oil type GMC YUKON 2001 Owner's Manual

2-88 Reduced Engine Power
This message is displayed
when the cooling system
temperature gets too hot and
the engine further enters
the engine coolant
protection mode.
If your vehicle is equipped with the 8.1L engine, this
light may come on because of an electronic throttle
control system fault. See ªEngine Overheatingº in the
Index for further information.
Check Eng Oil Pressure
This message is displayed
when the engine oil pressure
is low.
See ªOil Pressure Gageº in the Index for more information.
Check Eng Oil Level
This message is displayed
when the engine oil level
is low.
Once oil is added, it may need time to drain and settle in
the engine before this message will turn off. It is best to
let the engine cool down (if it is hot) or warm up (if it is
cold) and cycle the ignition to be sure this message turns
off. Refer to the dipstick for the correct level.
See ªEngine Oilº in the Index on how to check the oil
level and for what type of oil to add.

3-35
When the cleaning cassette has been ejected, the cut tape
detection feature is active again.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
After you clean the player, press and hold EJECT for
five seconds to reset the CLN indicator. The radio will
display
--- to show the indicator was reset.
Cassettes are subject to wear and the sound quality
may degrade over time. Always make sure the cassette
tape is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution
and clean it, wiping from the center to the edge.
Be sure never to touch the side without writing when
handling discs. Pick up discs by grasping the outer
edges or the edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.
Fixed Mast Antenna
The fixed mast antenna can withstand most car washes
without being damaged. If the mast should ever become
slightly bent, you can straighten it out by hand. If the
mast is badly bent, as it might be by vandals, you should
replace it.
Check every once in a while to be sure the mast is still
tightened to the cowl.

6-74 Crankcase Capacity
After refill, the level must be rechecked. Add enough
engine oil so that the fluid is within the proper operating
range. See ªEngine Oilº in the Index.
Engine VIN
Quantity with Filter

VORTEC 4800 V8 V 6.0 quarts (5.7 L)
VORTEC 5300 V8 T 6.0 quarts (5.7 L)
VORTEC 6000 V8 U 6.0 quarts (5.7 L)
VORTEC 8100 V8 G 6.5 quarts (6.1 L)

Oil filter should be changed at every oil change.
Fuel Tank Capacity
Type Quantity
4 Door Utility 26.0 U.S. gallons (98.4 L)
Suburban/Yukon XL
(1500 Series)32.5 U.S. gallons (123.0 L)
Suburban/Yukon XL
(2500 Series)38.5 U.S. gallons (147.6 L)
Normal Maintenance
Replacement Parts
Replacement part numbers listed in this section are
based on the latest information available at the time of
printing, and are subject to change. If a part listed in this
manual is not the same as the part used in your vehicle
when it was built, or if you have any questions, please
contact your GM dealer.

6-75
These specifications are for information only. If you have any questions, see the service manual for the chassis or
refer to the body manufacturer's publications.
VIN Code V T U G
Oil Filter* PF59 PF59 PF59 PF454
Engine Air Cleaner/Filter*
A1519CA1519CA1518C A1518C
Passenger Compartment Air Filter Kit** 52485513 52485513 52485513 52485513
PCV Valve* CV948C CV948C CV948C CV948C
Spark PlugsPTJ14R15***/
PZTR5A15PTJ14R15***/
PZTR5A15PTJ16R15***/
PZTR5A15PTJ16R15***/
PZTR5A15
Fuel Filter* GF626 GF626 GF626 GF626
Wiper Blades (Front) ** 15706394 15706394 15706394 15706394
Wiper Blade Type (Front) ITTA ITTA ITTA ITTA
Wiper Blade Length (Front) 22 inches
(56.0 cm)22 inches
(56.0 cm)22 inches
(56.0 cm)22 inches
(56.0 cm)
Wiper Blades (Rear) ** 22154396 22154396 22154396 22154396
Wiper Blade Type (Rear) ITTA ITTA ITTA ITTA
Wiper Blade Length (Rear) 18 inches
(45.0 cm)18 inches
(45.0 cm)18 inches
(45.0 cm)18 inches
(45.0 cm)
*AC Delco

part number
**GM part number
***Denso part number
A1518C high
-capacity air cleaner filter may be substituted.
 Spark Plug Gap is 0.060 inches
 NGK
