Power steering fluid GMC YUKON 2004 Owner's Manual

Service............................................................5-3
Doing Your Own Service Work.........................5-3
Adding Equipment to the Outside of Your
Vehicle......................................................5-4
Fuel................................................................5-4
Gasoline Octane............................................5-4
Gasoline Specications....................................5-5
California Fuel...............................................5-5
Additives.......................................................5-6
Fuel E-85 (85% Ethanol).................................5-6
Fuels in Foreign Countries...............................5-8
Filling Your Tank............................................5-8
Filling a Portable Fuel Container.....................5-10
Checking Things Under the Hood....................5-10
Hood Release..............................................5-11
Engine Compartment Overview.......................5-12
Engine Oil...................................................5-16
Engine Air Cleaner/Filter................................5-21
Automatic Transmission Fluid.........................5-23
Engine Coolant.............................................5-26
Coolant Surge Tank Pressure Cap..................5-28
Engine Overheating.......................................5-29Cooling System............................................5-32
Engine Fan Noise.........................................5-38
Power Steering Fluid.....................................5-38
Windshield Washer Fluid................................5-40
Brakes........................................................5-41
Battery........................................................5-44
Jump Starting...............................................5-45
All-Wheel Drive..............................................5-51
Rear Axle.......................................................5-52
Four-Wheel Drive............................................5-53
Front Axle......................................................5-54
Bulb Replacement..........................................5-55
Halogen Bulbs..............................................5-55
Headlamps..................................................5-55
Front Turn Signal, Sidemarker and Daytime
Running Lamps.........................................5-56
Side Identication Marker Lamps.....................5-57
Roof Marker Lamps......................................5-58
Taillamps.....................................................5-60
Replacement Bulbs.......................................5-61
Section 5 Service and Appearance Care
5-1

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-21.
B. Coolant Surge Tank. SeeCooling System on
page 5-32.
C. Air Filter Restriction Indicator (If Equipped). See
Engine Air Cleaner/Filter on page 5-21.
D. Engine Oil Dipstick. SeeEngine Oil on page 5-16.
E. Automatic Transmission Dipstick. SeeAutomatic
Transmission Fluid on page 5-23.
F. Engine Oil Fill. SeeEngine Oil on page 5-16.
G. Fan. SeeCooling System on page 5-32.
H. Remote Negative (−) Terminal (GND). SeeJump
Starting on page 5-45.I. Power Steering Fluid Reservoir. SeePower Steering
Fluid on page 5-38.
J. Remote Positive (+) Terminal. SeeJump Starting on
page 5-45.
K. Brake Master Cylinder Reservoir. SeeBrakes on
page 5-41.
L. Underhood Fuse Block. SeeFuses and Circuit
Breakers on page 5-113.
M. Battery. SeeBattery on page 5-44.
N. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-40.
5-13

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-21.
B. Coolant Surge Tank. SeeCooling System on
page 5-32.
C. Air Filter Restriction Indicator (If Equipped). See
Engine Air Cleaner/Filter on page 5-21.
D. Engine Oil Dipstick. SeeEngine Oil on page 5-16.
E. Automatic Transmission Dipstick. SeeAutomatic
Transmission Fluid on page 5-23.
F. Engine Oil Fill. SeeEngine Oil on page 5-16.
G. Fan. SeeCooling System on page 5-32.
H. Remote Negative (−) Terminal (GND). SeeJump
Starting on page 5-45.I. Remote Positive (+) Terminal. SeeJump Starting on
page 5-45.
J. Power Steering Fluid Reservoir. SeePower Steering
Fluid on page 5-38.
K. Brake Master Fluid Reservoir. SeeBrakes on
page 5-41.
L. Underhood Fuse Block. SeeFuses and Circuit
Breakers on page 5-113.
M. Battery. SeeBattery on page 5-44.
N. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-40.
5-15

Engine Fan Noise
Your vehicle has a clutched engine cooling fan. When the
clutch is engaged, the fan spins faster to provide more air
to cool the engine. In most everyday driving conditions,
the fan is spinning slower and the clutch is not fully
engaged. This improves fuel economy and reduces fan
noise. Under heavy vehicle loading, trailer towing and/or
high outside temperatures, the fan speed increases as
the clutch more fully engages. So you may hear an
increase in fan noise. This is normal and should not be
mistaken as the transmission slipping or making extra
shifts. It is merely the cooling system functioning properly.
The fan will slow down when additional cooling is not
required and the clutch disengages.
You may also hear this fan noise when you start the
engine. It will go away as the fan clutch partially
disengages.
Power Steering Fluid
8100 Engines
5-38

When to Check Power Steering Fluid
It is not necessary to regularly check power steering uid
unless you suspect there is a leak in the system or
you hear an unusual noise. A uid loss in this system
could indicate a problem. Have the system inspected
and repaired. SeeEngine Compartment Overview
on page 5-12for reservoir location.
How to Check Power Steering Fluid
Turn the key off, let the engine compartment cool down,
wipe the cap and the top of the reservoir clean, then
unscrew the cap and wipe the dipstick with a clean rag.
Replace the cap and completely tighten it. Then
remove the cap again and look at the uid level on the
dipstick.
The level should be at the FULL COLD mark. If
necessary, add only enough uid to bring the level up to
the mark.
What to Use
To determine what kind of uid to use, see
Recommended Fluids and Lubricants on page 6-12.
Always use the proper uid. Failure to use the proper
uid can cause leaks and damage hoses and seals. All Other Engines
5-39

Recommended Fluids and
Lubricants
Fluids and lubricants identied below by name, part
number or specication may be obtained from your
dealer.
Usage Fluid/Lubricant
Engine OilEngine oil which meets GM
Standard GM6094M and displays
the American Petroleum Institute
Certied for Gasoline Engines
starburst symbol. To determine the
proper viscosity for your vehicle’s
engine, seeEngine Oil on
page 5-16.
Engine Coolant50/50 mixture of clean, drinkable
water and use only
DEX-COOL
®Coolant. SeeEngine
Coolant on page 5-26.
Hydraulic Brake
SystemDelco Supreme 11 Brake Fluid or
equivalent DOT-3 brake uid.
Usage Fluid/Lubricant
Windshield
Washer SolventGM Optikleen
®Washer Solvent.
Power Steering
SystemGM Power Steering Fluid (GM Part
No. U.S. 89021184, in Canada
89021186).
Automatic
TransmissionDEXRON
®-III Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474).
Chassis
LubricationChassis Lubricant (GM Part No.
U.S. 12377985, in Canada
88901242) or lubricant meeting
requirements of NLGI #2, Category
LB or GC-LB.
Front Axle
(Four-Wheel
Drive)SAE 80W-90 Axle Lubricant (GM
Part No. U.S. 1052271, in Canada
10950849).
6-12

A
Accessory Power Outlets.................................3-21
Adding Washer Fluid.......................................5-40
Additional Program Information........................... 7-9
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment...........................5-113
Adjustable Throttle and Brake Pedal..................2-23
Adjusting the Speakers
(Balance/Fade)..................3-80, 3-84, 3-96, 3-111
After Off-Road Driving.....................................4-36
Air Bag
Passenger Status Indicator...........................3-43
Readiness Light..........................................3-43
Air Bag Systems.....................................1-72, 1-78
Adding Equipment to Your Air Bag-Equipped
Vehicle...................................................1-86
How Does an Air Bag Restrain?....................1-79
Passenger Sensing System...........................1-82
Servicing Your Air Bag-Equipped Vehicle.........1-86
What Makes an Air Bag Inate?....................1-79
What Will You See After an Air Bag
Inates?..................................................1-80
When Should an Air Bag Inate?...................1-77
Where Are the Air Bags?..............................1-75
Air Cleaner/Filter, Engine.................................5-21
Air Conditioning..............................................3-31
Airbag Sensing and Diagnostic Module (SDM).......7-10
All Overseas Locations...................................... 7-5
All-Wheel Drive...............................................5-51All-Wheel Drive with Stabilitrak
®........................2-33
AM .............................................................3-137
AM-FM Radio.................................................3-78
Antenna, Fixed Mast......................................3-139
Antenna, XM™ Satellite Radio Antenna
System.....................................................3-139
Anti-lock Brake System..................................... 4-7
Anti-Lock Brake, System Warning Light..............3-47
Appearance Care..........................................5-103
Care of Safety Belts...................................5-106
Chemical Paint Spotting..............................5-110
Cleaning the Inside of Your Vehicle..............5-104
Cleaning the Outside of Your Vehicle............5-107
Finish Damage..........................................5-109
Sheet Metal Damage..................................5-109
Underbody Maintenance.............................5-109
Vehicle Care/Appearance Materials...............5-110
Weatherstrips............................................5-106
Approaching a Hill..........................................4-28
Ashtrays........................................................3-21
Audio Output................................................3-131
Audio System(s).............................................3-77
AM-FM Radio.............................................3-78
Audio Steering Wheel Controls....................3-136
Care of Your Cassette Tape Player...............3-137
Care of Your CD and DVD Player................3-139
Care of Your CDs and DVDs.......................3-138
Chime Level Adjustment.............................3-139
Fixed Mast Antenna...................................3-139
Radio with Cassette and CD.........................3-92
1

EEasy Exit Seat...............................................2-65
Electrical System
Add-On Equipment.....................................5-113
Fuses and Circuit Breakers.........................5-113
Power Windows and Other Power Options.......5-113
Windshield Wiper Fuses.............................5-113
Emissions Inspection and Maintenance
Programs...................................................3-54
Engine
Air Cleaner/Filter.........................................5-21
Battery.......................................................5-44
Check and Service Engine Soon Light............3-51
Coolant......................................................5-26
Coolant Heater............................................2-23
Coolant Temperature Gage...........................3-49
Engine Compartment Overview......................5-12
Exhaust.....................................................2-42
Fan Noise..................................................5-38
Oil .............................................................5-16
Overheating................................................5-29
Starting......................................................2-22
ENGINE COOLANT HOT.................................3-71
Engine Hour Meter Display...............................3-42
Engine Oil Additives........................................5-19
ENGINE OVERHEATED..................................3-72
Entertainment System
Cleaning the Video Screen..........................3-139
DVD Distortion..........................................3-137Entry Lighting.................................................3-19
Environmental Concerns..................................4-25
Erasing HomeLink®Buttons..............................2-58
Event Data Records (EDR)..............................7-10
Exit Lighting...................................................3-19
Express-Down Windows...................................2-16
Extender, Safety Belt.......................................1-44
Exterior Lamps...............................................3-15
F
Filter
Engine Air Cleaner......................................5-21
Finding a Program Type (PTY) Station
(RDS and XM™).......................3-85, 3-96, 3-112
Finding a Station..................3-79, 3-83, 3-94, 3-110
Finish Care..................................................5-107
Finish Damage.............................................5-109
Fixed Mast Antenna.......................................3-139
Flash-to-Pass................................................... 3-9
Flat Tire........................................................5-83
Flat Tire, Changing.........................................5-84
Fluid
Automatic Transmission................................5-23
Power Steering...........................................5-38
Windshield Washer......................................5-40
FM Stereo....................................................3-137
Fog Lamps....................................................3-18
6

Headlamps....................................................5-55
Bulb Replacement.......................................5-55
Front Turn Signal, Sidemarker and Daytime
Running Lamps........................................5-56
Halogen Bulbs............................................5-55
Roof Marker Lamps.....................................5-58
Side Identication Marker Lamps...................5-57
Headphones.................................................3-129
Heated Seats................................................... 1-5
Heating.........................................................3-32
Highway Hypnosis...........................................4-44
Hill and Mountain Roads..................................4-44
Hitches..........................................................4-69
HomeLink
®Transmitter....................................2-55
HomeLink®Transmitter, Programming................2-56
Hood
Checking Things Under................................5-10
Release.....................................................5-11
Horn............................................................... 3-7
How to Add Coolant to the Coolant
Surge Tank.................................................5-34
How to Add Fluid............................................5-25
How to Check........................................5-23, 5-72
How to Check Lubricant...................................5-52
How to Check Power Steering Fluid..................5-39
How to Inspect...............................................5-21
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-28
Hydroplaning..................................................4-40
I
If No Steam Is Coming From Your Engine..........5-31
If Steam Is Coming From Your Engine...............5-30
If the Light is Flashing.....................................3-53
If the Light Is On Steady.................................3-53
If You Are Caught in a Blizzard.........................4-48
If You Are Stuck in Sand, Mud, Ice or Snow.......4-50
If You Do Decide To Pull A Trailer.....................4-63
Ignition Positions.............................................2-21
Infants and Young Children, Restraints...............1-48
Ination - Tire Pressure...................................5-72
Instrument Panel
Cluster.......................................................3-41
Overview..................................................... 3-4
Instrument Panel Brightness.............................3-19
Instrument Panel Fuse Block..........................5-114
Interior Lamps................................................3-19
J
Jump Starting.................................................5-45
K
KEYFOB X BATTERY LOW.............................3-72
Keyless Entry System....................................... 2-4
Keys............................................................... 2-3
8

Power
Accessory Outlets........................................3-21
Door Locks.................................................. 2-9
Electrical System.......................................5-113
Lumbar Controls........................................... 1-5
Seat............................................................ 1-4
Steering Fluid.............................................5-38
Windows....................................................2-16
Power Steering...............................................4-14
Power Winches..............................................4-79
Programmable Automatic Door Locks.................2-10
Programming the HomeLink
®Transmitter...........2-56
Q
QUADRASTEER™..........................................4-16
Questions and Answers About Safety Belts.........1-27
R
Radio Data System (RDS)..............3-81, 3-93, 3-108
Radio Messages.............................3-80, 3-87, 3-99
Radios..........................................................3-77
AM-FM Radio.............................................3-78
Care of Your Cassette Tape Player...............3-137
Care of Your CD and DVD Player................3-139
Care of Your CDs and DVDs.......................3-138
Radio with Cassette and CD.........................3-92
Radio with CD............................................3-81Radios (cont.)
Radio with Six-Disc CD..............................3-108
Rear Seat Audio........................................3-134
Setting the Time for Radios with Radio Data
Systems (RDS)........................................3-78
Setting the Time for Radios without Radio
Data Systems (RDS)................................3-77
Theft-Deterrent..........................................3-135
Understanding Reception............................3-137
RDS Messages.............................3-86, 3-98, 3-113
REAR ACCESS OPEN....................................3-73
Rear Air Conditioning and Heating System.........3-35
Rear Air Conditioning and Heating System and
Electronic Climate Controls...........................3-38
Rear Air Conditioning System...........................3-34
Rear Axle......................................................5-52
Locking......................................................4-11
Rear Door Security Locks................................2-12
Rear Safety Belt Comfort Guides......................1-42
Rear Seat Audio Controls...............................3-134
Rear Seat Audio (RSA)..................................3-134
Rear Seat Entertainment System.....................3-122
Rear Seat Operation......................................... 1-8
Rear Seat Outside Passenger Positions.............1-39
Rear Seat Passengers, Safety Belts..................1-39
Rear Storage Area..........................................2-62
Rear Window Defogger............................3-25, 3-33
Rearview Mirror, Automatic Dimming with
Compass and Temperature Display................2-46
12
