checking oil FORD THUNDERBIRD 1997 10.G Owners Manual

19 [IS13550( BC )04/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, seeEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your vehicle should be on level
ground.
[IS13600( BC )03/96]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the light is on, regardless of the oil level.
Contact your nearest dealer for service as
soon as possible.
*
[IS13700( BC )03/96]
For more information about adding oil, see
Adding engine oilin theMaintenance and Care
chapter of this guide.
%*
[IS13750( BC )04/96]
Low Fuel Light
[IS13800( BC )04/96]
This light comes on when your fuel gauge
indicates approximately 1/8 to 1/16 of a tank.
Your vehicle must be turned to ON for this light
to come on. This light will either flicker or glow
steadily.
[IS13850( BC )04/96]
one inch art:0000116-C
The low fuel light
File:03rcisb.ex
Update:Fri Jun 7 14:35:00 1996

202 %
*
[MC06500( ALL)01/96]
Checking and Adding Engine Oil
*
[MC06600( ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC06700( ALL)01/96]
Checking the engine oil level:
*
[MC06800( ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC06900( BCGV)01/96]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[MC07100( ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07200( ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07300( ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[MC07400( BC )03/96]
one inch art:0011218-A
Engine oil dipstick Ð 4.6 liter engines
[MC07600(MBC )12/95]
one inch art:0000970-A
Engine oil dipstick Ð 3.8 liter engines
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

294 Index
Engine oil............... 201
changing oil and oil filter....... 203
checking and adding......... 202
dipstick............... 202
disposal............... 204
engine oil pressure warning light..... 18
filter, specifications.......... 247
refill capacities............ 248
specifications...........201, 249
synthetic oil............. 201
ªbreak-inº oils............. 6
viscosity............... 201
Entry system
illuminated............... 88
remote................. 95
Exhaust fumes............. 143
Extended Service Plan, Ford........ 4
F
Fan .................. 196
engine fan, avoiding injury....... 196
Federal Communications Commission.... 57
Flashers, hazard.............. 77
Flashing the lights............. 75
Flat tire................. 175
Floor mats................ 92
Fluid refill capacities........... 248
Ford Customer Assistance Center..... 257
Ford Dispute Settlement Board...... 258
Ford Extended Service Plan........ 4
Ford Motor Company of Canada..... 263
Ford of Canada Customer
Assistance Centre........... 263
Foreign registration........... 264
French owner guides, how to obtain.... 3
Fuel.................. 227
capacity............... 248
choosing the right fuel......... 227
filling your vehicle with fuel...... 226
filter, specifications.......... 247
File:rcixb.ex
Update:Thu May 30 11:06:50 1996

Index 305
Trailer towing............. 158
calculating maximum
trailer weight........... 158
safety chains............. 160
tips................. 161
trailer brakes............. 161
trailer lamps............. 161
Transmission
automatic operation.......... 151
fluid, checking and adding
(automatic)............ 217
fluid, refill capacities......... 248
lubricant specifications........ 249
Transmission control switch....... 154
Transmitter (see Remote entry)....... 95
Trip odometer.............. 23
Trunk
remote release lever........... 72
using the remote entry system to open . . 96
Tune-up specifications (VECI)...... 235
Turn signal................ 74
indicator lights............. 17
lever................. 74
U
Used engine oil, disposal........ 204
V
Vanity mirror............... 86
Variable interval wipers.......... 75
VECI (Vehicle Emission Control Information)
decal................ 235
Vehicle Identification Number (VIN) . . . 258
Vehicle loading
automatic transmissions........ 157
calculating the load.......... 157
understanding loading information . . . 156
File:rcixb.ex
Update:Thu May 30 11:06:50 1996
