Cargo Tie Downs
Four cargo tie-downs are located in the rear
compartment of the vehicle. The tie-downs can be used
to secure small loads.
Sunroof
The vehicle may have a power sliding sunroof. To open
or close the sunroof, the ignition must be turned to
ON/RUN, ACC/ACCESSORY, or Retained Accessory
Power (RAP) must be active. SeeRetained Accessory
Power (RAP) on page 2-22.Press and release the back
of the control in the
overhead console to open
the sunroof. Press the front
of the control to close the
sunroof.
Once the sunroof is closed, press the forward side of the
control to open the sunroof to the vent position.
The sunroof has a sunshade which can be pulled forward
to block sun rays. If it is in the closed position, it will open
when the sunroof opens.
Do not keep the sunroof open for long periods of time
while the vehicle is not in use. Debris can collect in the
tracks, damage the sunroof operation and plug the water
draining system.
2-55

✍NOTES
2-56

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-6
Horn .............................................................3-6
Tilt Wheel.....................................................3-6
Turn Signal/Multifunction Lever.........................3-7
Turn and Lane-Change Signals........................3-7
Headlamp High/Low-Beam Changer..................3-8
Flash-to-Pass.................................................3-8
Windshield Wipers..........................................3-8
Windshield Washer.........................................3-9
Rear Window Wiper/Washer.............................3-9
Headlamp Washer........................................3-10
Cruise Control..............................................3-10
Headlamps..................................................3-13
Headlamps on Reminder................................3-14
Daytime Running Lamps (DRL).......................3-14
Automatic Headlamp System..........................3-14
Fog Lamps ..................................................3-15
Instrument Panel Brightness...........................3-16
Dome Lamps ...............................................3-16
Dome Lamp Override....................................3-16
Entry Lighting...............................................3-16Exit Lighting.................................................3-17
Reading Lamps............................................3-17
Electric Power Management...........................3-17
Battery Run-Down Protection..........................3-18
Accessory Power Outlet(s).............................3-18
Ashtray(s) and Cigarette Lighter......................3-19
Climate Controls............................................3-19
Dual Climate Control System..........................3-19
Dual Automatic Climate Control System...........3-22
Outlet Adjustment.........................................3-26
Rear Climate Control System.........................3-26
Warning Lights, Gages, and Indicators............3-27
Instrument Panel Cluster...............................
.3-28
Speedometer and Odometer...........................3-29
Trip Odometer..............................................3-29
Tachometer.................................................3-29
Safety Belt Reminders...................................3-30
Airbag Readiness Light..................................3-31
Passenger Airbag Status Indicator...................3-32
Charging System Light..................................3-33
Voltmeter Gage............................................3-34
Section 3 Instrument Panel
3-1

Brake System Warning Light..........................3-35
Antilock Brake System (ABS) Warning Light.....3-36
StabiliTrak
®Service Light...............................3-36
StabiliTrak®Indicator Light.............................3-37
Engine Coolant Temperature Gage..................3-37
Tire Pressure Light.......................................3-38
Malfunction Indicator Lamp.............................3-38
Oil Pressure Gage........................................3-42
Change Engine Oil Light................................3-43
Security Light...............................................3-43
Cruise Control Light......................................3-43
Reduced Engine Power Light.........................3-44
Highbeam On Light.......................................3-44
Service Four-Wheel Drive Warning Light..........3-44
Check Gages Warning Light...........................3-45
Gate Ajar Light.............................................3-45
Fuel Gage...................................................3-46
Low Fuel Warning Light.................................3-47
Check Gas Cap Light....................................3-47Driver Information Center (DIC).......................3-47
DIC Operation and Displays...........................3-48
DIC Warnings and Messages.........................3-51
DIC Vehicle Customization.............................3-56
Audio System(s).............................................3-62
Setting the Clock..........................................3-63
Radio(s)......................................................3-64
Using an MP3..............................................3-80
XM Radio Messages.....................................3-84
Navigation/Radio System...............................3-86
Bluetooth
®...................................................3-86
Rear Seat Entertainment (RSE) System...........3-96
Rear Seat Audio (RSA)................................3-109
Theft-Deterrent Feature................................3-110
Audio Steering Wheel Controls......................3-110
Radio Reception.........................................3-111
Fixed Mast Antenna....................................3-112
XM™ Satellite Radio Antenna System............3-112
Chime Level Adjustment...............................3-112
Section 3 Instrument Panel
3-2

✍NOTES
3-3

Instrument Panel Overview
3-4

The main components of the instrument panel are the following:
A.Headlamps on page 3-13.Dome Lamp Override
on page 3-16.Instrument Panel Brightness on
page 3-16.Fog Lamps on page 3-15(If Equipped).
B.Outlet Adjustment on page 3-26.
C.Turn Signal/Multifunction Lever on page 3-7.
D. OnStar
®and Audio Steering Wheel Controls.
SeeAudio Steering Wheel Controls on page 3-110.
E.Instrument Panel Cluster on page 3-28.
F.Audio Steering Wheel Controls on page 3-110.
G.Ignition Positions on page 2-21.
H.Audio System(s) on page 3-62.
I.Dual Climate Control System on page 3-19.
J.Hood Release on page 5-11.
K. Driver Information Center (DIC) Steering Wheel
Controls. SeeDriver Information Center (DIC)
on page 3-47.L. Transfer Case Controls. See “Automatic Transfer
Case” underFour-Wheel Drive on page 2-28.
M. Shift Lever and StabiliTrak
®(If Equipped) Button.
SeeShifting Into Park on page 2-34andStabiliTrak®
System on page 4-6.
N. Lighter. SeeAshtray(s) and Cigarette Lighter on
page 3-19.
O.Accessory Power Outlet(s) on page 3-18.
P.Parking Brake on page 2-33.
Q. Rear Window Washer/Wiper. SeeWindshield
Washer on page 3-9.
R. Rear Window Defogger. SeeDual Climate Control
System on page 3-19andDual Automatic Climate
Control System on page 3-22.
S.Glove Box on page 2-51.
3-5

Hazard Warning Flashers
|(Hazard Warning Flasher):Press this button
located on top of the steering column, to make the front
and rear turn signal lamps ash on and off. This warns
others that you are having trouble. Press again to
turn the ashers off.
When the hazard warning ashers are on, the vehicle’s
turn signals will not work.
Horn
To sound the horn, press the horn symbols on the
steering wheel pad.
Tilt Wheel
The tilt lever is on the
outboard side of the
steering column, under the
turn signal lever.
Hold the steering wheel and pull the lever toward you to
change the position, then release the lever to lock.
Do not adjust the steering wheel while driving.
3-6

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane Change Signals
23Headlamp High/Low-Beam Changer
Flash-to-Pass Feature
NWindshield Wipers
JWindshield Washer
ICruise Control
Information for these features is on the pages following.
Turn and Lane-Change Signals
An arrow on the instrument
panel cluster ashes in the
direction of the turn or
lane change.
Move the lever all the way up or down to signal a turn.
Raise or lower the lever until the arrow starts to ash
to signal a lane change. Hold it there until the lane
change is complete.
The lever returns to its starting position when it is
released.
If after signaling a turn or lane change the arrows ash
rapidly or do not come on, a signal bulb could be
burned out.
Have the bulbs replaced. If the bulb is not burned out,
check the fuse. SeeFuses and Circuit Breakers on
page 5-113.
3-7

If the vehicle has a trailer towing option with added
wiring for the trailer lamps, a turn signal asher is used.
With this asher installed, the signal indicator ashes
even if a turn signal bulb is burned out. Check the front
and rear turn signal lamps regularly to make sure
they are working.
Turn Signal On Chime
A chime sounds if the turn signal has been on 3/4 of a
mile (1.2 km). Move the turn signal lever to off.
Headlamp High/Low-Beam Changer
To change the headlamps from low to high beam,
push the lever toward the instrument panel. To return to
low-beam headlamps, pull the multifunction lever
toward you. Then release it.
When the high beams are
on, this indicator light on
the instrument panel
cluster will also be on.
Flash-to-Pass
This feature lets high-beam headlamps be used to
signal to a driver in front of you that you want to pass.
It works even if the headlamps are in the automatic
position.
To use it, pull the turn signal lever toward you, then
release it.
If the headlamps are in the automatic position or on low
beam, the high-beam headlamps turn on. They will stay
on as long as the lever is held toward you. The high-beam
indicator on the instrument panel cluster comes on.
Release the lever to return to normal operation.
Windshield Wipers
8(Mist):Turn the band to mist, for a single wiping
cycle. Hold it there until the wipers start, then release it.
The wipers will stop after one wipe. Hold the band on
mist longer if more wipe cycles are needed.
9(Off):Turns the wipers off.
N(Windshield Wipers):Turn the band to control the
windshield wipers.
6: Turn the band to set the wiper speed for a long or
short delay between wipes. The closer to the top of the
lever, the shorter the delay time.
