yellowblue
4-54
Additional Heavy-Duty Wiring
An eight
-wire harness is stored under the rear bumper of
your vehicle. The five
-wire light-duty harness is located
at the left hand rear inner lower quarter panel. The
additional heavy
-duty wiring is located forward of the
rear bumper and is attached to the center of the rear
crossmember or the forward vertical surface of the
platform hitch.
This harness has a 30 amp battery feed wire and no
connector, and should be wired by a qualified electrical
technician. After choosing an aftermarket mating
connector pair, have the technician attach one connector tothe eight
-wire trailer harness and the other connector to the
wiring harness on the trailer. Be sure that the wiring
harness on the trailer is strapped to the trailer's frame and
leave it loose enough so that the wiring doesn't bend or
break, but not so loose that it drags on the ground. The
technician can use the following color code chart when
connecting the wiring harness to your trailer.
Brown: Rear Lamps
Yellow: Left Stoplamp and Turn Signal
Dark Green: Right Stoplamp and Turn Signal
White (Heavy Gauge): Ground
Light Green: Back
-up Lamps
White (Light Gauge): Center High
-Mounted Stop
Lamp (If Equipped)
Blue: Auxiliary/Electric Trailer Brake Circuit
(If Equipped)
Orange: Fused Auxiliary Circuit (If Equipped)
Store the harness in its original place. Wrap the harness
together and tie it neatly so it won't be damaged.
Page 265 of 400
yellowblue
6-3
CAUTION:
You can be injured and your vehicle could be
damaged if you try to do service work on a
vehicle without knowing enough about it.
Be sure you have sufficient knowledge,
experience, the proper replacement parts
and tools before you attempt any vehicle
maintenance task.
Be sure to use the proper nuts, bolts and
other fasteners. ªEnglishº and ªmetricº
fasteners can be easily confused. If you use
the wrong fasteners, parts can later break
or fall off. You could be hurt.
Adding Equipment to the Outside of
Your Vehicle
Things you might add to the outside of your vehicle can
affect the airflow around it. This may cause wind noise
and affect windshield washer performance. Check with
your dealer before adding equipment to the outside of
your vehicle.
Fuel
Use regular unleaded gasoline rated at 87 octane or
higher. It is recommended that the gasoline meet
specifications which have been developed by the
American Automobile Manufacturers Association
(AAMA) and endorsed by the Canadian Motor Vehicle
Manufacturers Association for better vehicle
performance and engine protection. Gasolines meeting
the AAMA specification could provide improved
driveability and emission control system performance
compared to other gasolines. For more information,
write to: American Automobile Manufacturers
Association, 7430 Second Ave, Suite 300,
Detroit MI 48202.
Be sure the posted octane is at least 87. If the octane is
less than 87, you may get a heavy knocking noise when
you drive. If it's bad enough, it can damage your engine.
If you're using fuel rated at 87 octane or higher and you
hear heavy knocking, your engine needs service. But
don't worry if you hear a little pinging noise when
you're accelerating or driving up a hill. That's normal,
and you don't have to buy a higher octane fuel to get rid
of pinging. It's the heavy, constant knock that means
you have a problem.
Page 272 of 400
yellowblue
6-10
ªVORTECº 5700 V8 Engine
When you lift up the hood you'll see:
A. Battery
B. Coolant Recovery Tank
C. Radiator Cap
D. Air Cleaner
E. Air Filter Restriction IndicatorF. Engine Oil Dipstick
G. Automatic Transmission
Dipstick
H. Fan
I. Engine Oil FillJ. Power Steering Fluid Reservoir
K. Brake Fluid Reservoir
L. Windshield Washer
Fluid Reservoir
M. Fuse/Relay Center
Page 318 of 400
yellowblue
6-56
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle unless
you check with your dealer first. Some electrical
equipment can damage your vehicle and the
damage wouldn't be covered by your warranty.
Some add
-on electrical equipment can keep other
components from working as they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamps
The headlamp wiring is protected by a circuit breaker in
the lamp switch. An electrical overload will cause the
lamps to flicker on and off, or in some cases to remain
off. If this happens, have your headlamp wiring checked
right away.
Windshield Wipers
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools.
Although the circuit is protected from electrical
overload, overload due to heavy snow, etc., may cause
wiper linkage damage. Always clear ice and heavy snow
from the windshield before using the windshield wipers.
If the overload is caused by some electrical problem and
not snow, etc., be sure to get it fixed.
Power Windows and Other Power Options
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes.
This protects the circuit until the current load returns to
normal or the problem is fixed.
Page 319 of 400
yellowblue
6-57 Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links in the wiring itself. This
greatly reduces the chance of fires caused by electrical
problems. See ªFuses and Circuit Breakersº in the Index
for more information.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
If you ever have a problem on the road and don't have a
spare fuse, you can borrow one that has the same
amperage. Just pick some feature of your vehicle that
you can get along without
-- like the radio or cigarette
lighter
-- and use its fuse, if it is the correct amperage.
Replace it as soon as you can.Instrument Panel Fuse Block
The fuse block access door
is on the driver's side edge
of the instrument panel. Pull
off the cover to access the
fuse block.
You can remove fuses with
a fuse extractor. The fuse
extractor is mounted to the
fuse block access door.
To remove fuses, if you don't have a fuse extractor, hold
the end of the fuse between your thumb and index finger
and pull straight out.
You may have spare fuses attached to the inside of the
fuse block access door. These can be used to replace a
bad fuse. However, make sure that it is the
correct amperage.
Page 320 of 400
yellowblue
6-58
Fuse/Circuit
BreakerUsage
1 Stop/TCC Switch, Buzzer, CHMSL,
Hazard Lamps, Stoplamps
2 Transfer Case
3 Courtesy Lamps, Cargo Lamp, Glove
Box Lamp, Dome/Reading Lamps,
Vanity Mirrors, Power MirrorsFuse/Circuit
BreakerUsage
4 Instrument Cluster, DRL Relay, Lamp
Switch, Keyless Entry, Low Coolant
Module, Illuminated Entry Module
5 Rear Comfort Controls
6 Cruise Control
7 Auxiliary Power Outlet
8 Crank
9 License Lamp, Parking Lamps,
Taillamps, Tailgate Lamps, Front
Sidemarkers, Fog Lamp Relay, Door
Switch Illumination, Fender Lamps,
Headlamp Switch Illumination
10 Air Bag System
11 Wiper Motor, Washer Pump
12 A/C, A/C Blower, High Blower Relay
13 Power Amp, Rear Liftglass, Cigarette
Lighter, Door Lock Relay, Power
Lumbar Seat
14 4WD Indicator, Cluster, Front and Rear
Comfort Controls, Instrument Switches,
Radio Illumination, Chime Module
Page 321 of 400
yellowblue
6-59
Fuse/Circuit
BreakerUsage
15 DRL Relay, Fog Lamp Relay
16 Front and Rear Turn Signals,
Back
-Up Lamps, BTSI Solenoid
17 Radio (Ignition)
18 4WAL/VCM, ABS, Cruise Control
19 Radio (Battery)
20 PRNDL, Automatic Transmission,
Speedometer, Check Gages,
Warning Lights
21 Security/Steering
22 Auxiliary Power, Headlamp Delay
23 Rear Wiper, Rear Washer Pump
24 Front Axle, 4WD Indicator Lamp,
TP2 Relay
A Power Door Lock, Six
-Way Power
Seat, Keyless Entry Module
B Power WindowsUnderhood Fuse/Relay Center
The underhood fuse/relay center is located in the rear of
the engine compartment near the brake fluid reservoir.
Move the retainer clips for the cover to access the
fuse block.
You can remove fuses with a fuse extractor. The fuse
extractor is mounted to the interior fuse block. To
remove fuses if you don't have a fuse extractor, hold the
end of the fuse between your thumb and index finger
and pull straight out.
Page 322 of 400
yellowblue
6-60
Name Circuits Protected
ECM
-B Fuel Pump, PCM/VCM
RR DEFOG Rear Window Defogger
IGN
-E Auxiliary Fan Relay Coil, A/C
Compressor Relay, Hot Fuel Module
FUEL SOL Not Used
GLOW PLUG Not UsedName Circuits Protected
HORN Horn, Underhood Lamp
AUX FAN Auxiliary Fan
ECM
-1 Injectors, PCM/VCM
HTD ST
-FR Heated Front Seats
A/C Air Conditioning
HTD MIR Heated Outside Mirrors
ENG
-1 Ignition Switch, EGR, Canister
Purge, EVRV Idle Coast Solenoid,
Heated O
2
HTD ST-RR Heated Rear Seats
LIGHTING Headlamp and Panel Dimmer
Switch, Fog and Courtesy Fuses
BATT Battery, Fuse Block Busbar
IGN
-A Ignition Switch
IGN
-B Ignition Switch
ABS Anti
-Lock Brake Module
BLOWER Hi Blower and Rear Blower Relays
STOP/HAZ Stoplamps
HEATED
SEATSHeated Seats
Page 390 of 400
yellowblue
9-2
Brake (Continued)
Replacing System Parts 6-32 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-74 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Shift Interlock Check 7-37 . . . . . . . . . . . . . . .
Wear 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-34, 6-61 . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian Roadside Assistance 8-7 . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-63 . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-11, 2-36, 2-37, 4-41, 4-48, 4-49 . . . . .
Cargo Security Shade 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo Tie Downs 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Deck Service 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-22 . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Errors 3-11 . . . . . . . . . . . . . . . . . . . . . . .
CD Changer 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cellular Telephone 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp Bulb Replacement 6-37 . . . .
Center Passenger Position 1-36 . . . . . . . . . . . . . . . . . . . . . . . .
Certification/Tire Label 4-43 . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Warning Light 2-73 . . . . . . . . . . . . . . . . . . .
Check Gages Light 2-81 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Checking Your Restraint Systems 1
-57 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-48 . . . . . . . . . . .
Securing in the Center Rear Seat Position 1-50 . . . . . . . . . .
Securing in the Right Front Seat Position 1-52 . . . . . . . . . .
Top Strap 1-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air 6-15, 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning
Aluminum Wheels 6
-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps/Lenses 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-47 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-49 . . . . . . . . . . . . . . . . . . . . .
Leather 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Speaker Covers 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-50 . . . . . . . . . . . . . . . . . . .
Wood Panels 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Guides, Rear Safety Belts 1-34 . . . . . . . . . . . . . . . . .
Page 392 of 400
yellowblue
9-4
Electronic Compass 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 6-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-15, 6-64 . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-23, 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-76 . . . . . . . . . . . . . . . . . . . . .
Cooling System 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust 2-36, 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-37 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-11, 6-65, 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Gage 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Equipment, Adding to the Outside of Your Vehicle 6-3 . . . . . .
Ethanol 6-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-36, 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exit Lighting and Delayed Illumination 2-49 . . . . . . . . . . . . .
Exterior Lamps 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Feature Customization 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver's Door Alarm Delay 2-19 . . . . . . . . . . . . . . . . . . . . .
Keyless Entry Verification 2-17 . . . . . . . . . . . . . . . . . . . . . .
Leaving Programming Mode 2-19 . . . . . . . . . . . . . . . . . . . .
Lockout Prevention 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . Theft
-Deterrent Arming Method 2-18 . . . . . . . . . . . . . . . . .
Theft-Deterrent Arming Verification 2-19 . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-8 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Air Cleaner 6-15, 6-64 . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Engine Oil 6-14, 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Gear, Automatic Transmission 2-27 . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Leak Check 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-48, 6-36, 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding the Rear Seat 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-28, 6-21 . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle 6
-22, 7-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle Locking Feature 2-28 . . . . . . . . . . . . . . . . . . . . . . .
Front Park/Turn Signal Bulb Replacement 6-36, 6-61 . . . . . .
Front Sidemarker Lamp Bulb Replacement 6-36, 6-61 . . . . . .
Front Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Capacity 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-57 . . . . . . . . . . . . . . . . . . . . . . .
