If you need to replace any of your wheels, wheel bolts,
wheel nuts, or Tire Pressure Monitor System (TPMS)
sensors, replace them only with new GM original
equipment parts. This way, you will be sure to have the
right wheel, wheel bolts, wheel nuts, and TPMS
sensors for your vehicle.
{CAUTION:
Using the wrong replacement wheels, wheel bolts,
or wheel nuts on your vehicle can be dangerous.
It could affect the braking and handling of your
vehicle, make your tires lose air and make you lose
control. You could have a collision in which you or
others could be injured. Always use the correct
wheel, wheel bolts, and wheel nuts for replacement.Notice:The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance, and tire or tire chain
clearance to the body and chassis.
SeeChanging a Flat Tire on page 5-88for more
information.
Used Replacement Wheels
{CAUTION:
Putting a used wheel on the vehicle is dangerous.
You cannot know how it has been used or how far
it has been driven. It could fail suddenly and
cause a crash. If you have to replace a wheel, use
a new GM original equipment wheel.
5-75

Electrical System
Add-On Electrical Equipment
Notice:Do not add anything electrical to the
vehicle unless you check with your dealer/retailer
rst. Some electrical equipment can damage
the vehicle and the damage would not be covered
by the vehicle’s warranty. Some add-on electrical
equipment can keep other components from
working as they should.
Add-on equipment can drain the vehicle battery, even if
the vehicle is not operating.
The vehicle has an airbag system. Before attempting to
add anything electrical to the vehicle, seeServicing
Your Airbag-Equipped Vehicle on page 1-68.
Headlamps
The headlamp wiring is protected by four fuses. An
electrical overload will cause a lamp to go on and off.
If this happens, have the headlamp wiring checked
right away.
Windshield Wiper Fuses
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools. If the
overload is caused by some electrical problem, have it
xed.
Power Windows and Other Power
Options
Circuit breakers in the fuse block protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is xed or
goes away.
5-112

Fuses Usage
1Electrically-Controlled Air
Suspension
2Passenger Side High-Beam
HeadlampFuses Usage
3Passenger Side Low-Beam
Headlamp
4 Back-Up Trailer Lamps
5-114

Fuses Usage
5 Driver Side High-Beam Headlamp
6 Driver Side Low-Beam Headlamp
7 Windshield Wiper
8 Active Transfer Case
9 Windshield Washer
10 Powertrain Control Module B
11 Fog Lamps
12 Stoplamp
13 Cigarette Lighter
14 Ignition Coils
15Transmission Control Module
Canister
16 Truck Body Controller, Ignition 1
17 Crank
18 Airbag
19 Trailer Electric Brake
21 Horn
22 Ignition E
23 Electronic Throttle Control
24Instrument Panel Cluster, Driver
Information CenterFuses Usage
25Brake Transmission Shift
Interlock
26 Engine 1
27 Backup
28 Engine Control Module 1
29 Engine Control Module
30 Air Conditioning
31 Injector A
32 Trailer
33 Antilock Brakes (ABS)
34 Ignition A
35 Blower
36 Ignition B
50 Passenger Side Trailer Turn
51 Driver Side Trailer Turn
52 Hazard Flashers
53 Transmission
54 Oxygen Sensor B
55 Oxygen Sensor A
56 Injector B
57 Headlamp Driver Module
5-115

Fuses Usage
58 Body Controller 1
59 Electric Adjustable Pedals
61Vehicle Stability Enhancement
System
62 Regulated Voltage Control
63 Air Solenoid
64 Air Pump
Relays Usage
37 Headlamp Wiper
38 Rear Window Wiper/Washer
39 Fog Lamps
40 Horn
41 Fuel Pump
42 Windshield Washer
43 High-Beam Headlamp
44 Air Conditioning
46 Headlamp Driver Module
47 Starter
Relays Usage
49 Electric Adjustable Pedal
60 Powertrain
69 Air Solenoid
Miscellaneous Usage
48 Instrument Panel Battery
Rear Underseat Fuse Block
5-116

Audio System (cont.)
Setting the Clock.........................................3-63
Theft-Deterrent Feature...............................3-110
XM™ Satellite Radio Antenna System...........3-112
Audio System(s).............................................3-64
Automatic Headlamp System............................3-14
Automatic Transmission
Fluid..........................................................5-21
Operation...................................................2-25
B
Battery..........................................................5-38
Electric Power Management..........................3-17
Run-Down Protection...................................3-18
Bluetooth
®.....................................................3-86
Brake
Emergencies................................................ 4-6
Brake Fluid....................................................5-35
Brakes..........................................................5-35
System Warning Light..................................3-35
Braking........................................................... 4-4
Braking in Emergencies..................................... 4-6
Break-In, New Vehicle.....................................2-20
Bulb Replacement...........................................5-46
Back-Up Lamps...........................................5-48
Front Turn Signal, Sidemarker and
Parking Lamps.........................................5-47
Halogen Bulbs............................................5-46Bulb Replacement (cont.)
Headlamp Aiming........................................5-45
Headlamps.................................................5-46
License Plate Lamps....................................5-49
Replacement Bulbs......................................5-49
Taillamps, Turn Signal, and Stoplamps............5-47
Buying New Tires...........................................5-70
C
Calibration.....................................................2-40
California Fuel.................................................. 5-6
California Perchlorate Materials Requirements....... 5-4
California Proposition 65 Warning....................... 5-4
Canadian Owners................................................ ii
Capacities and Specications..........................5-120
Carbon Monoxide...........................2-12, 2-37, 4-28
Care of
Safety Belts..............................................5-106
Cargo Cover..................................................2-54
Cargo Tie Downs............................................2-55
CD, MP3 .......................................................3-80
Center Console Storage Area...........................2-52
Chains, Tire...................................................5-76
Charging System Light....................................3-33
Check
Engine Lamp..............................................3-38
Gages Warning Light...................................3-45
Check Gas Cap Light......................................3-47
2

Customer Assistance Information (cont.)
Reporting Safety Defects to the
Canadian Government..............................7-15
Reporting Safety Defects to the
United States Government.........................7-14
Roadside Assistance Program......................... 7-7
Service Publications Ordering Information........7-15
D
Daytime Running Lamp...................................3-14
Defensive Driving............................................. 4-2
Delayed Locking............................................... 2-8
Disc, MP3......................................................3-80
Doing Your Own Service Work........................... 5-4
Dome Lamp Override......................................3-16
Dome Lamps .................................................3-16
Door
Delayed Locking........................................... 2-8
Locks.......................................................... 2-7
Power Door Locks......................................... 2-8
Programmable Automatic Door Locks............... 2-9
Rear Door Security Locks.............................2-11
Driver Information Center (DIC).........................3-47
DIC Operation and Displays..........................3-48
DIC Vehicle Customization............................3-56
DIC Warnings and Messages........................3-51Driving
At Night.....................................................4-25
Before a Long Trip......................................4-26
Defensive..................................................... 4-2
Drunken....................................................... 4-3
Highway Hypnosis.......................................4-26
Hill and Mountain Roads..............................4-27
In Rain and on Wet Roads...........................4-25
Off-Road ....................................................4-13
Rocking Your Vehicle to Get it Out.................4-31
Winter........................................................4-28
Driving for Better Fuel Economy......................... 4-2
Dual Automatic Climate Control System.............3-22
Dual Climate Control System............................3-19
DVD
Rear Seat Entertainment System...................3-96
E
EDR .............................................................7-16
Electrical System
Add-On Equipment.....................................5-112
Engine Compartment Fuse Block.................5-113
Fuses and Circuit Breakers.........................5-113
Headlamps...............................................5-112
Power Windows and Other Power Options.......5-112
Rear Underseat Fuse Block.........................5-116
Windshield Wiper Fuses.............................5-112
4

Fuel (cont.)
Gage .........................................................3-46
Gasoline Octane........................................... 5-5
Gasoline Specications.................................. 5-6
Low Warning Light.......................................3-47
Fuses
Engine Compartment Fuse Block.................5-113
Fuses and Circuit Breakers.........................5-113
Rear Underseat Fuse Block.........................5-116
Windshield Wiper.......................................5-112
G
Gage
Check Gages Warning Light..........................3-45
Engine Coolant Temperature.........................3-37
Fuel..........................................................3-46
Oil Pressure...............................................3-42
Speedometer..............................................3-29
Tachometer.................................................3-29
Voltmeter Gage...........................................3-34
Garage Door Opener.......................................2-46
Gasoline
Octane........................................................ 5-5
Specications............................................... 5-6
Gate Ajar Light...............................................3-45
Glove Box.....................................................2-51
GM Mobility Reimbursement Program.................. 7-7
H
Hazard Warning Flashers................................... 3-6
Head Restraints..............................................1-10
Headlamp
Aiming .......................................................5-45
Headlamps............................................3-13, 5-46
Bulb Replacement.......................................5-46
Daytime Running Lamp................................3-14
Electrical System.......................................5-112
Flash-to-Pass............................................... 3-8
Front Turn Signal, Sidemarker and
Parking Lamps.........................................5-47
Halogen Bulbs............................................5-46
High/Low Beam Changer................................ 3-8
On Reminder..............................................3-14
Washer......................................................3-10
Heated Seats................................................... 1-4
Heater...........................................................3-19
Engine Coolant...........................................2-24
Heater...........................................................3-22
Highbeam On Light.........................................3-44
High-Speed Operation, Tires.............................5-62
Highway Hypnosis...........................................4-26
Hill and Mountain Roads..................................4-27
Hood
Checking Things Under................................5-10
Release.....................................................5-11
Horn ............................................................... 3-6
How to Wear Safety Belts Properly...................1-18
6

W
Warning Lights, Gages, and Indicators...............3-27
Warnings
DIC Warnings and Messages........................3-51
Hazard Warning Flashers............................... 3-6
Safety and Symbols......................................... iii
Washer, Headlamps........................................3-10
Wheels
Alignment and Tire Balance..........................5-74
Different Size..............................................5-72
Replacement...............................................5-74
Where to Put the Restraint...............................1-42
Windows.......................................................2-13
Power ........................................................2-14
Windshield
Backglass, and Wiper Blades, Cleaning........5-108
Washer........................................................ 3-9
Washer Fluid..............................................5-34Windshield (cont.)
Wiper Blade Replacement.............................5-50
Wiper Fuses.............................................5-112
Wipers......................................................... 3-8
Windshield, Rear Washer/Wiper.......................... 3-9
Winter Driving................................................4-28
X
XM Radio Messages.......................................3-84
XM™ Satellite Radio Antenna System..............3-112
Y
Your Vehicle and the Environment....................... 6-2
14
