Page 151 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-40
Change of Lower Arm Shaft Bush and Tube
1. Tear down the lower arm shaft bush and shaft tube:
(a) Tear down the large and small pinch-off gaskets of the
lower arm shaft bush first.
(b) Tear down

Page 152 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-41
4. Mount the transverse stabilizer rod on the lower arm;
Fastening torque(23)Nm
5. Check the Alignment of Front Wheel;
(See Page SA-6)
Suspension System and Automobile Axle (SF/2WD)Front Sus

Page 153 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-42
Upper Arm
Dismantle of Upper Arm
1. Tear down the torsion rod spring:
(See page SA-19)
2. Tear down the upper ball stud:
(a) Support the upper arm with a jack.
(b) Tear down the four sets of bol

Page 154 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-43
Mount of Upper Arm
1. Screw up the axle nut of upper arm according to the
specified torque;
Fastening torque(225)Nm
2. Mount on the upper arm;
Screw up the three bolts of the upper swing arm

Page 155 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-44
Front Wheel Hub and Steering Knuckle
Element Figure
Suspension System and Automobile Axle (SF/4WD)Front Wheel Hub and Steering Knuckle
lock ring
cushion block nut
lock ring
cushion
block
shock

Page 156 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-45
2. Tear down the free hub.
3. Tear down the retainer ring and the axle spine of washer-
steering knuckle:
Tear down the retainer ring with the pliers for retainer ring, and
take down the axle sp

Page 157 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-46
5. Tear down the front hub, the oil seal and the inner race
of front hub bearing (inner)
(a) Prize out the oil seal.
(b) Take out the inner race of front hub bearing (inner).
6. Inspection on an

Page 158 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-47
Assembly of Front Wheel Hub
1. Mount on the inner race and roller assembly of front hub
bearing as well as the oil seal of front hub.
Coat the lithium base grease of (4-5)mm on the inside surfac

Page 159 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-48
(e) Hold the bolt of front wheel hub with the spring-tension meter
and drag slowly in the direction of the spot tangent line.
Suitable tension range(29-54)N
The nut should be screwed up again w

Page 160 of 484

GREAT WALL PEGASUS 2006  Service Manual SA-49
Steering Knuckle
Dismantle of Steering Knuckle
1. Tear down the brake caliper, he front wheel and the front
brake disc.
2. Tear down the dust cover and the brake shell;
3. Tear down the steering
