Controls and Features
105
[CF27800(ALL)01/96]
Setting the autolamp
[CF27901(ALL)10/96]
The headlamps can be adjusted to turn on earlier or later in the
day according to the amount of outside light reaching the
sensor inside the mirror. To turn the headlamps on using
Autolamp, perform the following procedure.
[CF28001(ALL)10/96]1.
Turn the ignition switch to the ON position and place the
Autolamp slide knob to OFF.
[CF28011(ALL)10/96]2.
Press and hold the MODE switch throughout the procedure.
The MODE switch is located in a hole on the bottom left
side of the mirror. It can be accessed with a paper clip or
similar object.
[CF28021(ALL)10/96]3.
Slowly slide the Autolamp slide knob to the right until the
headlamps turn on. To have the headlamps turn on earlier,
go to step 4. To have the headlamps turn on later, go to step
5.
[CF28031(ALL)10/96]4.
Slowly slide the Autolamp slide knob to the left until the
headlamps turn off. Go to step 6.
[CF28041(ALL)10/96]5.
Slowly slide the Autolamp slide knob to the right until the
headlamps turn off. Go to step 6.
[CF28051(ALL)10/96]6.
Release the MODE switch. The new setting will be stored in
permanent memory. If further change is required, you must
repeat the procedure from the beginning.
% [CF28700(ALL)01/96]
Front Dome Lamp
[CF28800(ALL)01/96]
Front dome lamp, rear cargo and second row reading lamp may
be turned on and off using the dimmer switch.
[CF28900(ALL)09/96]
The front dome lamp is located in the overhead console
between the driver and front passenger seats.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Seating and Safety Restraints
169
*
[SS19500(ALL)05/96]
RWARNING
Do not place objects or mount equipment on or near the
air bag cover that may come in contact with an inflating
air bag. Failure to follow this instruction may increase
the risk of personal injury in the event of a collision.
*
[SS19600(ALL)05/96]
For further information about the proper mounting of
equipment in the front seat of this vehicle, please refer to Ford's
brochure entitledSome Important Information About Air Bag
Supplemental Restraint Systemwhich can be obtained by calling
Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.
*
[SS19700(ALL)05/96]
For additional important safety information on the proper use of
seat belts, child seats, and infant seats, please read the other
sections of this chapter of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats for Children.
%*
[SS19800(ALL)05/96]
How Does the Air Bag Supplemental Restraint System
Work?
*
[SS19900(ALL)05/96]
The Air Bag Supplemental Restraint System consists of the
driver and passenger air bags, impact sensors, a system
diagnostic module, a readiness light and tone, and the electrical
wiring which connects the components.
[SS20000(ALL)04/96]
The driver air bag is in the center of the steering wheel and is
indicated by the letters ªSRS.º The right front passenger seat air
bag is in the upper right-hand section of the instrument panel
ledge above the glove compartment. The letters ªSRSº appear
there. Both air bags are designed to stay out of sight until they
are activated.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

170
*
[SS20100(ALL)05/96]
RWARNING
Do not attempt to service, repair, or modify the Air Bag
Supplemental Restraint System or its fuses. See your
Ford or Lincoln-Mercury dealer.
[SS20200(ALL)04/96]
If a collision occurs, the sensors sense the severity of the impact
and activates the air bags if necessary. The air bag system is
designed to deploy in frontal and front-angled collisions more
severe than hitting a parked vehicle (of similar size and weight)
head-on at about 28 mph (45 km/h). Because the system senses
the crash severity rather than vehicle speed, some frontal
collisions at speeds above 28 mph (45 km/h) will not inflate the
air bag.
*
[SS20300(ALL)05/96]
When the sensors activate the system, the air bags inflate
rapidly, filling with non-toxic nitrogen gas in a fraction of a
second. Immediately after inflation, the air bags deflate by
releasing the nitrogen gas through vent holes. The whole
process takes place in a matter of seconds.
*
[SS20400(ALL)07/96]
RWARNING
Several air bag system components get hot after inflation.
Do not touch them after inflation.
