2-24 Hydraulic Brakes
If your vehicle has hydraulic brakes, it has a parking
brake lever or an electric/hydraulic parking brake. The
lever is below the instrument panel to the left of the
steering column. The electric/hydraulic parking brake
knob is to the right of the steering column.
Your vehicle may also be equipped with an automatic
transmission which has a shift lever. This lever will have
a PARK (P) position on the shift indicator. When the
PARK (P) position is selected with the shift lever, the
parking brake is automatically applied.
Propshaft Brake Burnish Procedure
It is recommended that the propshaft-mounted parking
brake be burnished as part of the new vehicle break
-in.
The parking brake will work best after it has been
burnished following these instructions.
Make 10 stops, using the parking brake hand lever, from
20 mph (32 km/h) about 2 1/2 miles (4 km) apart.
Between stops, drive the vehicle at 20 mph (32 km/h).
Lever Operated Parking Brake
To apply the parking brake,
pull the lever all the way up.
The PARK BRAKE light
will come on when the
parking brake is applied.
Then shift the transmission
to NEUTRAL (N) or
PARK (P).
The vehicle must be stopped when applying the parking
brake, except while burnishing the parking brake linings
(see ªPropshaft Brake Burnish Procedureº in the Index).
You can easily adjust the parking brake by turning the
knob on the lever. Turning it clockwise makes the brake
grip more tightly. It will also make the lever seem harder
to pull up. Turning the knob counterclockwise makes the
parking brake apply less firmly. Adjust the parking
brake only when the lever is down (released).
ProCarManuals.com

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-5 Air Conditioning
3
-5 Heating
3
-6 Defogging
3
-6 Ventilation System
3
-7 Audio Systems
3
-7 Setting the Clock3
-8 AM/FM Stereo
3
-10 Remote Cassette Tape Player (If Equipped)
3
-10 Understanding Radio Reception
3
-11 Tips About Your Audio System
3
-12 Care of Your Cassette Tape Player
3
-12 Fixed Mast Antenna
ProCarManuals.com

yellowblue
3-7
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defogger will work far better, reducing the
chance of fogging the inside of your windows.

When you enter a vehicle in cold weather, turn the
blower fan to high for a few moments before driving
off. This helps clear the intake ducts of snow and
moisture and reduces the chance of fogging the
inside of your windows.

Keep the air path under the seats clear of objects.
This helps air to circulate throughout your vehicle.
The air vents are located in the center and on the sides of
your instrument panel. You can move the vents to direct
the flow of air or close the vents altogether. When you
close a vent, it will increase the flow of air coming out
of any vents that are open.
If your vehicle does not have air conditioning, there are
air vent controls located below the instrument panel.Audio Systems
Your Delco Electronics audio system has been designed
to operate easily and give years of listening pleasure.
You will get the most enjoyment out of it if you acquaint
yourself with it first. Find out what your Delco
Electronics system can do and how to operate all its
controls, to be sure you're getting the most out of the
advanced engineering that went into it.
Setting the Clock
While pressing the SET button, press the UP button
until the correct hour appears on the display and the
DOWN button until the correct minute appears on the
display. If you press and hold the UP/DOWN button,
hours or minutes will advance rapidly.
ProCarManuals.com

yellowblue
3-8 AM-FM Stereo
Playing the Radio
ON
-OFF: Press the round button to turn the radio on.
Press it again to turn the radio off.
VOLUME: Slide the VOLUME lever to the right to
increase volume or to the left to decrease volume.
CALL: Press this button to display the clock for
a few seconds when the radio is on. To change what is
normally shown on the display (station or time), press
this button and the SET button.Finding a Station
AM/FM: Press this button to switch between AM and
FM. The display shows your selection.
TUNE: Press UP to increase the frequency of a radio
station and DOWN to decrease the frequency of a radio
station. If you press and hold the UP or DOWN button
for more than half a second, the radio will tune rapidly
in that direction.
SEEK: Press SEEK to tune the radio to the next higher
station and stay there.
SCAN: Press SCAN to listen to the next higher
radio station for a few seconds. Press SCAN again
to stop scanning.
PUSHBUTTONS: The six numbered pushbuttons
let you return to your favorite stations. You can set up to
12 stations (six AM and six FM). Just:
1. Turn the radio on.
2. Press AM/FM to select a band.
3. Tune in the desired station.
4. Press SET. (SET will appear on the display and will
blink for about eight seconds.)
ProCarManuals.com

yellowblue
4-11 Steering in Emergencies
There are times when steering can be more effective
than braking. For example, you come over a hill and
find a truck stopped in your lane, or a car suddenly pulls
out from nowhere, or a child darts out from between
parked cars and stops right in front of you. You can
avoid these problems by braking
-- if you can stop in
time. But sometimes you can't; there isn't room. That's
the time for evasive action
-- steering around
the problem.
In emergencies like these, first apply your brakes
-- but
unless you have anti
-lock, not enough to lock your
wheels. (See ªBraking in Emergenciesº earlier in this
section.) It is better to remove as much speed as you can
from a possible collision. Then steer around the
problem, to the left or right depending on the space
available. If your vehicle has anti
-lock brakes, you don't
need to release the brakes to maintain steering control.
An emergency like this requires close attention and a
quick decision. If you are holding the steering wheel at
the recommended 9 and 3 o'clock positions, you may be
able to turn it just enough to miss the object without
removing either hand. But you must act fast, steering
precisely. The more sharply you turn, the greater the
chance of a skid, a rollover or a ªjackknifeº with a
tractor
-trailer. Just as quickly straighten the wheel once
you have avoided the object.
The fact that such emergency situations are always
possible is a good reason to practice defensive driving at
all times and wear safety belts properly.
ProCarManuals.com

yellowblue
5-17
3. Remove the rubber
cap from the rear of
the chamber.
4. Put the release stud, nut and flat washer into
the chamber.
5. Turn the stud clockwise a quarter of a turn.6. Using a wrench, turn the
stud nut clockwise
several turns to release
the brakes. Follow the
same procedure to
release the other brake.
7. At the repair facility, apply air pressure of at least
70 psi (480 kPa) to the brake chambers, either from
an external air supply or the vehicle's air system.
8. Turn the stud nut counterclockwise several turns.
Remove the stud from the chamber.
9. Put the stud into the side of the chamber, and replace
the rubber cap.
ProCarManuals.com

yellowblue
5-25 How to Add Coolant to the Radiator
1. You can remove the
radiator pressure cap
when the cooling
system, including the
radiator pressure cap and
upper radiator hose, is
no longer hot.
Turn the pressure cap slowly counterclockwise until
it first stops. (Don't press down while turning the
pressure cap.)
If you hear a hiss, wait for that to stop. A hiss means
there is still some pressure left.
2. Then keep turning
the pressure cap, but
now push down as you
turn it. Remove the
pressure cap.
3. Fill the radiator with the
proper DEX
-COOL

coolant mixture, up to
the base of the filler
neck. (See ªEngine
Coolantº in the Index
for more information
about the proper
coolant mixture.)
ProCarManuals.com

yellowblue
5-31
1. You can remove the coolant surge tank pressure cap
when the cooling system, including the coolant surge
tank pressure cap and upper radiator hose, is no
longer hot. Turn the pressure cap slowly
counterclockwise until it first stops. (Don't press
down while turning the pressure cap.)
If you hear a hiss, wait for that to stop. A hiss means
there is still some pressure left.2. Then keep turning the cap, but now push down as
you turn it. Remove the pressure cap.
ProCarManuals.com

yellowblue
6-7
Filling Your Tank
CAUTION:
Fuel vapor is highly flammable. It burns
violently, and that can cause very bad injuries.
Don't smoke if you're near gasoline or diesel fuel,
or if you're refueling your vehicle. Keep sparks,
flames and smoking materials away from
gasoline or diesel fuel.
The fuel cap can be on either or both sides of your
vehicle depending on option content.
To take off the cap, turn it slowly to the left
(counterclockwise).
CAUTION:
Gasoline Engine Vehicles: If you get gasoline on
you and then something ignites it, you could be
badly burned. Gasoline can spray out on you if
you open the fuel filler cap too quickly. This
spray can happen if your tank is nearly full, and
is more likely in hot weather. Open the fuel filler
cap slowly and wait for any ªhissº noise to stop.
Then unscrew the cap all the way.
When you put the cap back on, turn it to the right until
it is tight.
ProCarManuals.com

yellowblue
6-46 Automatic Ether Injection System (Option)
If your diesel engine vehicle
has this feature, the ether
cylinder is on the upper
right rear side of the engine
compartment.
To change an empty ether cylinder, follow these steps.
1. Loosen the 5/16 inch screw head on the
cylinder
-to-bracket clamp.
2. Spread the clamp apart.3. Clean any dirt from the neck of the cylinder and the
top of the valve before you take out the cylinder.
4. Check the inside of the valve for any foreign matter.
Clean the valve as necessary.
5. Cover the valve to protect it from dirt and take out
the cylinder.
6. Install a new gasket whenever you take out the
cylinder. Use only one gasket and spread a light film
of clean oil on it before installation.
7. Put in the new cylinder. Turn it clockwise until it just
starts to contact the gasket.
8. Tighten the cylinder another half turn (180 degrees).
Don't over
-tighten.
9. Retighten the cylinder clamp.
