2-48
To idle your vehicle with the DRL off, put your
vehicle's transmission in PARK (P). The DRL will stay
off until you shift out of PARK (P).
The following does not apply to vehicles sold in Canada.
When necessary, you may turn off the automatic
headlamp system and the Daytime Running Lamps
(DRL) feature by following the steps below:
1. Turn the ignition to RUN.
2. Press the dome override button four times within six
seconds. After the fourth press of the button, a chime
will sound informing you that the system is off.
3. To return to the automatic mode, push the dome
override button four times within six seconds (the
chime will sound), or turn the ignition to LOCK and
then to RUN again.
As with any vehicle, you should turn on the regular
headlamp system when you need it.Fog Lamps
Use your fog lamps for better vision in foggy or misty
conditions. Your ignition must be in RUN for your fog
lamps to work.
The fog lamp button is
located on the instrument
panel to the right of the
exterior lamps knob. Press
the button to turn the fog
lamps on. Press the button
again to turn them off. A
light will glow near the
button when the fog lamps
are on.
Fog lamps will go off whenever your high
-beam
headlamps come on. When the high beams go off, the
fog lamps will come on again.

2-73
The main components of your instrument panel are the following:
A. Exterior Lamp Controls
B. Air Vents
C. Turn Signal/Multifunction Lever
D. Comfort Control Steering Wheel Controls
(If Equipped)
E. Instrument Panel Cluster
F. Audio Steering Wheel Controls (If Equipped)
G. Ignition Switch
H. Audio System
I. Comfort ControlsJ. Hood Release
K. Driver Information Center (DIC) Steering Wheel
Controls (If Equipped)
L. Transfer Case Controls (If Equipped)
M. Shift Lever
N. Lighter
O. Accessory Power Outlets
P. Parking Brake
Q. Rear Window Washer/Wiper
R. Rear Window Defogger
S. Glove Box

3-3
Passenger's Side Temperature Lever
The lever on the right side of the climate control panel
is used to adjust the air temperature on the passenger's
side, independent of the temperature set by the driver.
Slide the lever upward to raise the temperature. Slide
the lever downward to lower the temperature.
This lever also adjusts the temperature to the rear
seat outlets.
Mode Knob
The knob on the right side of the control panel has
several settings to control the direction of airflow:
(Panel): Selecting panel mode will deliver air to
the instrument panel outlets.
(Bi-Level): Selecting bi-level mode will deliver
warmer air to the floor and cooler air to the instrument
panel outlets.
(Floor): Selecting floor mode will deliver air to
the floor outlets and some air to the defroster and side
window vents.
(Defog): Selecting defog will deliver air to the
floor, windshield outlets and side window vents.
(Defrost): Selecting this setting directs most of the
air through the defroster and side window vents. Some
of the air also goes to the floor ducts.
Mode Buttons
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to limit odors entering your
vehicle and for maximum air conditioning performance
in hot weather. Recirculation cannot be used in floor,
blend or defrost modes. An indicator on the button will
light up, flash three times and turn off when
recirculation is selected in these modes.
While in the recirculation mode the windows may fog
when the weather is cold and damp. To clear the fog,
select either the blend or defrost mode and increase the
fan speed.
(Air Conditioning): Press this button to turn the
air conditioning compressor on and off. The system will
cool and dehumidify the air inside the vehicle when the
air conditioning compressor is engaged.

3-7
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to limit odors entering your
vehicle and for maximum air conditioning performance
in hot weather. Press this button again to allow outside
air to enter the vehicle.
If you select recirculation while in defrost, defog or
floor, the light on the button will flash and go out to let
you know this is not allowed. This is to prevent fogging.
When the weather is cool or damp, operating the system
in recirculation for extended periods of time may cause
fogging of the vehicle's windows. To clear the fog,
select either defog or FRONT defrost. Be sure A/C OFF
is not selected to allow the air conditioning compressor
to run automatically and help dehumidify the air.
(Air Conditioning): Press this button to turn the
air conditioning compressor on and off. When air
conditioning is selected or in AUTO mode, the system
will run the air conditioning automatically to cool and
dehumidify the air entering the vehicle. If you select
A/C OFF while in FRONT defrost, the A/C OFF text
will flash to let you know this is not allowed. This is to
prevent fogging.
FRONT (Defrost): Press this button to defrost the
windshield. The system will automatically control the
fan speed if you select defrost from AUTO. If the
outside temperature is 40
F (4
C) or warmer, your air
conditioning compressor will automatically run to help
dehumidify the air and dry the windshield.
Air Conditioning
On hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
If your vehicle has the manual system, for quick
cool
-down on very hot days, use the airflow from the
panel outlets, press recirculation and air conditioning
with the temperature control in the blue area. If this max
air conditioning setting is used for long periods of time,
the air in your vehicle may become too cold and dry.
For normal cooling on hot days, use air conditioning
without recirculation with the temperature control in the
blue area.

3-9 Rear Window Defogger
The lines you see on the rear window warm the glass.
Press the button to start warming your window. A light
will glow in the button while the defogger is working.
If your vehicle is equipped with heated mirrors, this
button will activate them.
After 10 minutes it will turn off by itself, or press the
button during the heating cycle to turn it off. If you need
additional warming time, push the button again.Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the defogger grid. The repairs wouldn't be
covered by your warranty.

6-59
Mini Fuses Usage
1 ECAS
2 Passenger's Side
High
-Beam Headlamp
3 Passenger's Side
Low
-Beam Headlamp
4 Back
-Up Trailer Lamps
5 Driver's Side
High
-Beam Headlamp
6 Driver's Side
Low
-Beam Headlamp
7 WASH
8ATC
9 Windshield Wipers
10 Powertrain Control Module B
11 Fog Lamps
12 ST/LP
13 Cigarette Lighter
14 COILSMini Fuses Usage
15 RIDE
16 TBD
-- Ignition 1
17 Crank
18 Air Bag
19 ELEK Brake
20 Cooling Fan
21 Horn
22 Ignition E
23 ETC
24 Instrument Panel Cluster,
Driver Information Center
25 Automatic Shift Lock
Control System
26 ENG 1
27 Back
-Up
28 Powertrain Control Module 1
29 Oxygen Sensor
