AC-18Air-Conditioning System
Evaporator
SYrear evaporator
upper housing
air cover
lower housing temperature controller air blowerevaporator core air pipeheat-sensitive resistance
1. Tear down the evaporator housing:
(a) Disconnect the plugging element;
(b) Tear down the two clipes;
(c) Tear down the four screws;
(d) Tear down the upper cluster housing;
(e) Tear down the HP/LP pressure pipe rubber washers; and
(f) Tear down the lower cluster housing.
2. Tear down the expansion valve:
(a) Tear down the liquid pipe from the entrance joint of
expansion valve;
(b) Tear down the sealing washer and thermal bulb from the
suction pipe of evaporator;
(c) Tear down the expansion valve.
expansion valve
HP pipe LP pipe
