93
*
[CF53700(MBC )01/96]
q
disable the starting circuit to prevent the
vehicle from being started
[CF53900(MBC )12/95]
To tell the difference between a PANIC alarm
and a triggered Anti-theft alarm:
[CF54000(MBC )12/95]
q
only the Anti-Theft alarm will cause the
alarm indicator lamp (located in the
instrument cluster) to flash on and off.
[CF54100(MBC )12/95]
q
only the Anti-Theft alarm will disable the
start circuit so that the vehicle can not be
started.
[CF54200(MBC )05/96]
q
the Anti-Theft alarm will not stop by pushing
the PANIC control on the Remote Entry
transmitter.
*
[CF54300(MBC )12/95]
For more information on the PANIC alarm, see
Remote Entry Systemin the Index.
%*
[CF54400(MBC )03/96]
Arming the system
[CF54500(MBC )12/95]
To arm the system, do the following steps in
sequence:
*
[CF54600(MBC )01/96]
1. Remove the key from the ignition. The hood
must be closed to arm the system.
[CF54700( BC )03/96]
At this point, the anti-theft system automatically
monitors the ignition keylock cylinder. If the
lock cylinder is forcibly removed, the anti-theft
alarm system will trigger. To arm the remaining
portion of the system, follow steps 2-4.
*
[CF54800(MBC )05/96]
2. Open any door. The alarm indicator light
will start flashing to remind you to arm the
system.
[CF54900(MBC )05/96]
3. Lock the doors by using the power door
lock switch or by pressing the remote entry
transmitter LOCK control.
[CF55000(MBC )12/95]
The alarm indicator will now glow steadily.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996

198 %
*
[MC03300( ALL)02/96]
Opening the Hood
[MC03400( ALL)12/95]
1. Inside the vehicle, pull the hood release
located under the lower left corner of the
instrument panel.
[MC03600( ALL)12/95]
2. Go around to the front of the vehicle, and
release the auxiliary catch that is located
under the front edge of the hood at the
center of the vehicle.
[MC03800( BC )12/95]
one third page art:0010537-A
The auxiliary catch under the front edge of the hood
*
[MC04100( BCGV)12/95]
3. Lift the hood until the counterbalanced
hinges hold it open.
*
[MC04300( BCGV)12/95]
Whenever you close the hood, latch it securely.
*
[MC04400( ALL)12/95]
NOTE: Apply lubricant to the hood latch at
six-month intervals to maintain smooth
and trouble-free operation.
%
*
[MC04500( ALL)03/96]
Engine Compartment
*
[MC04600(MBC )01/96]
Your vehicle has one of these types of engines:
[MC04800(MBC )02/96]
q
a 3.8 liter SFI engine
[MC04900(MBC )12/95]
q
a 4.6 liter SFI engine
*
[MC05000(MBC )03/96]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

202 %
*
[MC06500( ALL)01/96]
Checking and Adding Engine Oil
*
[MC06600( ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC06700( ALL)01/96]
Checking the engine oil level:
*
[MC06800( ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC06900( BCGV)01/96]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[MC07100( ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07200( ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07300( ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[MC07400( BC )03/96]
one inch art:0011218-A
Engine oil dipstick Ð 4.6 liter engines
[MC07600(MBC )12/95]
one inch art:0000970-A
Engine oil dipstick Ð 3.8 liter engines
File:11rcmcb.ex
Update:Thu May 30 11:02:59 1996

Index 301
Power steering
dipstick............... 214
driving with power steering...... 150
fluid, checking and adding...... 214
fluid, refill capacity.......... 248
fluid, specifications.......... 249
servicing............... 150
Prop rod, hood............. 198
R
Radio (see Electronic sound systems).... 25
Rear axle
lubricant specification......... 249
refill capacity............. 248
Rear window............... 88
defroster................ 66
Refill capacities for fluids........ 248
Relays................. 165
Remote control, trunk........... 72
Remote entry system........... 95
locking/unlocking doors........ 96
opening the trunk........... 96
panic alarm.............. 97
replacement/additional transmitters . . . 98
replacing the batteries.......... 97
Restraints, safety (see Safety restraints)
adult................ 103
child................. 118
head.................. 99
infant................ 118
Roadside assistance........... 255
Roadside emergencies.......... 165
Rotating the tires............ 222
File:rcixb.ex
Update:Thu May 30 11:06:50 1996
