to check
the engine coolant temperature gauge, the
engine oil pressure gauge or the fuel gauge. It
will come on if there is a condition that needs
your attention.
[LG08850( BC )07/93]
SeeEngine Coolant Temperature Gauge, Engine Oil
Pressure Gauge,orFuel Gaugein this chapter for
more information.
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

69 % [LG16220( ALL)05/94]
Battery Voltage Gauge (If Equipped)
*
[LG16225( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG16230( ALL)05/94]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
(when the engine is off, or idling at a low
speed), the pointer may move toward the lower
end of the NORMAL band.
*
[LG16260( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
[LG16285( BC )05/95]
one third page art:0010655-D
Battery voltage gauge
%*
[LG16300( ALL)05/94]
Engine Oil Pressure Gauge
[LG16500( ALL)05/94]
This gauge indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. With the
engine running, the pointer should move into
the NORMAL band. If the pointer drops below
the NORMAL band while the engine is running,
you have lost oil pressure and continued
operation will cause severe engine damage.
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

70 [LG16550( BC )05/95]
one third page art:0011146-BEngine oil pressure gauge
*
[LG16600( ALL)03/95]
If you lose engine oil pressure:
*
[LG16700( ALL)01/95]
1. Pull off the road as soon as safely possible.
*
[LG16800( ALL)04/95]
2. Shut off the engine immediately or severe
engine damage could result.
[LG16900( ALL)05/94]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, see theEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your car should be on level ground.
[LG17000( ALL)05/94]
4. If the level is low, add oil as necessary
before you start the engine again. Do not
overfill. Do not operate the engine if the
pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
[LG17200( ALL)05/94]
For more information about adding oil, see
Engine Oil Recommendationsin the Index.
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

312 Index
Emergency brake (parking brake)..... 174
Emission control system,
catalytic converter........... 280
Engine
check engine warning light....... 63
does not start.............. 49
fuel injected engine, starting....... 47
fuel pump shut-off switch........ 53
preparing to start............ 47
service points............. 227
starting................. 48
starting after a collision......... 53
storing your vehicle.......... 289
Engine block heater............ 50
Engine coolant
checking and adding......... 240
checking hoses............ 241
disposal............... 243
low coolant warning light........ 72
preparing for storage......... 290
proper solution............ 242
recovery reservoir........... 240
refill capacities............ 285
specifications............. 287
Engine coolant temperature gauge
description............... 66
mechanical............... 66
Engine fan............... 224
Engine oil
changing oil and oil filter....... 239
checking and adding......... 238
dipstick............... 238
disposal............... 240
engine oil pressure gauge........ 69
filter, specifications.......... 286
refill capacities............ 285
specifications............. 287
synthetic oil............. 237
ªbreak-inº oils............. 5
viscosity............... 237
