Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of your windows.

When you enter a vehicle in cold weather, turn the
fan knob all the way toward the red area for a few
moments before driving. This helps clear the intake
ducts of snow and moisture, and reduces the chance
of fogging the inside of your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.

The use of non
-GM approved hood air deflectors
may adversely affect the performance of the heating
and air conditioning system.
Passenger Compartment Air Filter
Your vehicle is equipped with a passenger compartment
air filter, which filters outside air entering the vehicle.
For information on replacing the filter see ªPassenger
Compartment Air Filterº in the Index.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock for Systems with HR and
MN Buttons
Press and hold HR until the correct hour appears on the
display. Press and hold MN until the correct minute
appears on the display. To display the clock with the
ignition off, press RECALL or HR/MN and the time
will be displayed for a few seconds. There is an initial
two
-second delay before the clock goes into the
time
-set mode.

6-
6-1
Section 6 Service and Appearance Care
Here you will find information about the care of your vehicle. This section begins with service and fuel information,
and then it shows how to check important fluid and lubricant levels. There is also technical information about your
vehicle, and a part devoted to its appearance care.
6
-2 Service
6
-3 Fuel
6
-5 Fuels in Foreign Countries
6
-6 Filling Your Tank
6
-8 Checking Things Under the Hood
6
-11 Engine Oil
6
-17 Engine Air Cleaner/Filter
6
-19 Passenger Compartment Air Filter
6
-20 Automatic Transmission Fluid
6
-23 Rear Axle
6
-24 All-Wheel Drive
6
-27 Engine Coolant
6
-30 Coolant Surge Tank Pressure Cap
6
-31 Power Steering Fluid
6
-32 Windshield Washer Fluid6
-33 Brakes
6
-36 Battery
6
-37 Bulb Replacement
6
-46 Windshield Wiper Blade Replacement
6
-47 Tires
6
-56 Appearance Care
6
-56 Cleaning the Inside of Your Vehicle
6
-60 Cleaning the Outside of Your Vehicle
6
-64 GM Vehicle Care/Appearance Materials
6
-65 Vehicle Identification Number (VIN)
6
-66 Electrical System
6
-76 Replacement Bulbs
6
-76 Capacities and Specifications
6
-77 Normal Maintenance Replacement Parts

6-11
A. Engine Air Cleaner/Filter
B. Coolant Surge Tank
C. Air Cleaner/Filter
Restriction Indicator
D. Engine Oil Dipstick
E. Engine Oil Fill Cap
F. Automatic Transmission Dipstick
G. Fan
H. Remote Negative (
-)
Terminal (GND)
I. Remote Positive (+) Terminal
J. Power Steering Fluid Reservoir
K. Brake Fluid Reservoir
L. Underhood Fuse Block
M. Battery
N. Windshield Washer Fluid Reservoir
Engine Oil
If the CHECK ENG OIL
LEVEL light appears on the
instrument cluster, it means
you need to check your
engine oil level right away.
For more information, see
ªCHECK ENG OIL
LEVELº in the Index.
You should check your engine oil level regularly; this is
an added reminder.

6-17
Engine Air Cleaner/Filter
The air cleaner/filter assembly has an indicator that lets
you know when the engine air cleaner/filter is dirty and
needs to be serviced. The air cleaner/filter indicator is
located on the air cleaner cover. See ªEngine
Compartment Overviewº in the Index for more
information on location.
See ªOwner Checks and Servicesº in the Index to
determine when to check the indicator.
The service window A with
the percentage scale shows
the amount of engine air
cleaner/filter life used.
When both service window
A and service window B
turn orange, replace the
engine air cleaner/filter.
After changing the air filter, press the top button on the
indicator to reset it.
The air cleaner/filter assembly is located on the front
corner of the engine compartment on the passenger's
side of the vehicle. See ªEngine Compartment
Overviewº in the Index for more information
on location.

6-18
To replace the engine air cleaner/filter do the following:
1. Loosen the screws on the cover of the housing and
lift up the cover.
2. Remove the air cleaner/filter from the housing. Care
should be taken to dislodge as little dirt as possible.
3. Clean the filter sealing surface and the housing.
4. Install the new engine air cleaner/filter.
5. Reinstall the cover and tighten the screws.Refer to the Maintenance Schedule to determine when to
replace the engine air cleaner/filter. See ªOwner Checks
and Servicesº in the Index.
CAUTION:
Operating the engine with the air cleaner/filter
off can cause you or others to be burned. The air
cleaner not only cleans the air, it stops flame if
the engine backfires. If it isn't there, and the
engine backfires, you could be burned. Don't
drive with it off, and be careful working on the
engine with the air cleaner/filter off.
NOTICE:
If the air cleaner/filter is off, a backfire can
cause a damaging engine fire. And, dirt can easily
get into your engine, which will damage it.
Always have the air cleaner/filter in place when
you're driving.

6-19
Passenger Compartment Air Filter
Your vehicle is equipped with a passenger compartment
air filter. The filter is located under the instrument panel,
below the glove compartment. Your vehicle may or may
not be equipped with an access panel.
To replace the passenger compartment air filter, do the
following:
1. If your vehicle does not have an access panel, skip
this step. If your vehicle is equipped with an access
panel, remove the bolts on it and set the panel aside.
Because this operation can be a little difficult, you
may choose to have it done at your dealer's service
department.
2. Reach under the
instrument panel
towards the front of the
vehicle and pull
downward on the filter
retaining bracket.
3. Remove the air filter by pulling downward on the
element. Remove the second portion of the air filter
by sliding it towards the rear of the vehicle and then
pulling downward.
4. Install the new filter by reversing the steps listed
previously. Be sure to follow any instructions that
may be included in the replacement filter package.
Refer to the Maintenance Schedule to determine when to
replace the passenger compartment air filter. See
ªScheduled Maintenanceº in the Index.

6-76
Replacement Bulbs
Lamp Bulb Number
Low
-Beam Headlamps 9005 or. . . . . . . . . . . . . . . . .
9005 LL (long life)
High
-Beam Headlamps 9005. . . . . . . . . . . . . . . . . . .
Daytime Running Lamps (DRL) 4157K or. . . . . . . . .
3157KX
Front Roof Marker Lamps 194. . . . . . . . . . . . . . . . . .
Front Parking and Turn Lamps 3157 or. . . . . . . . . . .
3157K (long life)
Rear Marker Lamp, Taillamp
and Stoplamps 3157. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Turn Lamps 3157. . . . . . . . . . . . . . . . . . . . . . . .
Back
-up Lamps 3157. . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp 912. . . . . . . . . . . . .
Cargo Lamp 912. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fender Marker Lamps 194. . . . . . . . . . . . . . . . . . . . .
For any bulb not listed here contact your dealer.
Capacities and Specifications
Capacities
Cooling System 14.8 quarts (14.0 L). . . . . . . . . . . . .
Engine Oil with Filter 6.0 quarts (5.7 L). . . . . . . . . .
Fuel Tank 26.0 U.S. gallons (98.4 L). . . . . . . . . . . . .
All capacities are approximate. When adding, be sure to
fill to the approximate level, as recommended in this
manual. See ªRecommended Fluids and Lubricantsº in
the Index.
Air Conditioning Refrigerant
Capacity
If you do your own service work, you'll need the proper
service manual. See ªDoing Your Own Service Workº in
the Index for additional information. It is recommended
that service work on your air conditioning system be
performed by a qualified technician.
Air Conditioning
Refrigerant R134a 1.76 lbs. (0.8 kg). . . . . . . . . . . . .
Use Refrigerant Oil, R134a Systems

6-77 Engine Specifications
Engine VORTEC 6000. . . . . . . . . . . . . . . . . . . . . . . .
Type V8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VIN Code U. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plug Gap 0.060 inches (1.52 mm). . . . . . . . . .
Wheels and Tires
Wheel Nut Torque 140 lb-ft (190 N´m) . . . . . . . . . . .
Tire Pressure See the Certification/Tire label. . . . . .
on the rear edge of the driver's door.
Normal Maintenance
Replacement Parts
Oil Filter* PF59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Air Cleaner/Filter* A1518C. . . . . . . . . . . . . . .
Passenger Compartment Air
Filter Kit** 52485513. . . . . . . . . . . . . . . . . . . . . . .
PCV Valve* CV948C. . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plugs PTZ16R15 Denso. . . . . . . . . . . . . . . . . .
PZTR5A15 NGK
Fuel Filter* GF626. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades** 15153642. . . . . . . . . . . . . . . . . . . . .
Type ITTA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
* ACDelco

Part No.
**GM Part No.

Scheduled Maintenance
7-9
7,500 Miles (12 500 km)

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
15,000 Miles (25 000 km)

Replace passenger compartment air filter. If you drive regularly under dusty
conditions, the filter may require replacement more often.

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
22,500 Miles (37 500 km)

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Scheduled Maintenance
7-10
30,000 Miles (50 000 km)

Replace passenger compartment air filter. If you drive regularly under dusty
conditions, the filter may require replacement more often.

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)

Replace fuel filter.
An Emission Control Service. (See footnote
.)
37,500 Miles (62 500 km)
Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking.
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
45,000 Miles (75 000 km)
Replace passenger compartment air filter. If you drive regularly under dusty
conditions, the filter may require replacement more often.
Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking.
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
