GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
142 Instruments and Controls
When the Light Is On Steady
This indicates that one or more of
the tires are significantly
underinflated.
A Driver Information Center (DIC)
tire pressure message may also
display. Stop as soon as possible,
and inflate the tires to the pressure
value shown on the Tire and
Loading Information label. SeeTire
Pressure 0333.
When the Light Flashes First and
Then Is On Steady
If the light flashes for about a minute
and then stays on, there may be a
problem with the TPMS. If the
problem is not corrected, the light
will come on at every ignition cycle.
See Tire Pressure Monitor
Operation 0336.Engine Oil Pressure Light
Caution
Lack of proper engine oil
maintenance can damage the
engine. Driving with the engine oil
low can also damage the engine.
The repairs would not be covered
by the vehicle warranty. Check
the oil level as soon as possible.
Add oil if required, but if the oil
level is within the operating range
and the oil pressure is still low,
have the vehicle serviced. Always
follow the maintenance schedule
for changing engine oil.
This light should come on briefly as
the engine is started. If it does not
come on, have the vehicle serviced
by your dealer. If the light comes on and stays on, it
means that oil is not flowing through
the engine properly. The vehicle
could be low on oil and might have
some other system problem. See
your dealer.
Low Fuel Warning Light
This light is near the fuel gauge and
comes on briefly when the ignition is
turned on as a check to show it is
working.
It also comes on when the fuel tank
is low on fuel. The light turns off
when fuel is added. If it does not,
have the vehicle serviced.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
Instruments and Controls 151
HUD Troubleshooting
If you cannot see the HUD image
when the ignition is on, check that:
.Nothing is covering the
HUD lens.
. The HUD brightness setting is
not too dim or too bright.
. The HUD is adjusted to the
proper height.
. Polarized sunglasses are
not worn.
. The windshield and HUD lens
are clean.
If the HUD image is not correct,
contact your dealer.
The windshield is part of the HUD
system. See Windshield
Replacement 0310.
Vehicle Messages
Messages displayed on the DIC
indicate the status of the vehicle or
some action that may be needed to
correct a condition. Multiple
messages may appear one after
another.
The messages that do not require
immediate action can be
acknowledged and cleared by
pressing
V. The messages that
require immediate action cannot be
cleared until that action is
performed.
All messages should be taken
seriously; clearing the message
does not correct the problem.
If a SERVICE message appears,
see your dealer.
Follow the instructions given in the
messages. The system displays
messages regarding the following
topics:
. Service Messages
. Fluid Levels
. Vehicle Security .
Brakes
. Steering
. Ride Control Systems
. Driver Assistance Systems
. Cruise Control
. Lighting and Bulb Replacement
. Wiper/Washer Systems
. Doors and Windows
. Seat Belts
. Airbag Systems
. Engine and Transmission
. Tire Pressure
. Battery
Engine Power Messages
ENGINE POWER IS REDUCED
This message displays when the
vehicle's propulsion power is
reduced. A reduction in propulsion
power can affect the vehicle's ability
to accelerate. If this message is on,
but there is no observed reduction
in performance, proceed to your
destination. The performance may

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
278 Driving and Operating
Contact your trailer dealer for
assistance with trailer repairs and
trailer warranty information.
Trailer Sway
Control (TSC)
Vehicles with StabiliTrak have a
Trailer Sway Control (TSC) feature.
Trailer sway is unintended
side-to-side motion of a trailer while
towing. If the vehicle is towing a
trailer and the TSC detects that
sway is increasing, the vehicle
brakes are selectively applied at
each wheel, to help reduce
excessive trailer sway. If equipped
with the Integrated Trailer Brake
Control (ITBC) system, and the
trailer has an electric brake system,
StabiliTrak may also apply the trailer
brakes.If TSC is enabled, the Traction
Control System (TCS)/StabiliTrak
warning light will flash on the
instrument cluster. Reduce vehicle
speed by gradually removing your
foot from the accelerator. If trailer
sway continues, StabiliTrak can
reduce engine torque to help slow
the vehicle. TSC will not function if
StabiliTrak is turned off. See
Traction Control/Electronic Stability
Control0226.
{Warning
Trailer sway can result in a crash
and in serious injury or death,
even if the vehicle is equipped
with TSC.
(Continued)
Warning (Continued)
If the trailer begins to sway,
reduce vehicle speed by
gradually removing your foot from
the accelerator. Then pull over to
check the trailer and vehicle to
help correct possible causes,
including an improperly or
overloaded trailer, unrestrained
cargo, improper trailer hitch
configuration, or improperly
inflated or incorrect vehicle or
trailer tires. SeeTowing
Equipment 0270 for trailer ratings
and hitch setup
recommendations.
Aftermarket Electronic Trailer
Sway Control Devices
Some trailers may come equipped
with an electronic device designed
to reduce or control trailer sway.
Aftermarket equipment
manufacturers also offer similar
devices that connect to the wiring
between the trailer and the vehicle.
These devices may interfere with

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
280 Driving and Operating
Always know the maximum speed
rating for the trailer tires before
driving. This may be significantly
lower than the vehicle tire speed
rating. The speed rating may be on
the trailer tire sidewall. If the speed
rating is not shown, the default
trailer tire speed rating is 105 km/h
(65 mph).Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector (DLC) is
used for vehicle service and
Emission Inspection/Maintenance
testing. SeeMalfunction Indicator
Lamp (Check Engine Light) 0136
. A device connected to the DLC
— such as an aftermarket fleet or
driver-behavior tracking device —
may interfere with vehicle
systems. This could affect vehicle
operation and cause a crash.
Such devices may also access
information stored in the vehicle’s
systems.
Caution
Some electrical equipment can
damage the vehicle or cause
components to not work and
would not be covered by the
vehicle warranty. Always check
with your dealer before adding
electrical equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing the Airbag-Equipped
Vehicle 084 and
Adding Equipment to the
Airbag-Equipped Vehicle 084.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
Vehicle Care 281
Vehicle Care
General Information
General Information . . . . . . . . . . 282
California Proposition65 Warning . . . . . . . . . . . . . . . . . 282
California Perchlorate Materials Requirements . . . . . 283
Accessories and Modifications . . . . . . . . . . . . . . . . 283
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . 283
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 284
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 286
Engine Oil . . . . . . . . . . . . . . . . . . . . 289
Engine Oil Life System . . . . . . . 291
Automatic Transmission Fluid (6-Speed Transmission) . . . . . 292
Automatic Transmission Fluid (10-Speed Transmission) . . . 295
Engine Air Cleaner/Filter . . . . . . 296
Cooling System . . . . . . . . . . . . . . 297
Engine Overheating . . . . . . . . . . 300
Engine Fan . . . . . . . . . . . . . . . . . . . 302
Washer Fluid . . . . . . . . . . . . . . . . . 302
Brakes . . . . . . . . . . . . . . . . . . . . . . . 303 Brake Fluid . . . . . . . . . . . . . . . . . . . 304
Battery - North America . . . . . . 305
Four-Wheel Drive . . . . . . . . . . . . . 305
Front Axle . . . . . . . . . . . . . . . . . . . . 306
Rear Axle . . . . . . . . . . . . . . . . . . . . 306
Noise Control System . . . . . . . . 306
Starter Switch Check . . . . . . . . . 308
Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 308
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . 308
Park Brake and P (Park) Mechanism Check . . . . . . . . . . 309
Wiper Blade Replacement . . . . 309
Glass Replacement . . . . . . . . . . 310
Windshield Replacement . . . . . 310
Gas Strut(s) . . . . . . . . . . . . . . . . . . 310
Headlamp Aiming
Headlamp Aiming . . . . . . . . . . . . 312
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . 312
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . . . . . . . 312
LED Lighting . . . . . . . . . . . . . . . . . 312
Fog Lamps . . . . . . . . . . . . . . . . . . . 312
Back-Up Lamps . . . . . . . . . . . . . . 313
License Plate Lamp . . . . . . . . . . 314
Electrical System
Electrical System Overload . . . 314
Fuses and Circuit Breakers . . . 315
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 315
Instrument Panel Fuse Block
(Right) . . . . . . . . . . . . . . . . . . . . . . 320
Instrument Panel Fuse Block (Left) . . . . . . . . . . . . . . . . . 323
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 325
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 326
All-Season Tires . . . . . . . . . . . . . . 327
Winter Tires . . . . . . . . . . . . . . . . . . 328
Low-Profile Tires . . . . . . . . . . . . . 328
All-Terrain Tires . . . . . . . . . . . . . . . 328
Tire Sidewall Labeling . . . . . . . . 329
Tire Designations . . . . . . . . . . . . . 330
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . . 331
Tire Pressure . . . . . . . . . . . . . . . . . 333
Tire Pressure for High-Speed Operation . . . . . . . . . . . . . . . . . . . 334
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 335
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . 336
Tire Inspection . . . . . . . . . . . . . . . . 340

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
304 Vehicle Care
Brake Fluid
The brake master cylinder reservoir
is filled with GM approved DOT 3
brake fluid as indicated on the
reservoir cap. SeeEngine
Compartment Overview 0286 for
the location of the reservoir.
Checking Brake Fluid
With the vehicle in P (Park) on a
level surface, the brake fluid level
should be between the minimum
and maximum marks on the brake
fluid reservoir.
There are only two reasons why the
brake fluid level in the reservoir may
go down:
. Normal brake lining wear. When
new linings are installed, the
fluid level goes back up. .
A fluid leak in the brake
hydraulic system. Have the
brake hydraulic system fixed.
With a leak, the brakes will not
work well.
Always clean the brake fluid
reservoir cap and the area around
the cap before removing it.
Do not top off the brake fluid.
Adding fluid does not correct a leak.
If fluid is added when the linings are
worn, there will be too much fluid
when new brake linings are
installed. Add or remove fluid, as
necessary, only when work is done
on the brake hydraulic system.
{Warning
If too much brake fluid is added, it
can spill on the engine and burn,
if the engine is hot enough. You
or others could be burned, and
the vehicle could be damaged.
Add brake fluid only when work is
done on the brake hydraulic
system. When the brake fluid falls to a low
level, the brake warning light comes
on. See
Brake System Warning
Light 0138.
Brake fluid absorbs water over time
which degrades the effectiveness of
the brake fluid. Replace brake fluid
at the specified intervals to prevent
increased stopping distance. See
Maintenance Schedule 0379.
What to Add
Use only GM approved DOT 3
brake fluid from a clean, sealed
container. See Recommended
Fluids and Lubricants 0388.
{Warning
The wrong or contaminated brake
fluid could result in damage to the
brake system. This could result in
the loss of braking leading to a
possible injury. Always use the
proper GM approved brake fluid.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-13566587) - 2020 - CRC - 4/15/19
Service and Maintenance 385
Additional
Maintenance and Care
Your vehicle is an important
investment and caring for it properly
may help to avoid future costly
repairs. To maintain vehicle
performance, additional
maintenance services may be
required.
It is recommended that your dealer
perform these services—their
trained dealer technicians know
your vehicle best. Your dealer can
also perform a thorough
assessment with a multi-point
inspection to recommend when your
vehicle may need attention.
The following list is intended to
explain the services and conditions
to look for that may indicate
services are required.
Battery
The 12-volt battery supplies power
to start the engine and operate any
additional electrical accessories. .
To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
. Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
. Belts may need replacing if they
squeak or show signs of
cracking or splitting.
. Trained dealer technicians have
access to tools and equipment
to inspect the belts and
recommend adjustment or
replacement when necessary.
Brakes
Brakes stop the vehicle and are
crucial to safe driving.
. Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping. .
Trained dealer technicians have
access to tools and equipment
to inspect the brakes and
recommend quality parts
engineered for the vehicle.
Fluids
Proper fluid levels and approved
fluids protect the vehicle’s systems
and components. See
Recommended Fluids and
Lubricants 0388 for GM approved
fluids.
. Engine oil and windshield
washer fluid levels should be
checked at every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be
filled.
Hoses
Hoses transport fluids and should
be regularly inspected to ensure
that there are no cracks or leaks.
With a multi-point inspection, your
dealer can inspect the hoses and
advise if replacement is needed.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./Cana-
da/Mexico-13566587) - 2020 - CRC - 4/15/19
Index 421
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 283
Accessory Power . . . . . . . . . . . . . . . 209
Active Fuel Management . . . . . . . 211
Adaptive Cruise Control . . . . . . . . 232
Add-On Electrical Equipment . . . 280
Additional Information OnStar . . . . . . . . . . . . . . . . . . . . . . . 412
Additional Maintenance
and Care . . . . . . . . . . . . . . . . . . . . . . 385
Adjustable Throttle and Brake Pedal . . . . . . . . . . . . . . . . . . . 201
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . 49
Air Cleaner/Filter, Engine . . . . . . . 296
Air Conditioning . . . . . . . . . . . 175, 179
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 181
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 180
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . 85
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 78
Passenger Sensing System . . . . 80
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 78 Airbag System (cont'd)
What Will You See after an
Airbag Inflates? . . . . . . . . . . . . . . . 78
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 77
Where Are the Airbags? . . . . . . . . 75
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . 84
Passenger Status Indicator . . . 135
Readiness Light . . . . . . . . . . . . . . 134
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 84
System Check . . . . . . . . . . . . . . . . . . 73
Alarm Vehicle Security . . . . . . . . . . . . . . . . 33
Alert Lane Change . . . . . . . . . . . . . . . . . 250
Side Blind Zone (SBZA) . . . . . . 249
All-Season Tires . . . . . . . . . . . . . . . . 327
All-Terrain Tires . . . . . . . . . . . . . . . . . 328
Antilock Brake System (ABS) . . . 224 Warning Light . . . . . . . . . . . . . . . . . 138
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 367
Interior . . . . . . . . . . . . . . . . . . . . . . . . 372
Armrest Storage . . . . . . . . . . . . . . . . 110

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./Cana-
da/Mexico-13566587) - 2020 - CRC - 4/15/19
422 Index
Assistance Program,Roadside . . . . . . . . . . . . . . . . . . . . . . 400
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 245
Assistance Systems for Parking and Backing . . . . . . . . . . 242
Automatic
Dimming Mirrors . . . . . . . . . . . . . . . . 39
Door Locks . . . . . . . . . . . . . . . . . . . . . 25
Emergency Braking (AEB) . . . . 248
Headlamp System . . . . . . . . . . . . 167
Level Control . . . . . . . . . . . . . . . . . 229
Transmission . . . . . . . . . . . . . . . . . 213
Transmission Fluid . . . . . . 292, 295
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 216
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 308
Axle, Front . . . . . . . . . . . . . . . . . . . . . . 306
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 306
B
Battery Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 173
Load Management . . . . . . . . . . . . 172 Battery (cont'd)
Power Protection . . . . . . . . . . . . . 172
Battery - North America . . . . 305, 360
Blade Replacement, Wiper . . . . . 309
Blind Spot Mirrors . . . . . . . . . . . . . . . 39
Brake Pedal and AdjustableThrottle . . . . . . . . . . . . . . . . . . . . . . 201
System Warning Light . . . . . . . . 138
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 303 Antilock . . . . . . . . . . . . . . . . . . . . . . . 224
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 225
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 304
Parking . . . . . . . . . . . . . . . . . . . . . . . 225
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 186 AutomaticEmergency (AEB) . . . . . . . . . . . 248
Break-In, New Vehicle . . . . . . . . . . 201
Bulb Replacement
Back-up Lamps . . . . . . . . . . . . . . . 313
Fog Lamps . . . . . . . . . . . . . . . . . . . 312
Headlamp Aiming . . . . . . . . . . . . . 312
Headlamps . . . . . . . . . . . . . . . . . . . 312
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . 312
License Plate Lamps . . . . . . . . . 314
Buying New Tires . . . . . . . . . . . . . . . 342
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 119
California Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 283
California Proposition
65 Warning . . . . . . . . . .282, 305, 360, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and
Specifications . . . . . . . . . . . . . . . . . 393
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 212
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 27
Winter Driving . . . . . . . . . . . . . . . . 194
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . .112
Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . 110
Center Seat . . . . . . . . . . . . . . . . . . . . . 48
Chains, Tire . . . . . . . . . . . . . . . . . . . . 347
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . 122
Charging System Light . . . . . . . . . 135
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 136

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./Cana-
da/Mexico-13566587) - 2020 - CRC - 4/15/19
Index 423
Check (cont'd)Ignition Transmission Lock . . . 308
Child Restraints Infants and Young Children . . . . . 88
Lower Anchors and Tethers
for Children . . . . . . . . . . . . . . . . . . . 93
Older Children . . . . . . . . . . . . . . . . . . 86
Securing . . . . . . . . . . . . 103, 105, 106
Systems . . . . . . . . . . . . . . . . . . . . . . . . 90
Child-View Mirror . . . . . . . . . . . . . . . . 41
Circuit Breakers . . . . . . . . . . . . . . . . 315
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 367
Interior Care . . . . . . . . . . . . . . . . . . 372
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . . 175
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Cluster, Instrument . . . . . . . . . . . . . 126
Collision Damage Repair . . . . . . . 403
Compartments
Storage . . . . . . . . . . . . . . . . . . . . . . . 109
Compass . . . . . . . . . . . . . . . . . . . . . . . 119
Connected Services
Connections . . . . . . . . . . . . . . . . . . 419
Diagnostics . . . . . . . . . . . . . . . . . . . 420
Navigation . . . . . . . . . . . . . . . . . . . . 418 Connections
Connected Services . . . . . . . . . . 419
Control Hill Descent . . . . . . . . . . . . . . . . . . 228
Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 226
Control of a Vehicle . . . . . . . . . . . . . 186
Convenience Net . . . . . . . . . . . . . . . 112
Convex Mirrors . . . . . . . . . . . . . . . . . . 37
Coolant Engine Temperature Gauge . . 131
Engine Temperature
Warning Light . . . . . . . . . . . . . . . 141
Cooling . . . . . . . . . . . . . . . . . . . . 175, 179
Cooling System . . . . . . . . . . . . . . . . . 297
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . 402
Cruise Control . . . . . . . . . . . . . . . . . . 230 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Cruise Control, Adaptive . . . . . . . . 232
Cupholders . . . . . . . . . . . . . . . . . . . . . 109
Customer Assistance . . . . . . . . . . . 399 Offices . . . . . . . . . . . . . . . . . . . . . . . . 398
Text Telephone (TTY)Users . . . . . . . . . . . . . . . . . . . . . . . 399
Customer Information Publications OrderingInformation . . . . . . . . . . . . . . . . . . 405 Customer Satisfaction
Procedure . . . . . . . . . . . . . . . . . . . . . 396
Cybersecurity . . . . . . . . . . . . . . . . . . . 408
D
Damage Repair, Collision . . . . . . . 403
Danger, Warning, and Caution . . . . 3
Data Collection Infotainment System . . . . . . . . . . 409
OnStar . . . . . . . . . . . . . . . . . . . . . . . 409
Data Recorders, Event . . . . . . . . . 408
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 167
Defensive Driving . . . . . . . . . . . . . . . 185
Delayed Locking . . . . . . . . . . . . . . . . . 25
Diagnostics Connected Services . . . . . . . . . . 420
Distracted Driving . . . . . . . . . . . . . . . 184
Dome Lamps . . . . . . . . . . . . . . . . . . . 170
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 144
Delayed Locking . . . . . . . . . . . . . . . . 25
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Power Locks . . . . . . . . . . . . . . . . . . . . 25
Drive Belt Routing, Engine . . . . . . 395
Driver Assistance Systems . . . . . 240
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . 144
