Compass display (if equipped)
The compass reading may be affected when you drive near large
buildings, bridges, power lines and powerful broadcast antenna. Magnetic
or metallic objects placed in, on or near the vehicle may also affect
compass accuracy.
Usually, when something affects the compass readings, the compass will
correct itself after a few days of operating your vehicle in normal
conditions. If the compass still appears to be inaccurate, a manual
calibration may be necessary. Refer toCompass zone/calibration
adjustment.
Most geographic areas (zones) have a magnetic north compass point that
varies slightly from the northerly direction on maps. This variation is four
degrees between adjacent zones and will become noticeable as the
vehicle crosses multiple zones. A correct zone setting will eliminate this
error. Refer toCompass zone/calibration adjustment.
Compass zone/calibration adjustment
Perform this adjustment in an open area free from steel structures and
high voltage lines.
For optimum calibration, turn off all electrical accessories (heater/air
conditioning, wipers, etc.) and make sure all vehicle doors are shut.
1. Turn ignition to the ON position.
2. Start the engine.
3. Determine your magnetic zone by
referring to the zone map.
4. From Info menu, select the
Compass/Outside Temperature
function.
1
2
3
4
5
6
7891011121314 15
Instrumentation
23

WINDSHIELD WIPER/WASHER CONTROLS
Rotate the windshield wiper control
to the desired interval, low or high
speed position.
The bars of varying length are for
intermittent wipers. When in this
position rotate the control upward
for fast intervals and downward for
slow intervals.
Push (tap) the end of the stalk
briefly for a single swipe (no wash).
Push and hold for three swipes with
wash. Push and hold for a longer
wash (up to ten seconds).
Mist Function
To operate the Mist function of the
windshield wipers, push and release
the windshield washer control
quickly. The wipers will cycle one or
two times.
Rear window wiper/washer controls
For rear wiper operation, rotate the
rear window wiper and washer
control to the desired position.
Select:
INT 2 Ð One second interval rear
wiper.
INT1ÐTensecond interval rear
wiper.
OFF Ð Rear wiper and washer off.
For rear wash cycle, rotate (and hold as desired) the rear wiper/washer
control to either
position.
From either position, the control will automatically return to the INT2 or
OFF position.
Controls and features
86

Seats ..........................................119
child safety seats ....................149
cleaning ............................252,253
SecuriLock passive anti-theft
system ..........................114,115,116
Servicing your vehicle ..............203
Spark plugs,
specifications ......................254,257
Specification chart,
lubricants ............................256,257
Speed control ..............................82
Speedometer ...............................15
Starting your vehicle .........161,163
jump starting ..........................197
Steering wheel
tilting .........................................88
Tachometer .................................14
Tilt steering wheel ......................88
Tires ......................191,226,227,228
changing ....................191,192,194
checking the pressure ............228
replacing ..................................229
rotating ....................................228
snow tires and chains ............230
tire grades ...............................227
treadwear ................................227
Towing ................................175,228
trailer towing ..........................175
wrecker ....................................202
Traction control ...................81,167
active light ..................................8off light ........................................9
Transaxle
automatic operation ...............169
fluid, refill capacities ..............255
lubricant specifications ..........257
Transmission
fluid, checking and adding
(automatic) .............................218
lubricant specifications ..........256
Trip odometer .............................16
Turn signal ..........................9,13,85
Vehicle dimensions ...................257
Vehicle Identification
Number (VIN) ...........................259
Vehicle loading ..........................173
Ventilating your vehicle ...........164
Warning chimes ...........................13
Warning lights (see Lights) .........8
Washer fluid ..............................211
Water, Driving through .............173
Windows
power .........................................89
rear wiper/washer .....................86
Windshield washer
fluid and wipers
checking and adding fluid .....211
checking and cleaning .....225,226
liftgate reservoir .....................211
operation ...................................86
replacing wiper blades ...........226
Wrecker towing .........................202
