When your vehicle has a at tire, use the following
example as a guide to assist you in the placement
of wheel blocks.
The following information will tell you how to use
the jack and change a tire.Removing the Spare Tire and Tools
The jacking equipment needed to remove the
spare tire is stored under the rear seat. To release
the jack from its holder, turn the knob on the
jack counterclockwise to lower the jack head.
SeeRear Seat Operation on page 18for more
information.
466

3. Insert the socket
end of the
extension (C)
on a 45 degree
angle downward
into the hoist drive
shaft hole.
It is exposed when the rear gate is open and
is just above the rear bumper. Be sure the
socket end of the extension (C) connects
to the hoist shaft.
4. Turn the wheel wrench counterclockwise to
lower the spare tire. Keep turning the wheel
wrench until the spare tire can be pulled
out from under the vehicle.
If the spare tire does not lower to the ground,
the secondary latch is engaged causing
the tire not to lower. SeeSecondary Latch
System on page 475for more information.
468

2. Using the wheel
wrench, loosen all
the wheel nuts.
Do not remove
them yet.
3. Turn the jack adjusting knob clockwise by
hand to raise the jack lift head.
4. Place the handle, extension, and wheel
wrench onto the jack.A. Front Frame/Rear Axle
B. Jack
C. Handle
D. Extension
E. Wheel Wrench
5. Place the jack in the appropriate position
nearest the at tire.
Front PositionRear Position
470

{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it
is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall.
To help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising
the vehicle.6. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off
the ground so there is enough room for
the spare tire to t.
471

{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
10. Put the nuts on by hand. Make sure the
rounded end is toward the wheel.
11. Tighten each nut by hand until the wheel is
held against the hub. If a nut cannot be
turned by hand, use the wheel wrench and
see your dealer as soon as possible.12. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
473

2. If visible, rst try to tighten the cable by
turning the wheel wrench clockwise until
you hear two clicks or feel it skip twice.
You cannot overtighten the cable.
3. Loosen the cable by turning the wheel wrench
counterclockwise three or four turns.
4. Repeat this procedure at least two times.
If the spare tire lowers to the ground,
continue with Step 2 ofRemoving the Spare
Tire and Tools on page 466.
5. Turn the wrench counterclockwise until
approximately 6 inches (15 cm) of cable
is exposed.
6. Attach the jack handle, extension(s) and the
wheel wrench to the jack and place it under
the vehicle towards the front of the rear
bumper. Position the center lift point of the
jack under the center of the spare tire.
7. Turn the wrench clockwise to raise the jack
until it lifts the end tting.
476

8. Continue raising the jack until the spare tire
stops moving upward and is held rmly in
place. The secondary latch has released and
the spare tire is balancing on the jack.
9. Lower the jack by turning the wheel wrench
counterclockwise. Keep lowering the jack
until the spare tire slides off the jack or
is hanging by the cable.
10. Disconnect the jack handle from the jack and
carefully remove the jack. Use one hand to
push against the spare while rmly pulling the
jack out from under the spare tire with the
other hand.
11. If the spare tire is
hanging from the
cable, insert
the socket end of
the extension
into the hoist shaft
hole on a 45 degree
angle downward.12. Be sure that the socket end of the extension
connects to the hoist shaft.
Turn the wheel wrench counterclockwise to
lower the spare the rest of the way.
477

13. Tilt the retainer at the end of the cable and pull
it through the wheel opening. Pull the tire out
from under the vehicle.
Notice:If you drive away before the spare tire
or secondary latch system cable has been
reinstalled, you could damage your vehicle.
Always reinstall this cable before driving your
vehicle.
14. Turn the wheel wrench clockwise to raise the
cable back up if the cable is hanging under
the vehicle.
Have the hoist assembly inspected as soon as
you can. You will not be able to store a spare
tire using the hoist assembly until it has been
repaired or replaced.Storing a Flat or Spare Tire and
Tools
{CAUTION:
Storing a jack, a tire, or other equipment
in the passenger compartment of the
vehicle could cause injury. In a sudden
stop or collision, loose equipment could
strike someone. Store all these in the
proper place.
478

3. Make sure the valve stem is pointed up and
to the rear.
4. Pull the retainer (D) through the wheel.
5. Put the socket end of the extension (C)
through the hole just above the rear bumper
at a 45 degree angle downward. Connect
the socket end of the extension to the hoist
shaft (B).
6. Raise the tire fully against the underside of
the vehicle. Continue turning the wheel
wrench (A) clockwise until you hear two clicks
or feel it skip twice. This indicates that the
tire is secure and the cable is tight. The spare
tire hoist cannot be overtightened.7. Make sure the tire is stored securely. Push,
pull (A), and then try to turn (B) the tire. If the
tire moves, use the wheel wrench and socket
end of the extension to tighten the cable.
8. Return the equipment to the proper location in
the vehicle as shown next.
480

A. Handle
B. Wheel Wrench
C. Instruction LabelD. Extension(s)
E. Knob
F. Wheel Blocks and Jack
1. Attach the handle (A), wheel wrench (B),
and extension (D) in the slots provided.
2. Roll up the instruction label (C) and return
to the slot in the tool kit.
3. Assemble the wheel blocks (F) to the jack.
4. Turn the knob (E) on the jack clockwise to
raise the jack head.
5. Return the rear seat to its proper position.
Spare Tire
Your vehicle, when new, had a fully-inated spare
tire. A spare tire may lose air over time, so check its
ination pressure regularly. SeeInation - Tire
Pressure on page 447andLoading Your Vehicle
on page 349for information regarding proper tire
ination and loading your vehicle. For instruction on
how to remove, install or store a spare tire, see
Removing the Flat Tire and Installing the Spare Tire
on page 469andStoring a Flat or Spare Tire and
Tools on page 478.
After installing the spare tire on your vehicle, you
should stop as soon as possible and make
sure the spare is correctly inated. Have the
damaged or at road tire repaired or replaced as
soon as you can and installed back onto your
vehicle. This way, a spare tire will be available
in case you need it again.
Do not mix tires and wheels of different sizes,
because they will not t. Keep your spare tire
and its wheel together.
