Page 9 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
8 In Brief
With Remote Start and PowerLiftgate Shown
Press this button to extend the key.
The key can be used for the ignition
and all locks.
K: Press to unlock the driver door
or all doors.
For vehicles with the manual
liftgate, press
Ktwice within
five seconds to unlock the liftgate.
Q: Press to lock all doors.
Lock and unlock feedback can be
personalized.
Y: If equipped with the power
liftgate, press and hold until the
liftgate begins to move.
7: Press and release to initiate
vehicle locator. Press and hold for at
least three seconds to sound the
panic alarm. Press
7again to
cancel the panic alarm.
/: PressQand release and then
immediately press and hold
/for at
least four seconds to start the
engine from outside the vehicle.
See Keys 025 and Remote Keyless
Entry (RKE) System Operation 027.
Remote Vehicle Start
If equipped, the engine can be
started from outside of the vehicle.
Starting the Vehicle
1. Press and releaseQon the
RKE transmitter.
2. Immediately press and hold
/
for at least four seconds or until
the turn signal lamps flash. Start the vehicle normally after
entering.
When the vehicle starts, the parking
lamps will turn on.
Remote start can be extended.
Canceling a Remote Start
To cancel a remote start, do one of
the following:
.
Press and hold
/until the
parking lamps turn off.
. Turn on the hazard warning
flashers.
. Turn the vehicle on and then off.
See Remote Vehicle Start 029.
Page 26 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
Keys, Doors, and Windows 25
Keys, Doors, and
Windows
Keys and Locks
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . . 27
Remote Keyless Entry (RKE) System Operation . . . . . . . . . . . . 27
Remote Vehicle Start . . . . . . . . . . 29
Door Locks . . . . . . . . . . . . . . . . . . . . 31
Power Door Locks . . . . . . . . . . . . . 32
Delayed Locking . . . . . . . . . . . . . . . 32
Automatic Door Locks . . . . . . . . . 32
Lockout Protection . . . . . . . . . . . . . 32
Safety Locks . . . . . . . . . . . . . . . . . . . 33
Doors
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 33
Vehicle Security
Vehicle Security . . . . . . . . . . . . . . . . 37
Vehicle Alarm System . . . . . . . . . 37
Immobilizer . . . . . . . . . . . . . . . . . . . . 38
Immobilizer Operation . . . . . . . . . 39
Exterior Mirrors
Convex Mirrors . . . . . . . . . . . . . . . . 39
Power Mirrors . . . . . . . . . . . . . . . . . . 40 Heated Mirrors . . . . . . . . . . . . . . . . . 40
Reverse Tilt Mirrors . . . . . . . . . . . . 40
Interior Mirrors
Interior Rearview Mirrors . . . . . . . 41
Manual Rearview Mirror . . . . . . . . 41
Automatic Dimming Rearview
Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 41
Windows
Windows . . . . . . . . . . . . . . . . . . . . . . . 41
Power Windows . . . . . . . . . . . . . . . 42
Sun Visors . . . . . . . . . . . . . . . . . . . . . 43
Roof
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 43
Keys and Locks
Keys
{Warning
Leaving children in a vehicle with
the ignition key is dangerous and
children or others could be
seriously injured or killed. They
could operate the power windows
or other controls or make the
vehicle move. The windows will
function with the keys in the
ignition, and children or others
could be caught in the path of a
closing window. Do not leave
children in a vehicle with the
ignition key.
Page 29 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
28 Keys, Doors, and Windows
press to indicate locking. See
Vehicle Personalization0125. If a
passenger door is open when
Qis
pressed, all doors lock.
Pressing
Qmay also arm the
theft-deterrent system. See Vehicle
Alarm System 037.
K:Press to unlock the driver door
or all doors. See Vehicle
Personalization 0125. The turn
signal indicators may flash to
indicate unlocking has occurred.
See Vehicle Personalization 0125.
Pressing
Kmay also disarm the
theft-deterrent system. See Vehicle
Alarm System 037.
For vehicles with the manual
liftgate, press
Ktwice within
five seconds to unlock the liftgate.
Y: If equipped with the power
liftgate, press and hold until the
liftgate begins to move. Press again
to stop the power liftgate.
7: Press and release one time to
initiate vehicle locator. The exterior
lamps flash and the horn chirps
three times. Press and hold
7for at least three seconds to sound the
panic alarm. The horn sounds and
the turn signals flash until
7is
pressed again or the key is placed
in the ignition and turned to
ON/RUN.
/: If equipped, first press and
release
Qthen immediately press
and hold
/for at least
four seconds to start the engine
from outside the vehicle using the
RKE transmitter. See Remote
Vehicle Start 029.
The buttons on the keys are
disabled when there is a key in the
ignition.
Programming Transmitters to
the Vehicle
Only RKE transmitters programmed
to this vehicle will work. If a
transmitter is lost or stolen, a
replacement can be purchased and
programmed through your dealer.
When the replacement transmitter is
programmed to this vehicle, all
remaining transmitters must also be
reprogrammed. Any lost or stolen transmitters will no longer work
once the new transmitter is
programmed. See your dealer to
have new transmitters programmed.
Programming with a Recognized
Transmitter
To program a new key:
1. Insert the original, already programmed key in the ignition
and turn to the key to the ON/
RUN position.
2. Turn the key to LOCK/OFF, and remove the key.
3. Insert the new key to be programmed and turn it to the
ON/RUN position within
five seconds.
The security light will turn off
once the key has been
programmed.
4. Repeat Steps 1–3 if additional keys are to be programmed.
If a key is lost or damaged, see your
dealer to have a new key made.
Page 38 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
Keys, Doors, and Windows 37
Manual Operation of Power
Liftgate
To change the liftgate to manual
operation, turn the mode switch to
the OFF position.
Caution
Attempting to move the liftgate
too quickly and with excessive
force may result in damage to the
vehicle.
With the power liftgate disabled and
all of the doors unlocked, the liftgate
can be manually opened and
closed. Manual operation of a
liftgate that also has power
operation requires more effort than
a standard manual liftgate. To open the liftgate, press the touch
pad under the liftgate handle and lift
up. To close the liftgate, use the pull
cup to lower the liftgate and close.
With the power liftgate disabled, the
liftgate electric latch will still power
latch once contact is made with the
striker. Always close the liftgate
before driving.
IfYon the RKE transmitter is
pressed while power operation is
disabled, the turn signals flash and
the liftgate will not move.
The liftgate has an electric latch.
If the battery is disconnected or has
low voltage, the liftgate will not
open. The liftgate will resume
operation when the battery is
reconnected and charged.
Vehicle Security
This vehicle has theft-deterrent
features; however, they do not make
the vehicle impossible to steal.
Vehicle Alarm System
This vehicle has an anti-theft alarm
system.
The indicator light, on the
instrument panel near the
windshield, indicates the status of
the system:
Off : Alarm system is disarmed.
Page 39 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
38 Keys, Doors, and Windows
On Solid :Vehicle is secured
during the delay to arm the system.
Fast Flash : Vehicle is unsecured.
A door, the hood, or the liftgate
is open.
Slow Flash : Alarm system is
armed.
Arming the Alarm System
1. Turn off the vehicle.
2. Lock the vehicle in one of three ways:
.Use the RKE transmitter.
. With a door open, press the
interior
Q.
3. After 30 seconds the alarm system will arm, and the
indicator light will begin to
slowly flash indicating the
alarm system is operating.
Pressing
Qon the RKE
transmitter a second time will
bypass the 30-second delay
and immediately arm the alarm
system. The vehicle alarm system will not
arm if the doors are locked with
the key.
If the driver door is opened without
first unlocking with the RKE
transmitter, the horn will chirp and
the lights will flash to indicate
pre-alarm. If the vehicle is not
started, or the door is not unlocked
by pressing
Kon the RKE
transmitter during the 10-second
pre-alarm, the alarm will be
activated.
If a door, the hood, or the liftgate is
opened without first disarming the
system, the turn signals will flash
and the horn will sound for about
30 seconds. The alarm system will
then re-arm to monitor for the next
unauthorized event.
Disarming the Alarm System
To disarm the alarm system or turn
off the alarm if it has been activated:
. Press
Kon the RKE transmitter.
. Start the vehicle. To avoid setting off the alarm by
accident:
.
Lock the vehicle after all
occupants have left the vehicle
and all doors are closed.
. Always unlock a door with the
RKE transmitter.
Unlocking the driver door with the
key will not disarm the system or
turn off the alarm.
How to Detect a Tamper
Condition
IfKis pressed on the RKE
transmitter and the horn chirps and
the lights flash three times, an alarm
occurred previously while the alarm
system was armed.
If the alarm has been activated, a
message will appear on the DIC.
See Security Messages 0123.
Immobilizer
See Radio Frequency
Statement 0305.
Page 311 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
310 OnStar
.Obtain and customize the Wi-Fi®
hotspot name or SSID and
password, if equipped.
Press
Qto connect to an
Advisor to:
. Verify account information or
update contact information.
. Get driving directions.
. Receive a Diagnostic check of
the vehicle's key operating
systems.
. Receive Roadside Assistance.
. Manage Wi-Fi Settings,
if equipped.
Press
>to get a priority connection
to an OnStar Advisor available 24/
7 to:
. Get help for an emergency.
. Be a Good Samaritan or
respond to an AMBER Alert.
. Get assistance in severe
weather or other crisis situations
and find evacuation routes.
OnStar Services
Emergency
Emergency Services require an
active, OnStar service plan
(excludes Basic Plan). With
Automatic Crash Response, built-in
sensors can automatically alert a
specially trained OnStar Advisor
who is immediately connected in to
the vehicle to help.
Press
>for a priority connection to
an OnStar Advisor who can contact
emergency service providers, direct
them to your exact location, and
relay important information.
With OnStar Crisis Assist, specially
trained Advisors are available
24 hours a day, 7 days a week, to
provide a central point of contact,
assistance, and information during a
crisis.
With Roadside Assistance, Advisors
can locate a nearby service provider
to help with a flat tire, a battery
jump, or an empty gas tank.
Security
If equipped, OnStar provides these
services:
. With Stolen Vehicle Assistance,
OnStar Advisors can use GPS to
pinpoint the vehicle and help
authorities quickly recover it.
. With Remote Ignition Block™,
if equipped, OnStar can block
the engine from being restarted.
. With Stolen Vehicle Slowdown
®,
if equipped, OnStar can work
with law enforcement to
gradually slow the vehicle down.
Theft Alarm Notification
If equipped, if the doors are locked
and the vehicle alarm sounds, a
notification by text, e-mail, or phone
call will be sent. If the vehicle is
stolen, an OnStar Advisor can work
with authorities to recover the
vehicle.
Page 320 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
Index 319
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 204
Accessory Power . . . . . . . . . . . . . . . 168
Add-On Electrical Equipment . . . 201
Additional Information OnStar
®. . . . . . . . . . . . . . . . . . . . . . 314
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . 286
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . 48
Air Cleaner/Filter, Engine . . . . . . . 213
Air Conditioning . . . . . . . . . . . 142, 144
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 147
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 147
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . 73
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 66
Passenger Sensing System . . . . 67
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 65
What Will You See after an
Airbag Inflates? . . . . . . . . . . . . . . . 66
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 65
Where Are the Airbags? . . . . . . . . 63 Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 72
Passenger Status Indicator . . . 106
Readiness Light . . . . . . . . . . . . . . 105
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 72
System Check . . . . . . . . . . . . . . . . . . 62
Alarm Vehicle Security . . . . . . . . . . . . . . . . 37
Alert
Side Blind Zone (SBZA) . . . . . . 187
All-Season Tires . . . . . . . . . . . . . . . . 236
All-Wheel Drive . . . . . . . . . . . . 175, 224
Antilock Brake System (ABS) . . . 175 Warning Light . . . . . . . . . . . . . . . . . .110
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 269
Interior . . . . . . . . . . . . . . . . . . . . . . . . 274
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 299
Automatic Climate Control System . . . . . . . 144
Door Locks . . . . . . . . . . . . . . . . . . . . . 32
Headlamp System . . . . . . . . . . . . 136
Transmission . . . . . . . . . . . . . . . . . 172
Transmission Fluid . . . . . . . . . . . 213
Page 328 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
Index 327
Seats (cont'd)Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Reclining Seatbacks . . . . . . . . . . . . 49
Securing Child Restraints . . . . 86, 88
Security
Light . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Messages . . . . . . . . . . . . . . . . . . . . 123
OnStar
®. . . . . . . . . . . . . . . . . . . . . . 310
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 37
Vehicle Alarm . . . . . . . . . . . . . . . . . . . 37
Service . . . . . . . . . . . . . . . . . . . . . . . . . 148 Accessories andModifications . . . . . . . . . . . . . . . . 204
Climate Control System . . . . . . . 142
Doing Your Own Work . . . . . . . . 204
Engine Soon Light . . . . . . . . . . . . 107
Maintenance Records . . . . . . . . 291
Maintenance, General
Information . . . . . . . . . . . . . . . . . . 279
Parts Identification Label . . . . . 292
Publications Ordering Information . . . . . . . . . . . . . . . . . . 304
Scheduling Appointments . . . . . 301
Vehicle Messages . . . . . . . . . . . . 123
Services Special Application . . . . . . . . . . . 286
Servicing the Airbag . . . . . . . . . . . . . 72 Shift Lock Control Function
Check, Automatic
Transmission . . . . . . . . . . . . . . . . . . 224
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 169
Out of Park . . . . . . . . . . . . . . . . . . . 170
Side Blind Zone Alert (SBZA) . . . 187
Sidemarker
Bulb Replacement . . . . . . . . . . . . 227
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 137
Spare Tire Compact . . . . . . . . . . . . . . . . . . . . . . 262
Special Application Services . . . . 286
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 293
Speedometer . . . . . . . . . . . . . . . . . . . 103
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . . 111
Start Assist, Hill . . . . . . . . . . . . . . . . . 177
Start Vehicle, Remote . . . . . . . . . . . 29
Starter Switch Check . . . . . . . . . . . 224
Starting the Engine . . . . . . . . . . . . . 167
Steering . . . . . . . . . . . . . . . . . . . . . . . . 151 Fluid, Power . . . . . . . . . . . . . . . . . . 220
Wheel Adjustment . . . . . . . . . . . . . . 97
Wheel Controls . . . . . . . . . . . . . . . . . 97 Stoplamps and Back-Up Lamps
Bulb Replacement . . . . . . . . . . . . 227
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . . . 93
Center Console . . . . . . . . . . . . . . . . . 92
Convenience Net . . . . . . . . . . . . . . . 94
Glove Box . . . . . . . . . . . . . . . . . . . . . . 92
Roof Rack System . . . . . . . . . . . . . . 94
Storage Compartments . . . . . . . . . . 92
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 160
Summer Tires . . . . . . . . . . . . . . . . . . 237
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 43
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward Collision
Alert (FCA) . . . . . . . . . . . . . . . . . . 185
Infotainment . . . . . . . . . . . . . 141, 308
Roof Rack . . . . . . . . . . . . . . . . . . . . . . 94
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 103
Taillamps Bulb Replacement . . . . . . . . . . . . 227
Text Telephone (TTY) Users . . . . 298
Theft-Deterrent Systems . . . . . . . . . 39 Immobilizer . . . . . . . . . . . . . . . . . . . . . 38
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Page 329 of 330
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9919509) - 2017 - crc - 8/16/16
328 Index
Tires (cont'd)All-Season . . . . . . . . . . . . . . . . . . . . 236
Buying New Tires . . . . . . . . . . . . . 250
Chains . . . . . . . . . . . . . . . . . . . . . . . . 254
Changing . . . . . . . . . . . . . . . . . . . . . 256
Compact Spare . . . . . . . . . . . . . . . 262
Designations . . . . . . . . . . . . . . . . . 240
Different Size . . . . . . . . . . . . . . . . . 251
If a Tire Goes Flat . . . . . . . . . . . . 255
Inspection . . . . . . . . . . . . . . . . . . . . 248
Messages . . . . . . . . . . . . . . . . . . . . 124
Pressure . . . . . . . . . . . . . . . . . . . . . . 243
Pressure Light . . . . . . . . . . . . . . . . .112
Pressure Monitor Operation . . 245
Pressure Monitor System . . . . . 244
Rotation . . . . . . . . . . . . . . . . . . . . . . 248
Sidewall Labeling . . . . . . . . . . . . . 238
Terminology and Definitions . . 240
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 252
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 253
Wheel Replacement . . . . . . . . . . 254
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 249
Winter . . . . . . . . . . . . . . . . . . . . . . . . 237
Towing Driving Characteristics . . . . . . . . 195 Towing (cont'd)
Equipment . . . . . . . . . . . . . . . . . . . . 200
General Information . . . . . . . . . . 195
Recreational Vehicle . . . . . . . . . . 266
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 198
Trailer Sway Control (TSC) . . . 200
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 266
Traction Control System (TCS)/
StabiliTrak
®Light . . . . . . . . . . . . . 111
Off Light . . . . . . . . . . . . . . . . . . . . . . . 111
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 177
Trailer
Sway Control (TSC) . . . . . . . . . . 200
Towing . . . . . . . . . . . . . . . . . . . . . . . . 198
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . 172
Fluid, Automatic . . . . . . . . . . . . . . 213
Messages . . . . . . . . . . . . . . . . . . . . 124
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . 301
Turn and Lane-Change
Signals . . . . . . . . . . . . . . . . . . . . . . . . 137
Turn Signal Bulb Replacement . . . . . . . . . . . . 227
U
Uniform Tire Quality Grading . . . 252
Universal Remote System . . . . . . 131Operation . . . . . . . . . . . . . . . . . . . . . 133
Programming . . . . . . . . . . . . . . . . . 131
Using This Manual . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . 37
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 151
Identification Number (VIN) . . . 292
Load Limits . . . . . . . . . . . . . . . . . . . 161
Messages . . . . . . . . . . . . . . . . . . . . .118
Personalization . . . . . . . . . . . . . . . 125
Reminder Messages . . . . . . . . . . 124
Remote Start . . . . . . . . . . . . . . . . . . . 29
Security . . . . . . . . . . . . . . . . . . . . . . . . 37
Towing . . . . . . . . . . . . . . . . . . . . . . . . 266
Vehicle Ahead Indicator . . . . . . . . 111
Vehicle Care Tire Pressure . . . . . . . . . . . . . . . . . 243
Vehicle Data Recording and
Privacy . . . . . . . . . . . . . . . . . . . . . . . . 306
Ventilation, Air . . . . . . . . . . . . . . . . . . 147
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
