{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it
is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall.
To help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising
the vehicle.6. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off
the ground so there is enough room for
the spare tire to t.
471

{CAUTION:
The underbody-mounted spare tire needs
to be stored with the valve stem pointing
up. If the spare tire is stored with the
valve stem pointing downward, its
secondary latch will not work properly
and the spare tire could loosen and
suddenly fall from your vehicle. If this
happened when your vehicle was being
driven, the tire might contact a person or
another vehicle, causing injury and, of
course, damage to itself as well. Be sure
the underbody-mounted spare tire is
stored with its valve stem pointing up.
Notice:An aluminum wheel with a at tire
should always be stored under the vehicle with
the hoist. However, storing it that way for an
extended period could damage the wheel.
To avoid this, always stow the wheel properly
with the valve stem pointing up and have
the wheel repaired as soon as possible.Follow this diagram to store the
underbody-mounted at or spare tire.
A. Wheel Wrench
B. Hoist Shaft
C. Extension
D. Retainer
E. Spare or Flat Tire
(Valve Stem
Pointed Up)
1. Put the tire (E) on the ground at the rear of
the vehicle.
2. Remove the hubcap, if the vehicle has one,
from the at tire by tapping the backside of
the hubcap with the wheel wrench (A). Store in
a safe location until the at tire is repaired.
Once the tire is repaired, replace the hubcap.
479

3. Make sure the valve stem is pointed up and
to the rear.
4. Pull the retainer (D) through the wheel.
5. Put the socket end of the extension (C)
through the hole just above the rear bumper
at a 45 degree angle downward. Connect
the socket end of the extension to the hoist
shaft (B).
6. Raise the tire fully against the underside of
the vehicle. Continue turning the wheel
wrench (A) clockwise until you hear two clicks
or feel it skip twice. This indicates that the
tire is secure and the cable is tight. The spare
tire hoist cannot be overtightened.7. Make sure the tire is stored securely. Push,
pull (A), and then try to turn (B) the tire. If the
tire moves, use the wheel wrench and socket
end of the extension to tighten the cable.
8. Return the equipment to the proper location in
the vehicle as shown next.
480

Emergency Tow From a Public Roadway or
Highway:Tow to the nearest dealership for
warranty service or in the event of a
vehicle-disabling accident. Winch-out
assistance when the vehicle is mired in sand,
mud, or snow.
Flat Tire Change:Installation of your spare tire
in good condition will be covered at no charge.
The customer is responsible for the repair or
replacement of the tire if not covered by a
warrantable failure.
Jump Start:No-start occurrences which
require a battery jump start will be covered at
no charge.
Dealer Locator Service:Information on the
dealer nearest your location.
Trip Routing:Your Roadside Assistance
Representative can provide you with specic
information regarding this feature.
Trip Interruption Expense Benets:Your
Roadside Assistance Representative can
provide you with specic information regarding
this feature.
Additional Services for Canadian
Customers

Trip Routing Service:Upon Request,
Roadside Assistance will send you detailed,
computer-personalized maps, highlighting your
choice of either the most direct route or the
most scenic route to your destination,
anywhere in North America, along with any
helpful travel information we may have
pertaining to your trip. To request this service,
please call us toll-free at 1-800-268-6800.
We’ll make every attempt to send your
personalized trip routing as quickly as
possible, but it’s best to allow three weeks
before your planned departure date. Trip
routing requests will be limited to six per
calendar year.
