CD player GMC C-SERIES 1999 Owners Manual

yellowblue
2-51
A. Left Side Window Defogger
B. Main Lamps Switch
C. Vent
D. Instrument Cluster
E. Warning Lights
F. Heated Mirror Switch (Option)
G. Exhaust Brake Switch (Option)
H. Marker/Clearance Lamps Switch (Option)
I. Audio System or Storage Area
J. VentsK. Glove Box
L. Right Side Window Defogger
M. Storage Tray/Cassette Player
N. Comfort Controls
O. Air Brake Controls (If Equipped)
P. Ashtray
Q. Air Vent Controls
R. Convenience Center Fuse Panel
S. Hourmeter (Option)
ProCarManuals.com

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-5 Air Conditioning
3
-5 Heating
3
-6 Defogging
3
-6 Ventilation System
3
-7 Audio Systems
3
-7 Setting the Clock3
-8 AM/FM Stereo
3
-10 Remote Cassette Tape Player (If Equipped)
3
-10 Understanding Radio Reception
3
-11 Tips About Your Audio System
3
-12 Care of Your Cassette Tape Player
3
-12 Fixed Mast Antenna
ProCarManuals.com

yellowblue
3-10 Remote Cassette Tape Player (If Equipped)
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this player.
To load a cassette tape, hold the cassette with the tape to
the right. Then, insert the cassette tape. Tape direction is
displayed by the lighted arrow. To change the tape
direction, press the FF button.
Once the tape is playing, use the control knobs for
VOLUME, BAL, FAD, BAS and TRE just as you do
for the radio.
REW: Press the left arrow to rapidly reverse the tape.
Press FF to stop reversing the tape.FF: Press the right arrow to rapidly advance the tape.
Press REW to stop forwarding the tape.
PROGRAM: An arrow will light on the display to
show which side of the tape is playing.
EJ: Press this button to remove the tape.
There is a space provided with your remote cassette tape
player to keep cassette tapes in.
Understanding Radio Reception
AM
The range for most AM stations is greater than for FM,
especially at night. The longer range, however, can
cause stations to interfere with each other. AM can pick
up noise from things like storms and power lines. Try
reducing the treble to reduce this noise if you ever get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km). Tall
buildings or hills can interfere with FM signals, causing
the sound to come and go.
ProCarManuals.com

yellowblue
3-11 Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be loud
and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.
To help avoid hearing loss or damage:

Adjust the volume control to the lowest setting.

Increase volume slowly until you hear comfortably
and clearly.NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delco Electronics radio or
other systems, and even damage them. Your
vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check Federal rules
covering mobile radio and telephone units.
ProCarManuals.com

yellowblue
3-12 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. If you notice a reduction in sound
quality, try a known good cassette to see if it is the tape
or the tape player at fault. If this other cassette has no
improvement in sound quality, clean the tape player.
The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealership (GM Part No. 12344789).
When using a scrubbing action, non
-abrasive cleaning
cassette, it is normal for the cassette to eject because
your unit is equipped with a cut tape detection feature
and a cleaning cassette may appear as a broken tape.
If the cleaning cassette ejects, insert the cassette at least
three times to ensure thorough cleaning.You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
Cassettes are subject to wear and the sound quality may
degrade over time. Always make sure the cassette tape
is in good condition before you have your tape
player serviced.
Fixed Mast Antenna
The fixed mast antenna can withstand most vehicle
washes without being damaged. If the mast should ever
become slightly bent, you can straighten it out by hand.
If the mast is badly bent, as it might be by vandals, you
should replace it.
Check every once in a while to be sure the mast is still
tightened to the cowl.
ProCarManuals.com

9-yellowblue
9-1
Section 9 Index
A
ir
Brake System Warning Light 2-59 . . . . . . . . . . . . . . . . . . . .
Cleaner 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaner Filter 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compressor Filter 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conditioning 3-5, 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conditioning Refrigerants 6-77 . . . . . . . . . . . . . . . . . . . . . .
Dryer 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter Restriction Indicator 6-17 . . . . . . . . . . . . . . . . . . . . . .
Suspension 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Brake Systems 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Dryer 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alcohol Injector 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moisture Ejector 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alcohol Injector 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-51 . . . . . . . . . . . . . . . . . . . . . .
AM-FM Stereo 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AM-FM Stereo with Remote Cassette Tape Player 3-10 . . . . .
Antenna 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake System Warning Light 2-61, 4-7 . . . . . . . . . . . . . . . .
Appearance Care 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care Materials 6-66 . . . . . . . . . . . . . . . . . . . . . . . Apply Park Brake Warning Light 2
-60 . . . . . . . . . . . . . . . . . .
Ashtray 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Transmission Fluid 6-18 . . . . . . . . . . . . . . . . . . . . .
Automatic Transmission Shift Indicator Check 7-25 . . . . . . . .
Auxiliary Power Jacks 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle, Rear 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Airshift Control 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential Lock Control 2-41 . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacity 6-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Motor 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tw o-Speed Electric Shift Control 2-17 . . . . . . . . . . . . . . . .
Towing 5-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery, Jump Starting 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake
Adjustment 6
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Brake Systems 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Parking Brake 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric/Hydraulic Parking Brake 2-25 . . . . . . . . . . . . . . . .
Electric/Hydraulic Parking Brake Fluid 6-36 . . . . . . . . . . . .
Exhaust 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-2
Brake (Continued)
Four-Wheel and Six-Wheel Drum 6-33 . . . . . . . . . . . . . . .
Four-Wheel Disc 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Systems 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Propshaft Brake Burnish Procedure 2-24 . . . . . . . . . . . . . . .
Releasing Air-Operated Parking Brakes 5-15 . . . . . . . . . . .
Replacing System Parts 6-35 . . . . . . . . . . . . . . . . . . . . . . . .
System Check 7-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Lights 2-57 . . . . . . . . . . . . . . . . . . . . . . . .
Brake, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-74 . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-29, 2-30 , 4-27 . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-12 . . . . . . . . . . . . . . . . . . . . . . . .
Center Passenger Position 1-22 . . . . . . . . . . . . . . . . . . . . . . . .
Certification/Tire Label 4-28, 6-67 . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Light 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . .
Chassis Lubrication 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Gages Light 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-36 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . Child Restraints 1
-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in the Center Seat Position 1-31 . . . . . . . . . . . . . .
Top Strap 1-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breaker Block, Instrument Panel 6-69 . . . . . . . . . . . . .
Cleaner, Air 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning
Fabric 6
-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-59 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-63 . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belts 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-62 . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch Pedal Free Travel 6-37 . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Component Box 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connections, Trailer 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank 5-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank 5-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-7
New Vehicle ªBreak-Inº 2-5 . . . . . . . . . . . . . . . . . . . . . . . . .
Night Vision 4-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Noise Control System 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off-Road Recovery 4-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil, Engine 6-13, 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-23 . . . . . . . . . . . . . . . . . . . . . . .
Owner Publications Order Form 8-9 . . . . . . . . . . . . . . . . . . . .
Owner Publications, Ordering 8-8 . . . . . . . . . . . . . . . . . . . . . .
Paint Spotting, Chemical 6-65 . . . . . . . . . . . . . . . . . . . . . . . .
Parking
Brake 2
-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake Check 7-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake Indicator Light 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . .
Over Things That Burn 2-29 . . . . . . . . . . . . . . . . . . . . . . . .
Passing 4-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power
Door Locks 2
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Option Fuses 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Fluid 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Take-Off (PTO) 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Pregnancy, Use of Safety Belts 1-21 . . . . . . . . . . . . . . . . . . . .
Pressure Caps 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Problems on the Road 5-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Publications, Service and Owner 8-8 . . . . . . . . . . . . . . . . . . . .
Radiator 5-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Pressure Cap 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Shutters 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio Reception 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Axle 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Airshift Control 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential Lock Control 2-41 . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacity 6-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Motor 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tw o-Speed Electric Shift Control 2-17 . . . . . . . . . . . . . . . .
Towing 5-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank, Coolant 5-22 . . . . . . . . . . . . . . . . . . . . . . . . . .
Refrigerants, Air Conditioning 6-77 . . . . . . . . . . . . . . . . . . . .
Releasing Air Operated Parking Brake 5-15 . . . . . . . . . . . . . .
Remote Cassette Tape Player 3-10 . . . . . . . . . . . . . . . . . . . . . .
Replacement Wheels 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Safety Belts 1-36 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reporting Safety Defects 8-6, 8-7 . . . . . . . . . . . . . . . . . . . . . .
Restraints
Checking 1
-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Parts After a Crash 1-36 . . . . . . . . . . . . . . . . . . .
System Check 7-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Right Passenger Position 1-21 . . . . . . . . . . . . . . . . . . . . . . . . .
Roadside Assistance 8-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rocking Your Vehicle 5-38 . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-9
Storage, Vehicle 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stuck: In Sand, Mud, Ice or Snow 5-37 . . . . . . . . . . . . . . . . . .
Sun Visors 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank, Coolant 5-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank Pressure Cap 6-22 . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols, Vehicle v. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tape Player Care 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt Steering Wheel 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Loading 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat 5-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dual Tire Operation 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation Check 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rims and Wheels 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Replacement 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . .
When It's Time for New 6-51 . . . . . . . . . . . . . . . . . . . . . . .
Top Strap 1-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque, Wheel Nut 6-52 , 6-74 . . . . . . . . . . . . . . . . . . . . . . . .
Towing Your Vehicle 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Trailer Brake Hand Control Valve 2
-39 . . . . . . . . . . . . . . . . . .
Trailer Connections 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission
Automatic 2
-20, 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Transmission External Filter 6-19 . . . . . . . . . . .
Double-Clutching 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filters 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid, Automatic 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacity 6-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual 2-22, 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual, Fluid 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Third Gear Hold 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Clutch 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TTY Users 8-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn and Lane Change Indicator 2-33 . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-65 . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle
Control 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6
-67 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com
