Service HONDA ACCORD 2004 CL7 / 7.G Owners Manual

µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work, and
it tells you how to properly restrain
inf ants and children in your vehicle.
.........
Important Safety Precautions . 6
.......
Your Vehicle’s Saf ety Features . 7
.......................................
Seat Belts . 8
...........................................
Airbags . 9
.........
Protecting Adults and Teens . 11
.....
1. Close and Lock the Doors . 11
...........
2. Adjust the Front Seats . 12
............
3. Adjust the Seat-Backs . 13
...
4. Adjust the Head Restraints . 14
5. Fasten and Position the Lap/
............
Shoulder Seat Belts . 14
....
6. Adjust the Steering Wheel . 16
7. Maintain a Proper Sitting
................................
Position . 16 .....
Advice f or Pregnant Women . 17
...
Additional Safety Precautions . 18
Additional Inf ormation About Your .................................
Seat Belts . 19
..
Seat Belt System Components . 19
......................
Lap/Shoulder Belt . 19
........ 20
...............
Seat Belt Maintenance . 21
Additional Inf ormation About Your .....................................
Airbags . 22
......
Airbag System Components . 22
......... 23
......................
Advanced Airbags . 25
...
How Your Side Airbags Work . 27
How Your Side Curtain Airbags
.........................................
Work . 28
..
How the SRS Indicator Works . 28
How the Side Airbag Of f
......................
Indicator Works . 29
How the Passenger Airbag Of f
......................
Indicator Works . 31
.............................
Airbag Service . 32
...
Additional Safety Precautions . 33
Protecting Children General ................................
Guidelines . 34 All Children Must Be
...............................
Restrained . 34
All Children Should Sit in the .................................
Back Seat . 35
The Passenger’s Front Airbag .........
Can Pose Serious Risks . 35
..........................................
Inf ants . 35
.............................
Small Children . 35
..........................
Larger Children . 35
If You Must Drive with Several
...................................
Children . 38
If a Child Requires Close ..................................
Attention . 38
...
Additional Safety Precautions . 38
Protecting Inf ants and .........................
Small Children . 40
.......................
Protecting Inf ants . 40
.........
Protecting Small Children . 42
......................
Selecting Child Seats . 43
....................
Installing a Child Seat . 45
Installing a Child Seat Using .....................................
LATCH . 46
...........
Protecting Larger Children . 51
...
Additional Safety Precautions . 55
.............
Carbon Monoxide Hazard . 56
...................................
Saf ety Labels . 57
Automatic Seat Belt Tensioners
How Your Front Airbags Work
Driver and Passenger Saf ety
Driver and Passenger Saf ety
5
——y

y
(
yy

Your airbag systems are virtually
maintenance-f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. If a
f ront airbag inf lates, the seat belt
tensioners must also be replaced.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by a Honda dealer or a
knowledgeable body shop.
Take your vehicle to
an authorized Honda dealer as
soon as possible. If you ignore this
indication, your airbags may not
operate properly. Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor and the f ront
passenger’s weight sensors to
make sure they are operating
properly.
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
Airbag ServiceAn airbag ever inf lates.
T he SRS indicat or light alert s yout o a problem. If your vehicle has a moderat e t o
severe impact .
32
——y

y
(
yy

The security system helps to dis-
courage vandalism and thef t of your
Honda.
The heating and air conditioning
systems in your Honda provide a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section de-
scribes those f eatures and how to
use them.
Your Honda has an anti-thef t audio
system that requires a code number
to enable it.
.............
Vents, Heating, and A/C . 110
...........................
Air Flow Buttons . 112
.............
Vents, Heating, and A/C . 115
..........
Dual Temperature Control . 119
..............
Climate Control Sensors . 121
..........................
Playing the Radio . 122
..............................
To the Radio . 124
....................
To Select a Station . 124
.................
Adjusting the Sound . 127
....................
Radio Frequencies . 128
........................
Radio Reception . 128
..................................
Playing a CD . 130
..........
Playing a CD, CD Changer . 132
.............................
To Play a CD . 132
...............
To Stop Playing a CD . 135
Removing CD’s from the
.................................
Changer . 135
Operating the Optional CD .................................
Changer . 136
.........
CD Player Error Messages . 137
.....
CD Changer Error Messages . 138
.....................
Protecting your CDs . 139
.................
General Inf ormation . 139
.........................
Protecting CD’s . 139
...............................
Playing a Tape . 140
..........................
To Play a Tape . 142 ............
To Stop Playing a Tape . 142
............
Tape Search Functions . 143
.....
Caring the Tape and Player . 144
Playing the XM Satellite ......................................
Radio . 145
...............
Satellite Digital Radio . 145
...
To Play XM Satellite Radio . 146
..................
To Select a Channel . 146
..............
Satellite Radio Signals . 148
Receiving Satellite Radio
....................................
Service . 149
.............
Steering Wheel Controls . 151
.................
Radio Thef t Protection . 152
..........................
Setting the Clock . 153
............................
Security System . 154
...............................
Cruise Control . 155
HomeLink Universal
................................
Transceiver . 158
On all models except 4-cylinder LX
model
Features
Features109
TM
TM
——y

y
(
y

y

Depending on where you drive, you
may experience reception problems.
Interf erence can be caused by any of
these conditions:Drivingonaneast/westroadwith
a mountain on the south side of
the road.
There may be other geographic
situations that could af f ect satellite
radio reception. Driving on a single lane road
alongside dense trees taller than
50 f t. (15 m) to the south of you
Driving on the lower level of a
multi-tiered road
Driving on a road beside a vertical
wall, steep clif f or hill to the south
of you
Driving in the tunnels
Driving on the north side of a
large commercial truck on an
east/west road If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Satellite Radio. With the
ignition switch in the ACCESSORY
(I) or ON (II) position, push the
PWR/VOL knob to turn on the audio
system and press the CD/SAT
button. A variety of music types and
styles will play.As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
CONT INUED
Receiving Satellite Radio Service
Playing the XM Satellite Radio
Features149
TM
——y

y
(
y
y

While awaiting activation, make sure
your vehicle remains in an open area
with good reception. Once your
audio system is activated, ‘‘category’’
or ‘‘CH’’ will appear in the display
and you will be able to listen to XM
Radio broadcasts. XM Radio will
continue to send an activation signal
to your vehicle for at least 12 hours
from activation request. If the
service has not been activated after
36 hours, contact XM Radio.
If you decide to purchase XM
Satellite Radio service, contact XM
Radio at www.xmradio.com, or at
1-800-852-9696. You will need to give
them your radio I.D. number and
your credit card number.
Turn the TUNE knob until ‘‘0’’
appears in the display. Your ID
number will appear in the display.
Af ter you have registered with XM
Radio, keep your audio system in the
SAT Radio mode while you await
activation. This should take about 30
minutes.
Playing the XM Satellite Radio
Features
To get your XM Satellite radio ID
number:
150
TM
——y

y
(
y
y

Bef ore you begin driving your Honda,
youshouldknowwhatgasolineto
use, and how to check the levels of
important f luids. You also need to
know how to properly store luggage
or packages. The inf ormation in this
section will help you. If you plan to
add any accessories to your vehicle,
please read the inf ormation in this
section f irst..............................
Break-in Period . 164
...............................
Gasoline Type . 164
.........
Service Station Procedures . 165
....................................
Ref ueling . 165
Opening and Closing the
.......................................
Hood . 166
...................................
Oil Check . 168
.............
Engine Coolant Check . 169
...............................
Fuel Economy . 170
........
Improving Fuel Economy . 170
....................................
Accessories . 171
.................................
Modif ications . 172
...........
Modif ying Your Vehicle . 172
.............................
Carrying Cargo . 173
..
Carrying Cargo in the Trunk . 175
Carrying Cargo in the
.....
Passenger Compartment . 175
Bef ore Driving
Bef ore Driving163
——y


y
(
y
y

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Do not change the oil until the
scheduled maintenance time.
Avoidhardbrakingforthefirst
200 miles (300 km).
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Your Honda is designed to operate
on unleaded gasoline with a pump
octane number of 86 or higher. Use
of a lower octane gasoline can cause
a persistent, heavy, metallic rapping
noise in the engine that can lead to
mechanical f ailure.
We recommend gasolines containing
detergent additives that help prevent
f uel system and engine deposits.
Using gasoline containing lead will
damage your vehicle’s emissions
controls. This contributes to air
pollution.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the Malfunction Indicator
Lamp on your instrument panel to
come on. If this happens, contact
your authorized Honda dealer f or
service.
Some gasoline today is blended with
oxygenates such as ethanol or
MTBE. Your vehicle is designed to
operate on oxygenated gasoline
containing up to 10 percent ethanol
by volume and up to 15 percent
MTBE by volume. Do not use
gasoline containing methanol.
For f urther important f uel-related
inf ormation, please ref er to your
Quick Start Guide.
Break-in Period, Gasoline T ype
Bef ore Driving
Break-in Period Gasoline Type
164
——y

y
(
y
y

Remove the f uel f ill cap slowly.
You may hear a hissing sound as
pressure inside the tank escapes.
The fuel fill cap is attached to the
f uel f iller with a tether. Put the
attachment on the fuel fill cap into
the slit on the f uel f ill door.
Stop f illing the tank af ter the f uel
nozzle automatically clicks of f . Do
not try to ‘‘top of f ’’ the tank. Leave
some room f or the f uel to expand
with temperature changes.
even though the tank is not f ull,
there may be a problem with your
vehicle’s fuel vapor recovery
system. The system helps keep
f uel vapors f rom going into the
atmosphere. Consult your dealer.
Park with the driver’s side closest
to the gas pump.
Open the f uel f ill door by pulling
onthehandletotheleftof the
driver’s seat. 3. 4.
1. 2.
If the f uel nozzle keeps clicking of f
CONT INUED
Service Station Procedure
Bef ore Driving
Ref ueling
165
FUEL FILL CAP
Push
TETHER
Gasoline is highly flammable
and explosive. You can be
burned or seriously injured
when handling fuel.Stop the engine and keep
heat, sparks, and flamesaway.
Handle fuel only outdoors.
Wipe up spills immediately.
——y


y
(
y
y

To Open the Hood:Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly.
Screw the fuel fill cap back on
until it clicks at least three times.
If you do not properly tighten the
cap, the Malf unction Indicator
Lampmaycomeon(seepage
).
Push the f uel f ill door closed until
it latches.
Put your f ingers under the f ront
edge of the hood to the right of
the center. Slide your hand to the
lef t until you f eel the hood latch
handle. Push this handle up to
release it. Lift up the hood.
If the hood latch handle moves stif f ly,
or if you can open the hood without
lifting the handle, the mechanism
should be cleaned and lubricated.
1.
2.
5. 6.
260
Service Station Procedure
Bef ore Driving
Opening and Closing the Hood
166
HOOD RELEASE HANDLE
LATCH
——y

y
(
y
y

Pull the support rod out of its clip
and insert the end into the hole on
the front of the hood near the
center.
To Close the Hood:
Lif t it up slightly to remove the
support rod f rom the hole. Put the
support rod back into its holding clip.
Lower the hood to about a f oot (30 cm) above the f ender, then let it
drop. Make sure it is securely
latched.
Lif t the hood up most of the way.
The hydraulic supports will lif t it
uptherestof thewayandholditup.
Lower it to about a f oot (30 cm)
above the f ender, then press down
f irmly with your hands. Make sure it is securely latched.
To Close the Hood:
3.
4-cylinder models
4-cylinder models 6-cylinder models
Service Station Procedure
Bef ore Driving167
SUPPORT ROD
——y

y
(
y
y
