HONDA ACCORD 2004 CL7 / 7.G Owners Manual

To remove the burned out bulb,
push it in and turn it
counterclockwise until it unlocks.
Install the new bulb and turn it
clockwise to lock it in place.
Insert the socket into the
headlight assembly. Turn it
clockwise to lock it in place.
Testthelightstomakesurethe
new bulb is working.
Put the inner f ender cover in place.
Install and lock each holding clip
bypushingonthecenter.
5. 6. 7. 8. 9.
Lights
Maint enance232
——y
y
(
yy

Open the trunk.
Remove the light assembly cover
by pulling its outside edge.
Remove the socket by turning it
one-quarter turn counterclockwise
and pull the bulb straight out of its
socket.Push a new bulb straight into the
socket until it bottoms, and
reinstall the socket into the light
assembly by turning it clockwise
until it locks.
Open the trunk.
Remove the trim clips f rom the
right or lef t corner of the trunk lid
trim by caref ully prying them
using a small, f lat-tip screwdriver
wrapped with tape.
Testthelightstomakesurethe
new bulb is working.
Reinstall the light assembly cover.
1. 3.
2. 4. 5.
1. 2.
6.
6-cylinder models
CONT INUED
Lights
Maint enance
Replacing Rear Bulbs
(in Fenders)
Replacing Rear Bulbs
(in T runk L id)
233
BULBS
COVER SOCKETS
TRIM CLIPS
——y
y
(
yy

Caref ully bend back the corner of
the trunk lid trim to expose thebulbs.
Remove the socket by turning it
one-quarter turn counterclockwise
and pull the bulb straight out of its
socket.Install a new bulb into the socket
and reinstall the socket into the
light assembly.
Open the trunk and remove the
socket f rom the light assembly by
turning it one-quarter turn counter-
clockwise.
Remove the burned-out bulb by
pulling it straight out of the socket.
Install the new bulb and reinstall
the socket.
Press the trim clips back into their
holes.
Push the trunk lid trim back into
position.
Test the lights.
3. 4. 5.6. 7.1. 2. 3.
8.
Lights
Maint enance
Replacing a High-mount Brake
Light Bulb
234
BULBS
SOCKETS BULBS SOCKETS
BULBSOCKET
——y
y
(
yy

Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.If you use a non-Honda f loor mat,
make sure it f its properly and that it
canbeusedwiththefloormat
anchor. Do not put additional f loor
mats on top of the anchored mat.
This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the heating and
cooling system/climate control
system.
Have your Honda dealer replace this
f ilter every 30,000 miles (48,000 km)
under normal conditions. It should
be replaced every 15,000 miles
(24,000 km) if you drive primarily in
urban areas that have high
concentrations of soot in the air, or if
the f low f rom the climate control
system becomes less than usual.
Clean dirty seat belts with a sof t
brush and a mixture of mild soap and
warm water. Do not use bleach, dye,
or cleaning solvents that can weaken
the belt material. Let the belts air
drybeforeyouusethevehicle.
If you remove the f loor mats, make
sure to re-anchor them when you put
them back in your vehicle.
The driver’s and right rear f loor
mats that came with your vehicle
hooks over the f loor mat anchor.
This keeps the f loor mats f rom
sliding f orward and possibly
interf ering with the pedals or
marking the f ront passenger’s
weight sensors inef f ective.
Seat Belts, Floor Mats, Dust and Pollen Filter
Maint enance
Seat Belts Floor Mats
Dust and Pollen Filter
235
LOOP
——y
y
(
yy

Check the condition of the wiper
blades at least every six months.
Look f or signs of cracking in the
rubber, or areas that are getting
hard. Replace the blades if you f ind
these signs, or if they leave streaks
and unwiped areas when used.To replace a wiper blade:Raise the wiper arm of f the
windshield. Raise the driver’s side
first, then the passenger’s side. Disconnect the blade assembly
fromthewiperarmbypushingin
the lock tab. Hold the lock tab in
while you push the blade assembly
toward the base of the arm.
2.
1.
Wiper Blades
Maint enance236
WIPER ARMS
LOCK TAB
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.
——y
y
(
yy

Remove the blade f rom its holder
by grasping the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder.Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.Slide the new wiper blade into the
holder until the tabs lock.
Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Lower the wiper arm down against
the windshield. Lower the
passenger’s side f irst, then the
driver’s side.
3. 4. 5. 6.
7.
Wiper Blades
Maint enance237
BLADE BLADE
REINFORCEMENT
——y

y
(
yy

Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e, and riding
comf ort.Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly.
We recommend that you visually
check your tires every day. If you
think a tire might be low, check it
immediately with a tire gauge.
To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.
For convenience, the recommended
tire sizes and cold air pressures are
on a label on the driver’s doorjamb.
For additional technical information,
see page .
Use a gauge to measure the air
pressure at least once a month. Even
tires that are in good condition may
lose one to two psi (10 to 20 kPa, 0.1
to 0.2 kgf /cm ) per month.
Remember to check the spare tire at
thesametime.276
Tires
Maint enance
Inf lation
238
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
——y
y
(
y
y

Î Î
ÎÎ
Check the pressure in the tires when
they are cold. This means the vehicle
has been parked f or at least three
hours, or driven less than 1 mile (1.6
km).
Add or release air, if needed, to
match the recommended cold tire
pressuresonthispage.
If you check the pressure when the
tires are hot (driven f or several
miles), you will see readings 4 to 6
psi (30 to 40 kPa, 0.3 to 0.4 kgf /cm )
higher than the cold reading. This is
normal; do not release air to match
the cold pressure.Tubeless tires have some ability to
self -seal if they are punctured. You
should look closely f or punctures if a
tire starts losing pressure.
Youshouldgetyourowntire
pressure gauge and use it whenever
you check your tire pressures. This
will make it easier f or you to tell if a
pressure loss is due to a tire problem
and not due to a variation between
gauges.
Thecompactsparetirepressureis:
All models except LX
LX modelTire Size Cold Tire Pressure
for Normal Driving
Tire Size Cold Tire Pressure for Normal Driving
1 2 Front:
Rear:
EX and V6 models
DX model
Front:
Rear:
1 2
Tires
Maint enance239
60 psi (420 kPa , 4.2 kgf/cm)
P195/65R15 89HP205/60R16 91V 32 psi (220 kPa ,
2.2 kgf/cm
)
30 psi (210 kPa , 2.1 kgf/cm
)
P205/65R15 92H 30 psi (210 kPa ,2.1 kgf/cm
)
29 psi (200 kPa , 2.0 kgf/cm
)
——y
y
(
yy

Every time you check inf lation, you
should also examine the tires f or
damage, f oreign objects, and wear.
Youshouldlookfor:Your vehicle’s tires have wear
indicators molded into the tread.
When the tread wears down to that
point, you will see a 1/2 inch (12.7
mm) wide band running across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread lef t on
the tire. A tire that is this worn gives
very little traction on wet roads. You
should replace the tire if you can see
the tread wear indicator in three or
more places around the tire.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Excessive tread wear.
Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see f abric or cord.
Bumps or bulges in the tread or
side of the tire. Replace the tire if
youfindeitherortheseconditions.
U.S. LX, EX and EX-V6 models
Tires
Maint enance
Tire Inspection
Tire Maintenance
240
NOTICE:
INDICATOR LOCATION MARKS
TREAD WEAR INDICATORS
Improper wheel weights can
damage your vehicle’s aluminum
wheels. Use only genuine Honda
wheels weights f or balancing.
——y
y
(
yy

To help increase tire lif e and
distribute wear more evenly, rotate
the tires every 10,000 miles (16,000
km). Move the tires to the positions
showninthecharteachtimethey
are rotated. If you purchase
directional tires, rotate only f ront-to-
back.Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall). Mixing radial and
bias-ply tires on your vehicle can
reduce braking ability, traction, and
steering accuracy. Using tires of a
dif f erent size or construction can
cause the ABS to work inconsistently.
It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
TheABSworksbycomparingthe
speed of the wheels. When replacing
tires, use the same size originally
supplied with the vehicle. Tire size
and construction can affect wheel
speed and may cause the system to
work.
Maint enance
Tire Rotation Replacing Tires
Tires
241
(For Non-directional
Tires and Wheels) Front Front
(For Directional
Tires and Wheels)
Installing improper tires on your
vehicle can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
——y

y
(
yy
