GMC ENVOY 1999 Owners Manual

yellowblue
2-41
There is a delay in the transition between the daytime
and nighttime operation of the Daytime Running Lamps
(DRL) and the automatic headlamp systems so that
driving under bridges or bright overhead street lights
does not affect the system. The DRL and automatic
headlamp system will only be affected when the light
sensor sees a change in lighting lasting longer than
the delay.
To idle your vehicle with the automatic headlamp
system off, set the parking brake while the ignition is
off. Then start your vehicle. The automatic headlamp
system will stay off until you release the parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Lamps On Reminder
A reminder chime will sound when your headlamps or
parking lamps are manually turned on and your ignition
is in OFF, LOCK or ACCESSORY. To disable the
chime, turn the thumbwheel all the way down. In the
automatic mode, the headlamps turn off once the
ignition key is in OFF.
Daytime Running Lamps (If Equipped)
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
The DRL system will make your high
-beam headlamps
come on at reduced brightness when:

the ignition is on,

the headlamp switch is in automatic headlamp mode,

the light sensor detects daytime light,

the transmission is not in PARK (P), and

the parking brake is released.
When the DRL are on, only your high
-beam headlamps
will be on. The taillamps, sidemarker and other lamps
won't be on. The instrument panel won't be lit up either.
When it begins to get dark, the high
-beam headlamps
will automatically switch from DRL to the regular
low
-beam headlamps.
To idle your vehicle with the DRL off, put your
vehicle's transmission in PARK (P). The DRL will stay
off until you shift out of PARK (P).
As with any vehicle, you should turn on the regular
headlamp system when you need it.
ProCarManuals.com

yellowblue
2-42 Fog Lamps
Use your fog lamps for better vision in foggy or misty
conditions. Your low
-beam headlamps or your parking
lamps must be on for your fog lamps to work.
The fog lamp switch is on the instrument panel under
the lamps switch. Press the switch to turn the fog lamps
on. Press the switch again to turn them off. A light will
glow in the switch when the fog lamps are on.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high beams go off, the
fog lamps will come on again.
Interior Lamps
Brightness Control
Turn the thumbwheel next to the headlamp switch up to
make your instrument panel lights brighter. Turn the
switch all the way up to turn on the interior lamps.
Illuminated Entry
Your vehicle is equipped with an illuminated
entry feature.
When the doors are opened, the dome lamps will come
on if the DOME OVERRIDE button is in the ªoutº
position. When all the doors are closed, or the front door
handles are lifted and released, the lamps will stay on
for a short period of time and will turn off automatically.
If you use your keyless entry transmitter to unlock the
vehicle, the interior lights will come on for a short time
whether or not the DOME OVERRIDE button is in the
ªoutº position.
ProCarManuals.com

yellowblue
2-43 Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition. If the DOME
OVERRIDE button is in the ªoutº position, these lights
will stay on for a short period of time and then will
go out.
Front Reading Lamps
Press the button near each lamp on the overhead console
to turn the reading lamps on and off. The lamps can be
swiveled to point in the desired direction.
If you have the mini console, press the lens on each
lamp to turn it on or off.
Dome Lamps
The dome lamps will come on when you open the doors.
You can also turn the dome lamps on by rotating the
thumbwheel, located next to the parking/headlamps
knob, all the way up. In this position, the dome lamps
will remain on whether the doors are opened or closed.You can use the DOME OVERRIDE button, located
below the parking/headlamp knob, to set the dome
lamps to come on automatically when the doors are
opened, or to remain off. To turn the lamps off, press the
button once into the ªinº position. With the button in
this position, the dome lamps will remain off when the
doors are open. To return the lamps to automatic
operation, press the button again and return it to the
ªoutº position. With the button in this position, the dome
lamps will come on when you open the door. This will
override the illuminated entry feature, unless you use
your keyless entry transmitter to unlock the vehicle.
Battery Run-Down Protection
This feature shuts off the dome, courtesy, vanity,
reading, glove box and underhood lamps if they are left
on for more than 20 minutes when the ignition is off.
This will keep your battery from running down.
If the battery run
-down protection shuts off the interior
lamps, it may be necessary to do one of the following to
return to normal operation:

Shut off all lamps and close all doors, or

Turn the ignition key to RUN.
ProCarManuals.com

yellowblue
2-44
Mirrors
Electrochromic Day/Night Inside
Rearview Mirror
This mirror automatically changes to reduce glare from
headlamps behind you. A photocell on the back of the
mirror senses when it is becoming dark outside. Another
photocell built into the mirror surface senses when
headlamps are behind you.
At night, when the glare is too high, the mirror will
gradually darken to reduce glare (this change may take a
few seconds). The mirror will return to its clear daytime
state when the glare is reduced. The mirror will also
return to its clear daytime state when the vehicle is put
into REVERSE (R).
Press the AUTO button at the base of the mirror to turn
on the automatic feature. The button has an indicator
light to show it is on. Press the OFF button to turn the
automatic feature off.
Time Delay
The automatic mirror has a time delay feature which
prevents unnecessary switching from the night back to
the day position. This delay prevents rapid changing of
the mirror as you drive under lights and through traffic.
ProCarManuals.com

yellowblue
2-45
Cleaning the Photocells
Use a cotton swab and glass cleaner to clean the
photocells when necessary.
Power Remote Control Mirror
The control is located on the
driver's door armrest.
Move the upper control to the left or right to choose the
mirror, then press the arrows on the control pad to adjust
the mirror.
Convex Outside Mirror
A convex mirror's surface is curved so you can see more
from the driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right or left lane,
you could hit a vehicle. Check your inside mirror
or glance over your shoulder before
changing lanes.
Heated Outside Rearview Mirror
When you operate the rear window defogger, a defogger
also warms the heated driver's and passenger's outside
rearview mirrors to help clear them of ice, snow and
condensation. See ªRear Window Defoggerº in the
Index for more information.
Electrochromic Rearview Outside Mirror
Only the driver's side outside mirror will adjust for the
glare of headlamps behind you. See ªElectrochromic
Day/Night Inside Rearview Mirrorº earlier in
this section.
ProCarManuals.com

yellowblue
2-46 Power Folding Mirrors
Your vehicle is equipped with power folding mirrors.
This feature can be helpful when taking your vehicle
through a car wash or through narrow spaces.
To fold the mirrors in, press the blank side of the switch
located on the driver's side door panel near the window.
To have the mirrors return to their normal position, press
the side of the switch with the graphic on it. The switch
will stay in whichever position it is placed.
If at any time your mirrors become disengaged, fold the
mirrors out manually and then use the switch to fold the
mirrors in and out. This will assure that the power fold
unit in your mirrors is properly engaged.
Storage Compartments
Glove Box
To open your glove box, lift the lever on the front of the
glove box and lower the door. The glove box should not
be open while driving.
Overhead Console
The overhead console includes reading lamps, a driver
information system, a storage compartment for
sunglasses and a universal transmitter.
ProCarManuals.com

yellowblue
2-47
Reading Lamps
Press the button near each
lamp to turn the reading
lamps on and off.
The lamps can also be swiveled to point in the
desired direction.Driver Information System
This system displays the outside air temperature,
compass direction and trip information in the
overhead console.
US/MET: The US/MET (United States/metric) button
allows you to switch the display between the English
and metric system.
ProCarManuals.com

yellowblue
2-48
MODE: The MODE button can be used to toggle
between three modes of operation: OFF, COMP/TEMP
and TRIP.
COMP/TEMP: The display provides the outside
temperature and one of eight compass readings to
indicate the direction the vehicle is facing.
Before you turn on the ignition and move the vehicle,
the temperature indicated will be the last outside
temperature recorded with the ignition on. If the outside
temperature is 37
F (3
C) or lower, the display will
toggle between the word ICE and the current
temperature every eight seconds. This is a warning to
the driver that road conditions may be icy, and that
appropriate precautions should be taken.
The compass is self
-calibrating, so it does not need to be
manually set. However, if C (Calibration) is displayed,
the compass will need to be calibrated. You may also
place the compass in a noncalibrated mode by pressing
and holding the MODE and US/MET buttons
simultaneously while in the COMP/TEMP mode. After
about 10 seconds, the compass will display C and you
can release the buttons. Drive the vehicle in a complete
360
circle three times at a speed of less than 5 mph
(8 km/h), and the compass will function normally. Once
the calibration is complete, the display will return to a
compass reading.
Variance is the difference between magnetic north and
geographic north. In some areas, the difference between
the two can be great enough to cause false compass
readings. If this happens, follow these instructions to set
the variance for your particular location:
1. Find your location on the zone map earlier in this
section. Note your zone number.
2. Press and hold both the MODE and the US/MET
buttons in the COMP/TEMP mode.
ProCarManuals.com

yellowblue
2-49
3. After five seconds, the compass will acknowledge
the variation mode by displaying the current zone
number. When it does, release both buttons.
4. Press US/MET until your zone number appears on
the display.
5. Press MODE to enter your zone number. Your
variance is now set and the display will return to the
COMP/TEMP mode.
TRIP: Once in the TRIP mode, pressing the MODE
button will step you through the following
TRIP functions:

AVG ECON: The average fuel economy since the
last reset is displayed.

INST ECON: Instantaneous fuel economy for the
last second of driving is displayed.
RANGE: The display indicates the estimated
distance that can be travelled with the remaining fuel
in the tank, based on the fuel economy for the last
few hours of driving.

FUEL USED: The fuel used since the last reset
is displayed.

AVG SPEED: The average speed since the last reset
is displayed.
To reset the trip computer, press the MODE and US/MET
buttons simultaneously for at least two seconds. All
functions will be displayed for half a second once the
system is reset. Reset can only be performed in the AVG
ECON, FUEL USED and AVG SPEED modes. All three
modes are reset simultaneously.
ProCarManuals.com

yellowblue
2-50
Sunglasses Storage Compartment
The console has a sunglasses storage compartment.
Center Floor Console
Your vehicle has a console between the two front
bucket seats.
To open the console, pull up on the console cover.
The console has two cupholders and a storage tray,
including a change holder, for the front seat passenger
and driver to use.
ProCarManuals.com
