2-20Automatic Transmission Operation
There are several different positions for your shift lever.
Your vehicle is equipped with an automatic transmission
and features an electronic shift position indicator located
within the instrument panel cluster. This display is
powered anytime the shift lever is capable of being
moved out of PARK (P). This means that if your key is
in OFF, rather than LOCK, there will be a small current
drain on your battery which could discharge your battery
over a period of time. If you have to leave your key in
the ignition in OFF for an extended period, it is
recommended that you remove the IGN 0 fuse from the
instrument panel fuse block. See ªFuses and Circuit
Breakersº in the Index. PARK (P): This position locks your rear wheels. It's the
best position to use when you start your engine because
your vehicle can't move easily.
CAUTION: It is dangerous to get out of your vehicle if the
shift lever is not fully in PARK (P) with the
parking brake firmly set. Your vehicle can roll.
Don't leave your vehicle when the engine is
running unless you have to. If you have left the
engine running, the vehicle can move suddenly.
You or others could be injured. To be sure your
vehicle won't move, even when you're on fairly
level ground, always set your parking brake and
move the shift lever to PARK (P).
See ªShifting Into PARK (P)º in the Index.
If you're pulling a trailer, see ªTowing a Trailerº
in the Index.

2-42Dome Lamps The dome lamps will come on when you open a door
and will slowly dim to off when all doors are closed.
You can also turn the dome lamps on by turning the
thumbwheel, located next to the exterior lamp control,
all the way up. In this position, the dome lamps will
remain on whether a door is opened or closed.
You can use the DOME OVERRIDE button, located
below the exterior lamp control, to set the dome lamps
to come on automatically when a door is opened, or
remain off. To turn the lamps off, press the button into
the in position. With the button in this position, the
dome lamps will remain off when the doors are open. To
return the lamps to automatic operation, press the button
again and return it to the out position. With the button in
this position, the dome lamps will come on when you
open a door.
Battery Run-Down Protection This feature shuts off the dome, reading, glove box and
underhood lamps if they are left on for more than 20
minutes when the ignition is off. This will keep your
battery from running down. Mirrors Electrochromic Inside Rearview Mirror
with Compass and Temperature Display When on, an electrochromic mirror automatically dims
to the proper level to minimize glare from lights behind
you after dark.
The electrochromic mirror will always revert to on when
the vehicle is started.
The mirror also includes a display of both the compass
and the temperature in the upper right corner of the
mirror face. The dual display can be turned on or off by
briefly pressing either the TEMP or COMP button.

2-43Temperature Display
Pressing the TEMP button once briefly will toggle the
compass/temperature reading on and off. To alternate
the temperature reading between Fahrenheit and Celsius,
press and hold the TEMP button for three seconds until
the display blinks F
and C
. Press and release the
TEMP button to toggle between the Fahrenheit and
Celsius readings. After five seconds of inactivity, the
display will stop flashing and stay at the last setting.
If an abnormal reading is displayed, please consult
your dealer. Electrochromic Mirror Operation
Each time the vehicle is started, the electrochromic
mirror is activated. If you do not want it on, then you
will have to manually turn it off. The time period you
need to press and hold the TEMP button to turn the
electrochromic feature on or off is six seconds. The
indicator light to the right of the TEMP button will
turn on or off to show you when the electrochromic
feature is activated.
Compass Operation
With the ignition on, the compass will show
two character boxes. The mirror will display the
compass heading.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.

2-44 Compass Calibration
The compass may need calibration if:

After five seconds, the display does not show a
compass heading (N for North, for example), there
may be a strong magnetic field interfering with the
compass. Such interference may be caused by a
magnetic antenna mount, magnetic note pad holder
or a similar magnetic item.

The compass does not display the correct heading
and the compass zone variance is set correctly.
In order to calibrate, the letters CAL must be displayed
in the mirror compass windows. If CAL is not
displayed, push in the COMP button for approximately
eight seconds or until the letters CAL are displayed.
The compass can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

drive the vehicle on your everyday routine and after
several turns the compass will become calibrated and
will display a direction. Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
- country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance, do the following:
1. Press and hold the COMP button located at the
bottom of the mirror for three seconds until a zone
number appears in the display.
2. Find your current location and variance zone number
on the following zone map.

2-453. Press the COMP button on the bottom of the mirror
until the new zone number appears in the display.
After you stop pressing the button in, the display will
show a compass direction within a few seconds. Power Outside Rearview Mirrors
The control is located on the driver's door armrest.
Move the upper selector switch to the left or right
to choose the mirror you want to adjust, then press
the arrows located on the lower control pad to adjust
the mirror.
The mirrors include ground illumination lamps (puddle
lamps) in the base of the mirror. For more information
on these lamps, see ªPuddle Lampsº in the Index.

2-46Driver's Outside Auto-Dimming
Rearview Mirror The driver's outside mirror will adjust for the glare of
headlamps behind you. This feature is controlled by the
on and off settings on the electrochromic mirror. See
ªElectrochromic Inside Rearview Mirror with Compass
and Temperature Displayº earlier in this section.
Convex Outside Mirror Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat.
CAUTION:A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes. Heated Outside Rearview Mirrors The outside rearview mirrors have a defrost mode.
To turn on the defrost feature, press the rear window
defogger button. See ªRear Window Defoggerº in the
Index for further information.
Storage Compartments Glove Box To open your glove box, lift up the latch and pull the
door open.

2-65Speedometer and Odometer Your speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour (km/h).
Your odometer shows how far your vehicle has been
driven, in either miles (used in the United States) or
kilometers (used in Canada).
Trip Odometer
The trip odometer can tell you how far your vehicle has
been driven since you last set the trip odometer to zero.
Press the reset button to toggle between the trip
odometer and the regular odometer. Holding the reset
button for two seconds while the trip odometer is
displayed will reset it.
To display the odometer reading with the ignition off,
press the reset button.
Engine Hour Meter Display
The odometer can also display the number of hours the
engine has run. To display the hour meter, turn the
ignition off, press and hold the reset button for at least
four seconds. The hour meter will be displayed for up to
30 seconds, or until the ignition is turned on. Tachometer Your tachometer displays the engine speed in
revolutions per minute (rpm).
Warning Lights, Gages
and Indicators This part describes the warning lights and gages on your
vehicle. The pictures will help you locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.

2-70Engine Coolant Temperature Gage
United States Canada
This gage shows the engine coolant temperature.
It also provides an indicator of how hard your vehicle is
working. During a majority of the operation, the gage
will read 210
F (100
C) or less. If you are pulling a
load or going up hills, it is normal for the temperature to
fluctuate and approach the 250
F (122
C) mark. If the
gage reaches the 260
F (125
C) mark, it indicates that
the cooling system is working beyond its capacity.
The ªProblems on the Road,º section of this manual
shows what to do. See ªEngine Overheatingº in
the Index. Transmission Temperature Gage
United States Canada
When your ignition is on, the gage shows the
temperature of the transmission fluid. The normal
operating range is from 100
F (38
C) to about
265
F (130
C).
At approximately 265
F (130
C), the message center
will display a TRANS FLUID HOT message and the
transmission will enter a transmission protection mode.
When the transmission enters the protection mode, you
may notice a change in the transmission shifting
patterns. The transmission will return to normal shifting
patterns when the transmission fluid temperature falls
below 260
F (127
C).

2-71See ªMessage Centerº in the Index for further information.
If the transmission fluid reaches temperatures of
approximately 275
F (135
C) or greater, the message
center will display a TRANS HOT...IDLE ENG warning
message. Pull the vehicle off the roadway when it is safe
to do so. Set the parking brake, place the transmission in
PARK (P) and allow the engine to idle until the
transmission temperature falls below 260
F (127
C).
If the transmission continues to operate above 265
F
(130
C), please contact your nearest dealer or the GM
Roadside Assistance Center.
NOTICE: If you keep driving your vehicle with the
transmission temperature gage above the
normal operating range, you can damage the
transmission. This could lead to costly repairs
that may not be covered under your warranty. The following situations can cause the transmission to
operate at higher temperatures:

Towing a trailer

Hot outside air temperatures

Hauling a large or heavy load

Low transmission fluid level

High transmission fluid level

Restricted air flow to the radiator and the auxiliary
transmission oil cooler (if equipped).
A temporary solution to hotter transmission operating
temperatures may be to let the transmission cool down.
If the transmission is operated at higher temperatures on
a frequent basis, see ªScheduled Maintenanceº in the
Index for the proper transmission maintenance intervals.

2-76Cruise Light
United States Canada
The CRUISE light comes on whenever you set your
cruise control. See ªCruise Controlº in the Index.
Tow/Haul Light This light is displayed
when the tow/haul mode
has been activated.
For more information, see ªTow/Haul Modeº in
the Index. Fuel Gage
United States Canada
The fuel gage, when the ignition is on, tells you about
how much fuel you have left in your tank.
The gage will first indicate empty before you are out of
fuel, and you should get more fuel as soon as possible.
