Position the lap part of the belt as
low as possible across your hips,
then pull up on the shoulder part of
the belt so the lap part f its snugly.
This lets your strong pelvic bones
take the force of a crash and reduces
the chance of internal injuries.
If necessary, pull up on the belt again
to remove any slack, then check that
the belt rests across the center of
your chest and over your shoulder.
This spreads the f orces of a crashover the strongest bones in your
upper body.
If the seat belt touches or crosses
your neck, or if it crosses your arm
instead of your shoulder, you need to
adjust the seat belt anchor height.
This could cause
very serious injuries in a crash. If a seat belt does not seem to work
as it should, it may not protect the
occupant in a crash.
Using a seat
belt that is not working properly can
result in serious injury or death.
Have your Honda dealer check the
belt as soon as possible.
See page f or additional
inf ormation about your seat belts
and how to take care of them.
To adjust the height of a f ront seat
belt anchor, press the release button
and slide the anchor up or down as
needed (the anchor has f our
positions).
19
CONT INUED
Protecting A dults and Teens
Driver and Passenger Saf ety
Never place t he shoulder port ion of alap/shoulder belt under your arm orbehind your back.
No one should sit in a seat wit h aninoperat ive seat belt .
15
RELEASE
BUTTONS
Improperly positioning the seat
belts can cause serious injury
or death in a crash.
Make sure all seat belts are
properly positioned beforedriving.
——y


y
(
y
y

The security system helps to dis-
courage vandalism and thef t of your
Honda.
The heating and air conditioning
systems in your Honda provide a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section de-
scribes those f eatures and how to
use them.
Your Honda has an anti-thef t audio
system that requires a code number
to enable it.
.............
Vents, Heating, and A/C . 110
...........................
Air Flow Buttons . 112
.............
Vents, Heating, and A/C . 115
..........
Dual Temperature Control . 119
..............
Climate Control Sensors . 121
..........................
Playing the Radio . 122
..............................
To the Radio . 124
....................
To Select a Station . 124
.................
Adjusting the Sound . 127
....................
Radio Frequencies . 128
........................
Radio Reception . 128
..................................
Playing a CD . 130
..........
Playing a CD, CD Changer . 132
.............................
To Play a CD . 132
...............
To Stop Playing a CD . 135
Removing CD’s from the
.................................
Changer . 135
Operating the Optional CD .................................
Changer . 136
.........
CD Player Error Messages . 137
.....
CD Changer Error Messages . 138
.....................
Protecting your CDs . 139
.................
General Inf ormation . 139
.........................
Protecting CD’s . 139
...............................
Playing a Tape . 140
..........................
To Play a Tape . 142 ............
To Stop Playing a Tape . 142
............
Tape Search Functions . 143
.....
Caring the Tape and Player . 144
Playing the XM Satellite ......................................
Radio . 145
...............
Satellite Digital Radio . 145
...
To Play XM Satellite Radio . 146
..................
To Select a Channel . 146
..............
Satellite Radio Signals . 148
Receiving Satellite Radio
....................................
Service . 149
.............
Steering Wheel Controls . 151
.................
Radio Thef t Protection . 152
..........................
Setting the Clock . 153
............................
Security System . 154
...............................
Cruise Control . 155
HomeLink Universal
................................
Transceiver . 158
On all models except 4-cylinder LX
model
Features
Features109
TM
TM
——y

y
(
y

y

Vents, Heating, and A/C
Features110
TEMPERATURE
CONTROL DIAL
MAX A/C BUTTON REAR WINDOW
DEFOGGER BUTTON
TEMPERATURE
CONTROL DIAL
(DRIVER’S SIDE)
FAN CONTROL
BUTTONS
SET TEMPERATURE INDICATOR
TEMPERATURE
CONTROL DIAL
(PASSENGER’S SIDE)
MODE
BUTTON
RECIRCULATION BUTTON AIR
CONDITIONING
BUTTON
AUTO BUTTON
OFF BUTTONDUAL BUTTON WINDSHIELD DEFROST BUTTON
FAN SPEED
INDICATOR
AIR
CONDITIONING
BUTTON MODE BUTTONS
RECIRCULATION BUTTON
REAR WINDOW
DEFOGGER
BUTTON
WINDSHIELD
DEFROST BUTTON
FAN CONTROL DIAL
All models except EX-L and EX-V6 EX-L and EX-V6 Models without Navigation System
——y

y
(
y

y

Vents, Heating, and A/C
Features111
AUTO BUTTONMODE ICONS
A/C BUTTON
AIR CONDITIONING ICONS
FAN CONTROL ICONS
DUAL BUTTON TEMPERATURE CONTROL
BUTTONS (PASSENGER’S SIDE)
RECIRCULATION BUTTON WINDSHIELD DEFROST BUTTONREAR WINDOW DEFOGGER BUTTON
TEMPERATURE CONTROL
BUTTONS (DRIVER’S SIDE) SET TEMPERATURE INDICATOR
OFF BUTTON
EX-L and EX-V6 Models with Navigation System (U.S. Vehicles Only)
——y

y
(
y

y

ÛÝ
Air conditioning is optional f or DX
models. Your Honda dealer can
install a Honda air conditioning
system that is designed to f it in your
vehicle.
For EX-L and EX-V6 with navigation
system, see page f or Automatic
Climate Control and Manual
Operations inf ormation. On EX-L and EX-V6 models with the
navigation system, you can manually
select the f an speed by pressing the
A/C button next to the display and
then, pressing the f an control icons.
On EX-L and EX-V6 models without
the navigation system, you can
manually select the f an speed by
pressing the f an control buttons. The
f an speed is represented by vertical
bars in the display.
On all models except EX-L and
EX-V6, turn this dial clockwise to
increase f an speed and increase the
airflow.
Turning this dial clockwise increases
the temperature of the airflow.For vehicles with the navigation
system, press the DUAL button and
the green indicator will come on.
The driver and passenger can each
select the temperature control
buttons ( or ) to the desired
setting.
When the indicator in the DUAL
button is off, both sides adjust to the
same temperature.
The driver and passenger can select
independent temperature settings by
selecting the DUAL button.
For vehicles without navigation
system, push the DUAL button.
When the indicator in the button is
lit, turn the dials to adjust the
temperature.
117
On all models except EX-L and EX-V6
with Navigation System
On EX-L and EX-V6 models
Heating and Cooling
What Each Control Does T emperature Control
Fan Control
Air Flow Buttons
Features112
——y

y
(
y

y

On all models except EX-L and
EX-V6, this button turns the air
conditioning on and of f . The light
abovethebuttonisonwhentheA/C
is on.
On vehicles without the navigation
system, press the A/C button to turn
on the A/C. You will see A/C ON or
A/C OFF in the display.When the light in or above the
button is on, air f rom the vehicle’s
interior is sent throughout the
system again. When the light is of f ,
air is brought in f rom the outside of
the vehicle (Fresh Air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
ThesystemshouldbeleftinFresh
Air mode under almost all conditions.
Keeping the system in Recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to Recirculation mode when
driving through dusty or smoky
conditions, then return to Fresh Air
mode.
When you turn the A/C of f , the
system cannot regulate the inside
temperature if you set the
temperature control buttons below
the outside temperature.
On vehicles with the navigation
system, press the A/C button to view
the display. Touching ‘‘ON’’ or
‘‘OFF’’ in the display turns the air
conditioningonandoff.Youwillsee
A/C ON or A/C OFF in the display. This button turns the rear window
def ogger of f and on (see page ).77
EX-L and EX-V6Air Conditioning (A/C) Button
Rear Window Def ogger Button
Recirculation Button
Air Flow Buttons
Features113
——y

y
(
y

y

Use the mode control buttons or
icons to select the vents the air f lows
f rom. Some air will f low f rom the
dashboard corner vents in all modes.Air flows from the center
and corner vents in the dashboard.
Air f low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents.
Air f low is divided between
the f loor vents and the def roster
vents at the base of the windshield.
Air f lows f rom the def roster
vents at the base of the windshield. When you select or ,
the system automatically switches to
Fresh Air mode and turns on the
A/C. In these modes, the A/C stays
on with the indicator off.
When you select , the system
automatically switches to Fresh Air
mode.
Set the temperature control dial or
the button to the lower limit.
Make sure the A/C is of f .
Select and Fresh Air mode.
Set the f an to the desired speed.
The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window. The system automatically
turns on the A/C and switches to
Recirculation mode. Air f lows f rom
the center and side vents in the
dashboard.
Each time you press the MODE
button, the display shows the mode
selected.
Press the A/C button to view the
display, then touch any of the mode
icons on the display. 1. 2. 3.4.
For Vehicles without Navigation System
For Vehicles with Navigation System All models except EX-L and EX-V6
On EX-L and EX-V6 model
Mode Control Ventilation
MAX A/C Button
Air Flow Buttons
Features114
——y

y
(
y

y

ÛÝ
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reads normally.
Turn on the A/C by pressing the
button. The light above or in the
button comes on when a f an speed
is selected.
Make sure the temperature
control dial or button is set to their
lower limit.
Select .
If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the f an to the desired speed. Press the A/C button, the Manual
Operation A/C screen will appear.
Select the ON icon on the display.
Select the desired temperature
and MODE selections. If the
outside air is humid, select the
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in Fresh Air mode.
Select .
When you select , the system
automatically switches to the
Fresh Air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control dial.
Press the A/C button, the manual
operation of A/C screen will
appear.
Select the desired mode and f an
speed icons on the display.
Adjustforwarmthwiththe
temperature buttons ( or ). To cool the interior with MAX A/C:
Set the f an to the desired speed.
Select the MAX A/C mode.
The system automatically turns on
the A/C, selects and
switches to Recirculation mode.
Make sure the temperature
control dial is all the way to the left.
1. 2. 3. 4. 5.
1.2. 3. 1.2. 3.
1. 2. 3. 1.2. 3.
69
If the interior is very warm,
On all models except EX-L and EX-V6
Except EX-L and EX-V6 with Navigation
System Except EX-L and EX-V6 with Navigation
SystemEX-L and EX-V6 with Navigation System
EX-L and EX-V6 with Navigation System
Using the Heater Using the A /C
Vents, Heating, and A/C
Features115
——y

y
(
y

y

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.Switch the f an on.
Turn on the air conditioning.
Select and Fresh Air mode.
Adjust the temperature control
dial or buttons to your pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C). To remove f og f rom the inside of the
windows:
Set the f an to the desired speed or
high f or f aster def rosting.
Select . When you select , the system automatically
switches to Fresh Air mode and
turns on the A/C. The A/C
indicator will not come on in U.S.
vehicles.
Set the temperature control dial or
buttons so the airflow feels warm.
Select to help clear the
rear window.
To increase airf low to the
windshield, close the side vents.
When you switch to another mode
f rom , the A/C stays on.
Press the A/C button to turn it of f . Select . The system
automatically switches to Fresh
Air mode and turns on the A/C.
The A/C indicator will not come
on in U.S. vehicles.
Select .
Set the f an and temperature
controls to maximum level.
To clear the windows f aster, you can
close the dashboard corner vents by
rotating the wheel below it. This will
send more warm air to the
windshield def roster vents. Once the
windshield is clear, select the Fresh
Air mode to avoid f ogging the
windows.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving.
1.2.3.4.
1. 2. 3. 4.5.1. 2. 3.
Dehumidif y the Interior T o Def og and Def rost T o Remove Exterior Frost or Ice
From the Windows
Vents, Heating, and A/C
Features116
——y


y
(
y

y

Without Navigation SystemWith Navigation System
On EX-L and EX-V6 models
Your vehicle has two temperature
control dials, one f or the driver, and
one f or the passenger.
Your vehicle has four temperature
control buttons, two f or the driver,
and two f or the passenger.
Thedriver’ssideandthepassenger’s
side can be controlled independently
by adjusting these dials or buttons
when the green indicator in the
DUAL button is lit.
Push AUTO or . The selected
temperatures appear in the upper
display. For vehicles when the
indicator in the DUAL button is of f ,
you can adjust both sides to the
same temperature by adjusting the
driver’s side temperature control dial
or buttons.
CONT INUED
Dual Temperature Control
Comf ort and Convenience Feat ures
T emperat ure Cont rol Dials/But t ons
119
DUAL BUTTON
Without Navigation System
DUAL BUTTON
DRIVER’S SIDE
TEMPERATURE
CONTROL BUTTONS PASSENGER’S SIDE
TEMPERATURE
CONTROL BUTTONS
With Navigation System
DRIVER’S SIDE
TEMPERATURE
CONTROL DIAL
PASSENGER’S SIDE
TEMPERATURE
CONTROL DIAL
——y

y
(
y
y
