1-74 4. Buckle the belt. Make sure the release button is
positioned so you would be able to unbuckle the
safety belt quickly if you ever had to.
5. To tighten the belt, pull its free end while you push
down on the child restraint. If you're using a
forward
- facing child restraint, you may find it
helpful to use your knee to push down on the child
restraint as you tighten the belt.
6. Push and pull the child restraint in different
directions to be sure it is secure.
To remove the child restraint, just unbuckle the vehicle's
safety belt. It will be ready to work for an adult or larger
child passenger.

1-75Securing a Child Restraint in the Right
Front Seat Position
Your vehicle has a right front passenger air bag. Never
put a rear
- facing child restraint in this seat. Here's why: CAUTION: A child in a rear
- facing child restraint can be
seriously injured or killed if the right front
passenger's air bag inflates. This is because the
back of the rear
- facing child restraint would be
very close to the inflating air bag. Always secure
a rear
- facing child restraint in the rear seat.
Although a rear seat is a safer place, you can secure a
forward
- facing child restraint in the right front seat.
You'll be using the lap
- shoulder belt. See the earlier
part about the top strap if the child restraint has one.
Be sure to follow the instructions that came with the
child restraint. Secure the child in the child restraint
when and as the instructions say.
1. Because your vehicle has a right front passenger air
bag, always move the seat as far back as it will go
before securing a forward
- facing child restraint.
See ªSeatsº in the Index.
2. Put the restraint on the seat.

1-76 3. Pick up the latch plate, and run the lap and shoulder
portions of the vehicle's safety belt through or
around the restraint. The child restraint instructions
will show you how.
If the shoulder belt goes in front of the child's face or
neck, put it behind the child restraint.
4. Buckle the belt. Make sure the release button is
positioned so you would be able to unbuckle the
safety belt quickly if you ever had to. 5. Pull the rest of the shoulder belt all the way out of
the retractor to set the lock.

1-776. To tighten the belt, feed the shoulder belt back into the
retractor while you push down on the child restraint.
You may find it helpful to use your knee to push down
on the child restraint as you tighten the belt.
7. Push and pull the child restraint in different
directions to be sure it is secure.
To remove the child restraint, just unbuckle the vehicle's
safety belt and let it go back all the way. The safety belt
will move freely again and be ready to work for an adult
or larger child passenger.

1-78Older Children
Older children who have outgrown booster seats should
wear the vehicle's safety belts.
If you have the choice, a child should sit next to a
window so the child can wear a lap
- shoulder belt and
get the additional restraint a shoulder belt can provide. Q: What is the proper way to wear safety belts?
A: If possible, an older child should wear a
lap
- shoulder belt and get the additional restraint a
shoulder belt can provide. The shoulder belt should
not cross the face or neck. The lap belt should fit
snugly below the hips, just touching the top of the
thighs. It should never be worn over the abdomen,
which could cause severe or even fatal internal
injuries in a crash.
Accident statistics show that children are safer if they
are restrained in the rear seat.
In a crash, children who are not buckled up can strike
other people who are buckled up, or can be thrown
out of the vehicle. Older children need to use safety
belts properly.

1-79CAUTION: Never do this.
Here two children are wearing the same belt.
The belt can't properly spread the impact forces.
In a crash, the two children can be crushed
together and seriously injured. A belt must be
used by only one person at a time.
Q: What if a child is wearing a lap
- shoulder belt,
but the child is so small that the shoulder belt is
very close to the child's face or neck?
A: Move the child toward the center of the vehicle, but
be sure that the shoulder belt still is on the child's
shoulder, so that in a crash the child's upper body
would have the restraint that belts provide. If the
child is sitting in a rear seat outside position, see
ªRear Safety Belt Comfort Guidesº in the Index.
If the child is so small that the shoulder belt is still
very close to the child's face or neck, you might
want to place the child in a seat that has a lap belt,
if your vehicle has one.

1-80 CAUTION: Never do this.
Here a child is sitting in a seat that has a
lap
- shoulder belt, but the shoulder part is behind
the child. If the child wears the belt in this way,
in a crash the child might slide under the belt.
The belt's force would then be applied right on
the child's abdomen. That could cause serious or
fatal injuries.
Wherever the child sits, the lap portion of the belt
should be worn low and snug on the hips, just touching
the child's thighs. This applies belt force to the child's
pelvic bones in a crash.

1-81Safety Belt Extender If the vehicle's safety belt will fasten around you,
you should use it.
But if a safety belt isn't long enough to fasten, your
dealer will order you an extender. It's free. When you go
in to order it, take the heaviest coat you will wear, so the
extender will be long enough for you. The extender will
be just for you, and just for the seat in your vehicle that
you choose. Don't let someone else use it, and use it
only for the seat it is made to fit. To wear it, just attach
it to the regular safety belt.
Checking Your Restraint Systems Now and then, make sure the safety belt reminder light
and all your belts, buckles, latch plates, retractors and
anchorages are working properly. Look for any other
loose or damaged safety belt system parts. If you see
anything that might keep a safety belt system from
doing its job, have it repaired.
Torn or frayed safety belts may not protect you in a
crash. They can rip apart under impact forces. If a belt
is torn or frayed, get a new one right away.
Also look for any opened or broken air bag covers, and
have them repaired or replaced. (The air bag system
does not need regular maintenance.) Replacing Restraint System Parts
After a Crash If you've had a crash, do you need new belts or LATCH
system parts?
After a very minor collision, nothing may be necessary.
But if the belts were stretched, as they would be if worn
during a more severe crash, then you need new parts.
If the LATCH system was being used during a more
severe crash, you may need new LATCH system parts.
If belts are cut or damaged, replace them. Collision
damage also may mean you will need to have LATCH
system, safety belt or seat parts repaired or replaced.
New parts and repairs may be necessary even if the belt
or LATCH system wasn't being used at the time of
the collision.
If an air bag inflates, you'll need to replace air bag
system parts. See the part on the air bag system earlier
in this section.

2-
2-1Section 2 Features and ControlsHere you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
- 2 Windows
2
- 4 Keys
2
- 6 Door Locks
2
- 9 Keyless Entry System
2
- 12 Liftgate/Liftgate Glass
2
- 12 Theft
2
- 14 Content Theft
- Deterrent
2
- 15 Passlock

2
- 16 New Vehicle ªBreak Inº
2
- 16 Ignition Positions
2
- 17 Starting Your Engine
2
- 19 Engine Coolant Heater (If Equipped)
2
- 20 Automatic Transmission Operation
2
- 23 Parking Brake
2
- 24 Shifting Into PARK (P)
2
- 27 Shifting Out of PARK (P)
2
- 27 Parking Over Things That Burn
2
- 28 Engine Exhaust 2
- 28 Running Your Engine While You're Parked
2
- 30 Locking Rear Axle
2
- 30 All
- Wheel Drive
2
- 30 Tilt Wheel
2
- 31 Turn Signal/Multifunction Lever
2
- 37 Exterior Lamps
2
- 41 Interior Lamps
2
- 42 Mirrors
2
- 46 Storage Compartments
2
- 54 OnStar

System (If Equipped)
2
- 57 Sunroof (If Equipped)
2
- 58 HomeLink

Transmitter
2
- 62 The Instrument Panel
- Your
Information System
2
- 64 Instrument Panel Cluster
2
- 65 Warning Lights, Gages and Indicators
2
- 77 Message Center
2
- 83 Secondary Information Center (SIC)

2-2Windows
CAUTION:Leaving children in a vehicle with the windows
closed is dangerous. A child can be overcome by
the extreme heat and can suffer permanent
injuries or even death from heat stroke. Never
leave a child alone in a vehicle, especially with
the windows closed in warm or hot weather.
