4-11An emergency like this requires close attention and a
quick decision. If you are holding the steering wheel at
the recommended 9 and 3 o'clock positions, you can
turn it a full 180 degrees very quickly without removing
either hand. But you have to act fast, steer quickly, and
just as quickly straighten the wheel once you have
avoided the object.
The fact that such emergency situations are always
possible is a good reason to practice defensive driving
at all times and wear safety belts properly. Off -
Road Recovery You may find that your right wheels have dropped off the
edge of a road onto the shoulder while you're driving.
If the level of the shoulder is only slightly below the
pavement, recovery should be fairly easy. Ease off the
accelerator and then, if there is nothing in the way, steer
so that your vehicle straddles the edge of the pavement.
You can turn the steering wheel up to one
- quarter turn
until the right front tire contacts the pavement edge. Then
turn your steering wheel to go straight down the roadway.

4-21Q: What should I do if my vehicle stalls, or is about
to stall, and I can't make it up the hill?
A: If this happens, there are some things you should
do, and there are some things you must not do.
First, here's what you should do:

Push the brake pedal to stop the vehicle and keep
it from rolling backwards. Also, apply the
parking brake.

If your engine is still running, shift the transmission
to REVERSE (R), release the parking brake, and
slowly back down the hill in REVERSE (R).

If your engine has stopped running, you'll need to
restart it. With the brake pedal pressed and the
parking brake still applied, shift the transmission to
PARK (P) and restart the engine. Then, shift to
REVERSE (R), release the parking brake, and
slowly back down the hill as straight as possible
in REVERSE (R).
As you are backing down the hill, put your left hand
on the steering wheel at the 12 o'clock position. This
way, you'll be able to tell if your wheels are straight
and maneuver as you back down. It's best that you
back down the hill with your wheels straight rather
than in the left or right direction. Turning the wheel
too far to the left or right will increase the possibility
of a rollover.
Here are some things you must not do if you stall, or are
about to stall, when going up a hill.

Never attempt to prevent a stall by shifting into
NEUTRAL (N) to ªrev
- upº the engine and regain
forward momentum. This won't work. Your vehicle
will roll backwards very quickly and you could go
out of control.
Instead, apply the regular brake to stop the vehicle. Then
apply the parking brake. Shift to REVERSE (R), release
the parking brake, and slowly back straight down.

Never attempt to turn around if you are about to stall
when going up a hill. If the hill is steep enough to
stall your vehicle, it's steep enough to cause you to
roll over if you turn around. If you can't make it up
the hill, you must back straight down the hill.

5-16 The coolant surge tank on
your vehicle may be
equipped with one of the
two caps shown.
1. Park the vehicle on a level surface. You can remove
the coolant surge tank pressure cap when the cooling
system, including the coolant surge tank pressure cap
and upper radiator hose, is no longer hot. Turn the
pressure cap slowly counterclockwise (left) about
one full turn. If you hear a hiss, wait for that to stop.
A hiss means there is still some pressure left.

5-22 Yukon XL Denali Models
A. Bottle Jack
B. Wheel Blocks
C. Wing Nut
D. Mounting Bracket
E. Removable Tray F. Retaining Hook
G. Retaining Bracket
and Wing Nut
H. Tool Kit with Jack
Tools and Gloves Yukon Denali: The equipment you'll need is located
under the second row passenger's seat on the driver's
side of the vehicle, and behind the left trim panel on the
driver's side of the vehicle. Skip the first step and follow
the last three.
Yukon XL Denali: The equipment you'll need is
located under the storage tray in the rear trim panel on
the driver's side of the vehicle.
1. Remove the tray to access the tools.
2. There is a wing nut used to retain the tool kit.
To remove it, turn the wing nut counterclockwise.
3. To release the bottle jack from its holder, turn the
knob on the bottle jack counterclockwise to lower
the jack head.
4. The wheel blocks and the wheel block retainer can be
removed by turning the wing nut counterclockwise.
You'll use the jack handle extensions and the wheel
wrench to remove the underbody
- mounted spare tire.

5-24 3. Insert the hoist end
(open end) (F) of the
extension through
the hole (G) in the
rear bumper.
Be sure the hoist end of the extension connects into
the hoist shaft (E). The ribbed square end of the
extension is used to lower the spare tire.
4. Turn the wheel wrench (H) counterclockwise to
lower the spare tire to the ground. Continue to turn
the wheel wrench until the spare tire can be pulled
out from under the vehicle. 5. The wheel wrench has a
hook that allows you to
pull the hoist cable
towards you to assist in
reaching the spare tire.
6. When the tire has
been lowered, tilt the
retainer (D) at the end of
the cable so it can be
pulled up through the
wheel opening.
7. Put the spare tire near the flat tire.
Use the following pictures and instructions to remove
the flat tire and raise the vehicle.

5-26 Turn the wheel wrench clockwise to raise the jack lift
head to the lifting point. To remove the center cap place the chisel end of the
wheel wrench in the slot on the wheel and gently
pry out.

5-27Removing the Flat Tire and Installing the
Spare Tire 1. Use the wheel wrench to loosen all the wheel nuts.
Turn the wheel wrench counterclockwise to loosen
the wheel nuts. Don't remove the wheel nuts yet.
Jack Positions (overall view)
These locations are the general area of jack
placement. See text and art following for the exact
jack placement. CAUTION: Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
CAUTION: Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to fit the jack
lift head into the proper location before raising
the vehicle.

5-28 2. Position the jack under the vehicle.
Front Position
Front Tire Flat: Position the jack on the frame behind
the flat tire where the frame sections overlap. Raise the
vehicle far enough off the ground so there is enough
room for the spare tire to fit clear the ground. Rear Tire Flat: Use the
jacking pad provided on the
rear axle. Turn the wheel
wrench clockwise to raise
the vehicle. Raise the
vehicle far enough off the
ground so there is enough
room for the spare tire to
clear the ground.
Rear Position

5-30 5. After mounting the
spare, put the wheel
nuts back on with the
rounded end of the nuts
toward the wheel.
Tighten each wheel nut
by hand. Then use the
wheel wrench to tighten
the nuts until the wheel
is held against the hub.
Front Position 6. Turn the wheel wrench
counterclockwise to
lower the vehicle. Lower
the jack completely.
Rear Position

5-317. Tighten the nuts
firmly in a crisscross
sequence as shown
by turning the wheel
wrench clockwise.
CAUTION:Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to become loose
and even come off. This could lead to an accident.
Be sure to use the correct wheel nuts. If you have
to replace them, be sure to get new GM original
equipment wheel nuts.
Stop somewhere as soon as you can and have the
nuts tightened with a torque wrench to the
proper torque. See ªCapacities and
Specificationsº in the Index. NOTICE: Improperly tightened wheel nuts can lead to
brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specification.
When you reinstall the regular wheel and tire, you must
also reinstall the center cap. Place the cap on the wheel
and tap it into place until it seats flush with the wheel.
