HONDA ACCORD 2001 CF / 6.G Owners Manual

Your car has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.
If your car’s battery has been
disconnected or gone dead, these
codes are erased. It takes several
days of driving under various
conditions to set the codes again.If possible, do not take your car f or a
state emissions test until the
readiness codes are set. To check if
they are set, turn the ignition ON (II),
but do not start the engine. The
Malf unction Indicator Lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks 5 times, the readiness
codes are not set. See State
Emissions Testing on pages and
. 301
302
(L4-ULEV, V6)
Malf unction Indicator L amp
T aking Care of t he Unexpect ed
Readiness Codes 312

ÎÎ
ÎÎIf it comes on at any other time, it
indicates a problem with the car’s
brake system. In most cases, the
problem is a low f luid level in the
brake f luid reservoir. Press lightly on
the brake pedal to see if it f eels
normal. If it does, check the brake
f luid level the next time you stop at a
service station (see page ). If the
fluid level is low, take the car to your
dealer and have the brake system
inspected f or leaks or worn brake
pads.
However, if the brake pedal does not
f eel normal, you should take
immediate action. Because of the
brake system’s dual-circuit design, a
problem in one part of the system
will still give you braking at two
wheels. You will f eel the brake pedal
go down much f arther bef ore the car
begins to slow down, and you will
have to press harder on the pedal.
The distance needed to stop will be
much longer. Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the
longer distance needed to stop, it is
hazardous to drive the car. You
should have it towed, and repaired as
soon as possible. (See
on page .)
If you must drive the car a short
distance in this condition, drive
slowly and cautiously.
The Brake System Indicator
normallycomesonwhenyouturn
the ignition switch ON (II). It is a
reminder to check the parking brake.
It comes on and stays lit if you do not
f ully release the parking brake. 251
320Emergency
Towing
Brake System Indicator
T aking Care of t he Unexpect ed 313
UU..SS..iinnddiiccaattoorrsshhoowwnn
BBRRAAKKEESSYYSSTTEEMMIINNDDIICCAATTOORR

Use a screwdriver or coin to
remove the round plug in the
center of the headliner.Remove the wrench. Replace the
round plug.
If the electric motor will not close
the moonroof , do the f ollowing:
Check the f use f or the moonroof
motor (see page ). If the f use
is blown, replace it with one of the
same or lower rating.
Try closing the moonroof . If the
new f use blows immediately or the
moonroof motor still does not
operate, you can close the
moonroof manually. Insert the moonroof wrench into
the socket behind this plug. Turn
the wrench until the moonroof is
f ully closed.
Get the moonroof wrench out of
the tool kit in the trunk.
5. 6.
4.
1.
2.
3. 315
Closing t he Moonroof
T aking Care of t he Unexpect ed
314
SSOOCCKKEETTRROOUUNNDDPPLLUUGG

The under-hood f use box is located
in the back of the engine compart-
ment on the passenger’s side. To
open it, push the tabs as shown.
All the electrical circuits in your car
have fuses to protect them from a
short circuit or overload. These
f uses are located in three f use boxes.
Theinteriorfuseboxesarelocated
on each side of the dashboard. To
open an interior f use box, open the
car door. Pull the cover open, then
take it out of its hinges by pulling it
toward you.
Fuses
T aking Care of t he Unexpect ed315
IINNTTEERRIIOORRUUNNDDEERR--HHOOOODDTTAABB

Turn the ignition switch to LOCK
(0). Make sure the headlights and
all other accessories are off.
Remove the cover f rom the f use
box.Check each of the large f uses in
the under-hood f use box by
looking through the top at the wire
inside. Removing these f uses
requires a Phillips-head screw-
driver.
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each f use with the f use
puller provided in the under-hood
fuse box.
If something electrical in your car
stops working, the f irst thing you
should check f or is a blown f use.
Determine f rom the chart on pages
and , or the diagram on the
fuse box lid, which fuse or fuses
control that component. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
not the cause. Replace any blown
f uses and check the component’s
operation. 3.
1. 2. 4.
318 319
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed
316
BBLLOOWWNN
FFUUSSEEPPUULLLLEERR

Look f or a burned wire inside the
f use. If it is burned, replace it with
oneof thesparefusesof thesame
rating or lower.If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your car.
Leave the blown fuse in that
circuit and have your car checked
by a qualif ied mechanic.
If you cannot drive the car without
f ixing the problem, and you do not
have a spare fuse, take a fuse of the
same rating or a lower rating f rom
one of the other circuits. Make sure
youcandowithoutthatcircuit
temporarily (such as the cigarette
lighter or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
5. 6.
Fuses
T aking Care of t he Unexpect ed
317
BBLLOOWWNN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a replace-
ment f use with the proper rating f or the
circuit, install one with a lower rating.

µµ
No.
No.
Amps. Amps. Circuits Protected
Circuits Protected
1 23456789
1011 12131415161718192021
20 A
(7.5A) 20 A
20 A
20 A
15 A
30 A
15 A
100 A 20 A 40 A
40 A
40 A
20 A
40 A
40 A
20 A
20 A
50 A
Back Up, ACC
Power Window Motor
Spare Fuse
Power Seat
BSC
Heater Motor
Rear Defroster
Heated Seat
Condenser Fan
IG1 Main
Lef t Headlight
(DIMMER RELAY)
Right Headlight
ABS F/S
Stop
ACG
ABS Motor
Hazard
Spare Fuse
Battery
Cooling Fan
Fuses
T aking Care of t he Unexpect ed
318
UNDER-HOOD FUSE BOX

ÎÎ
Î
Î
On Canadian models
1 23456 7 89
10111213 15 A
10 A
7.5 A
7.5 A
7.5 A 15 A
7.5 A
7.5 A
7.5 A
7.5 A 15 A
30 A
7.5 A IG1 Fuel Pump
IG1 SRS
IG2 HAC
R/C Mirror
IG2 Day Light
ECU (ECM/PCM), Cruise
Control
IG1 Moonroof , Washer
ACC
Instrument Panel, Back-up
Lights
IG1 Turn Signals
IG1 Coil
IG1 Wiper
STS Moonroof
Driver Power Seat Recline
Assistant Power Seat
Recline
Driver Power Seat Slide
Assistant Power Seat Slide
Daytime Running Light
Rear Lef t Power Window
Front Right Power Window
Radio, Cigarette Lighter
Small Lights
Interior Light, Courtesy
Lights
Power Door Locks
Clock
ABS Motor Check
Front Lef t Power Window
Rear Right Power Window
On Canadian models
123 4 56789
1011 12 13141516 30 A
20 A
20 A
20 A
20 A
10 A
20 A
20 A
20 A
10 A
7.5 A
20 A
7.5 A
7.5 A 20 A
20 A
No. Amps. Circuits Protected
Circuits Protected
No. Amps.
Fuses
T aking Care of t he Unexpect ed 319
INTERIOR FUSE BOXES
:
DRIVER’S SIDE
PASSENGER’S SIDE
:

µµ µ
Release the parking brake.
Start the engine.
ShifttoD ,thentoN.
Turn of f the engine.
If your car needs to be towed, call a
prof essional towing service or, if you
belong to one, an organization that
provides roadside assistance. Never
tow your car behind another vehicle
with just a rope or chain. It is very
dangerous.
There are three popular types of
prof essional towing equipment.
The operator
loads your car on the back of a truck.
The tow
truck uses two pivoting arms that go
under the tires (f ront or rear) and lif t
them of f the ground. The other two
tires remain on the ground. The tow
truck uses metal cables with hooks
on the ends. These hooks go around
parts of the f rame or suspension and
the cables lif t that end of the car of f
the ground. Your car’s suspension
and body can be seriously damaged.
If your Honda cannot be transported
by f lat-bed, it should be towed by
wheel-lif t equipment with the f ront
wheels of f the ground. If due to
damage, your car must be towed
with the f ront wheels on the ground,
do the f ollowing:
Release the parking brake.
Shif t the transmission to Neutral. With the f ront wheels on the ground,
it is best to tow the car no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
4
Automatic Transmission:
5-speed Manual Transmission
Flat -bed Equipment
Wheel-L if t Equipment Sling-t ype Equipment
This is the best way to transport
your Honda.
T his is
an acceptable way to tow your
Honda. T his method of towing is
unacceptable.
Emergency T owing
T aking Care of t he Unexpect ed
320 Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
car must be transported with the f ront
wheels of f the ground.

If you decide to tow your car with all
f our wheels on the ground, make
sure you use a properly-designed and
attached tow bar. Prepare the car for
towing as described above, and leave
the ignition switch in Accessory (I)
so the steering wheel does not lock.
Make sure the radio and any items
plugged into the accessory power
socket are turned of f so they do not
rundownthebattery.
Emergency T owing
T aking Care of t he Unexpect ed321
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in Accessory (I), and
make sure the steering wheel turns
f reely bef ore you begin towing. Trying to lif t or tow your car by the
bumpers will cause serious damage.
The bumpers are not designed to
support the car’s weight.
