Page 11 of 398
But don’t have a seatback reclined if your vehicle is
moving.
{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts can’t do their job
when you’re reclined like this.
The shoulder belt can’t do its job because it
won’t be against your body. Instead, it will be
in front of you. In a crash you could go into it,
receiving neck or other injuries.
The lap belt can’t do its job either. In a crash
the belt could go up over your abdomen. The
belt forces would be there, not at your pelvic
bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
1-5
Page 12 of 398
Rear Seats
Rear Seat Operation
Removing the Rear Seat
1. Disconnect the quick
release latch plates for
the lap shoulder
belts on the bench seat
to be removed. To
do this, press the tip of
a key into the release
hole of the safety
belt buckle while
pulling up on the
safety belt.2. Locate the pins.
There are two pins located on the inboard sides
of the rear seats. If the vehicle has oor mats,
the pins will be located under a ap that has
been cut into the mat. The driver’s side pin will
have an “L” marked on it and will look like this:
1-6
Page 13 of 398
The passenger’s side pin will have an “R”
marked on it and will look like this:
3. Pull the pin handle up to disengage from the
retaining clip, then pull the pin out.
4. Repeat this procedure for the pin on the other
seat base.5. Pull the seat rearward about two inches (5 cm) and
then lift the seat from the oor rails.
6. Remove the seat from the vehicle.
7. For the rst row rear
seat, stow the safety
belt latch by attaching
the clip on the
safety belt latch to the
trim just inside the
side door. For
the remaining rear
seats, stow the safety
belt latch plate on
the clip at the
window trim.
1-7
Page 14 of 398
Replacing the Rear Seats
{CAUTION:
A seat that isn’t locked into place properly can
move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure
to lock the seat into place properly when
installing it.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won’t provide the
protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.1. Position the seat into the open slots in both rails.
Push the seat forward in the rail, hooking both
seat bases onto the pins inside of the rails.
2. To install the locking pins at the rear of the seat
base, locate the hole in the rail for the pin. It is
found on the inboard side of the seat. If the vehicle
has oor mats, pull the ap that has been cut
into the mat.
3. Insert the locking pin into the seat base and push
the seat to line up with the pin with the base. The
pin with the handle marked “R” must be installed on
the passenger’s side and the pin with the handle
marked “L” on the driver’s side.
1-8
