16 %
*
[IS09000( ALL)03/96]
High Beam Light
*
[IS09100( ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
[IS09200( ALL)04/96]
one inch art:0010125-B
The high beam light
%*
[IS11050( BC )12/95]
Service Engine Soon Warning Light
%*
[IS11100( ALL)05/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
[IS11350( BC )05/96]
one inch art:0000282-B
The service engine soon warning light
%*
[IS12100( BC )04/96]
Anti-Theft Alarm Light (If equipped)
[IS12150(MBC )04/96]
one inch art:0001389-A
Anti-theft alarm light
File:03rcisb.ex
Update:Fri Jun 7 14:35:00 1996
Page 69 of 301
![FORD THUNDERBIRD 1997 10.G Owners Manual 67
%*
[CF15810( ALL)03/96]
The Interior and Exterior Lights
%*
[CF15820( ALL)03/96]
Daytime Running Light System
*
[CF15900( ALL)03/96]
(Canadian vehicles only)
*
[CF16000( ALL)03/96]
The Daytime Runn FORD THUNDERBIRD 1997 10.G Owners Manual 67
%*
[CF15810( ALL)03/96]
The Interior and Exterior Lights
%*
[CF15820( ALL)03/96]
Daytime Running Light System
*
[CF15900( ALL)03/96]
(Canadian vehicles only)
*
[CF16000( ALL)03/96]
The Daytime Runn](/img/11/5383/w960_5383-68.png)
67
%*
[CF15810( ALL)03/96]
The Interior and Exterior Lights
%*
[CF15820( ALL)03/96]
Daytime Running Light System
*
[CF15900( ALL)03/96]
(Canadian vehicles only)
*
[CF16000( ALL)03/96]
The Daytime Running Light (DRL) system turns
the high beam headlamps on, with a reduced
light output, when:
*
[CF16100( ALL)03/96]
q
The headlamp system is in the OFF position,
and
*
[CF16200( ALL)01/96]
q
The vehicle is running, and
*
[CF16300( ALL)03/96]
q
The vehicle has a fully released parking
brake.
*
[CF16400( BCGV)12/95]
NOTE: If you have a vehicle with an
automatic lighting system, the DRL
system is active until the automatic
system turns on the headlamps.
[CF16500( ALL)04/96]
NOTE: The high beam indicator will not turn
on in the flash-to-pass mode during
nighttime driving.
*
[CF16600( ALL)01/96]
NOTE: You may notice that the lights flicker
when the vehicle is turned on or off.
This is a normal condition.
*
[CF16700( ALL)03/96]
RWARNING
The Daytime Running Light (DRL) system
will not illuminate the tail lamps and
parking lamps. Turn on your headlamps
at dusk. Failure to do so may result in a
collision.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996
Page 70 of 301
![FORD THUNDERBIRD 1997 10.G Owners Manual 68 %
*
[CF16800( ALL)03/96]
Turning On the Exterior Lights
*
[CF17100( BCGV)03/96]
To turn on the headlamps, parking lamps, side
markers, license plate lamps and tail lamps, use
the rotary knob that i FORD THUNDERBIRD 1997 10.G Owners Manual 68 %
*
[CF16800( ALL)03/96]
Turning On the Exterior Lights
*
[CF17100( BCGV)03/96]
To turn on the headlamps, parking lamps, side
markers, license plate lamps and tail lamps, use
the rotary knob that i](/img/11/5383/w960_5383-69.png)
68 %
*
[CF16800( ALL)03/96]
Turning On the Exterior Lights
*
[CF17100( BCGV)03/96]
To turn on the headlamps, parking lamps, side
markers, license plate lamps and tail lamps, use
the rotary knob that is to the left of the steering
wheel.
[CF17300( BC )05/96]
half page art:0010195-E
The knob that controls the headlamps and parking lamps
(shown with autolamp feature Ð other models similar)
[CF17501( ALL)04/96]
To turn on the parking lamps, license plate
lamps, tail lamps and marker lamps, move the
knob to the first position.
[CF17550( ALL)04/96]
To turn on the headlamps, parking lamps,
license plate lamps, tail lamps and marker
lamps, move the knob to the second position.
*
[CF17600( ALL)04/96]
For more information about how the high beams
work, see the high beam section later in this
chapter.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996
Page 71 of 301
![FORD THUNDERBIRD 1997 10.G Owners Manual 69 [CF17700( BCGV)12/95]
Chime for headlamps on
*
[CF17800( ALL)12/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until FORD THUNDERBIRD 1997 10.G Owners Manual 69 [CF17700( BCGV)12/95]
Chime for headlamps on
*
[CF17800( ALL)12/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until](/img/11/5383/w960_5383-70.png)
69 [CF17700( BCGV)12/95]
Chime for headlamps on
*
[CF17800( ALL)12/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
%*
[CF18000( BC )01/96]
Setting the Autolamp Delay System (If
equipped)
*
[CF18100( BCGV)01/96]
The autolamp sets the headlamps to turn on and
off automatically. You can use the autolamp to:
*
[CF18200( BCGV)01/96]
q
turn on the lamps automatically at night
*
[CF18300( BCGV)01/96]
q
turn off the lamps automatically during
daylight
*
[CF18400( BCGV)01/96]
q
keep the lamps on for up to three minutes
after you turn the key to OFF.
[CF18600( BC )12/95]
one third page art:0010199-D
